class: center, middle, inverse, title-slide # Lecture 7 ## Solution methods for discrete time dynamic models ### Ivan Rudik ### AEM 7130 --- # Roadmap 1. How do we think about solving dynamic economic models 2. Value function iteration 3. Fixed point iteration 4. Time iteration 5. VFI + discretization --- # Things to do 1. Install: `LinearAlgebra, Optim, Plots, Roots` -- 2. Keep in mind that for VFI and TI we will be using optimization/rootfinding packages + This matters because these packages typically only let the functions they work on have one input: the guesses for the maximizing input or root + We get around this by expressing the function as a *closure* + i.e. declare the function inside of a wrapper function that does the maximization/rootfinding so it can access the parameters in the wrapper function -- 3. Keep in mind we will be working with about the simplest example possible, more complex problems will be more difficult to solve in many ways --- # Solutions to economic models How do we solve economic models? -- First, what do we want? -- We want to be able to compute things like optimal policy trajectories, welfare, etc -- There are generally two objects that can deliver what we want: 1. Value functions 2. Policy functions -- The idea behind the most commonly used solution concepts is to recover good approximations to one of these two functions --- # Solutions to economic models We recover these functions by exploiting two things: 1. Dynamic equilibrium conditions incorporating these functions (e.g. Bellman equations, Euler equations) 2. Fixed points -- First lets look at recovering the value function --- # Our general example Consider the following problem we will be using for all of these solution methods: `\begin{gather} \max_{\left\{c_t \right\}_{t=0}^\infty} \sum_{t=1}^\infty \beta^t u(c_t) \notag \\ \text{subject to:} \,\,\,\,\, k_{t+1} = f(k_t) - c_t \notag \end{gather}` where both consumption and time `\(t+1\)` capital are positive, `\(k(0) = k_0\)`, `\(\alpha > 0\)`, and `\(\beta \in (0,1)\)` --- # Our general example Represent the growth model as a Bellman equation `\begin{gather} V(k) = \max_{c} u(c) + \beta V(k') \notag \\ \text{subject to:} \,\,\,\,\, k' = f(k) - c \notag \end{gather}` -- we can reduce this to `$$V(k) = \max_{c} u(c) + \beta V(f(k) - c)$$` --- # Method 1: Value function iteration In VFI we approximate the .hi-blue[value function] with some flexible functional form `\(\Gamma(k_t;b)\)` where `\(b\)` is a vector of coefficients The algorithm has 6 steps --- # Method 1: Value function iteration .hi-blue[Step 1:] Select the number of collocation points in each dimension and the domain of the approximation space -- .hi-blue[Step 2:] Select an initial vector of coefficients `\(b_0\)` with the same number of elements as the collocation grid, and initial guesses for consumption for the solver -- .hi-blue[Step 3:] Select a rule for convergence -- .hi-blue[Step 4:] Construct the grid and basis matrix --- # Method 1: Value function iteration .hi-blue[Step 5:] While convergence criterion `\(>\)` tolerance **(outer loop)** + Start iteration `\(p\)` + For each grid point **(inner loop)** + Solve the right hand side of the Bellman equation at each grid point using the value function approximant `\(\Gamma(k_{t+1};b^{(p)})\)` in place of `\(V(k_{t+1})\)` + Recover the maximized values at each grid point, conditional on the approximant + Fit the polynomial to the values and recover a new vector of coefficients `\(\hat{b}^{(p+1)}\)`. + Compute the vector of coefficients `\(b^{(p+1)}\)` for iteration `\(p+1\)` by `\(b^{(p+1)} = (1-\gamma) b^{(p)} + \gamma \hat{b}^{(p+1)}\)` where `\(\gamma \in (0,1).\)` (damping) + Use the optimal controls for this iteration as our initial guess for next iteration -- .hi-blue[Step 6:] Error check your approximation --- # Functional forms and parameters ## Functional forms - `\(u(c_t) = c_t^{1-\eta}/(1-\eta)\)` - `\(f(k_t) = k_t^\alpha\)` ## Parameters - `\(\alpha = 0.75\)` - `\(\beta = 0.95\)` - `\(\eta = 2\)` ## Initial capital value for simulating - `\(k_0 = (\alpha \beta)^{1/(1-\alpha)}/2\)` --- # Step 1: Select the number of points and domain If `\(k_0 = (\alpha \beta)^{1/(1-\alpha)}/2\)` what are a logical set of bounds for the capital state? -- `\(k^0\)` and the steady state level `\((\alpha \beta)^{1/(1-\alpha)}\)` -- Put everything in a **named tuple** to make passing things easier ```julia using LinearAlgebra using Optim using Plots params = (alpha = 0.75, beta = 0.95, eta = 2, steady_state = (0.75*0.95)^(1/(1 - 0.75)), k_0 = (0.75*0.95)^(1/(1 - 0.75))/2, capital_upper = (0.75*0.95)^(1/(1 - 0.75))*1.01, capital_lower = (0.75*0.95)^(1/(1 - 0.75))/2, num_points = 7, tolerance = 0.0001) ``` ``` ## (alpha = 0.75, beta = 0.95, eta = 2, steady_state = 0.25771486816406236, k_0 = 0.12885743408203118, capital_upper = 0.26029201684570297, capital_lower = 0.12885743408203118, num_points = 7, tolerance = 0.0001) ``` --- # Step 2: Select an initial vector of coefficients `\(b_0\)` In some cases you might have a good guess (e.g. increasing and concave so you know the second value is positive, third value is negative, rest maybe set to zero) -- Other cases you might not, guessing zeros effectively turns the initial iteration into a static problem, the second iteration into a 2 period problem, and so on -- ```julia coefficients = zeros(params.num_points) ``` ``` ## 7-element Array{Float64,1}: ## 0.0 ## 0.0 ## 0.0 ## 0.0 ## 0.0 ## 0.0 ## 0.0 ``` --- # Step 3: Select a convergence rule There's a lot of potential options here to determine convergence of the function -- Relative or absolute change? Or both? -- Change in the value function? Change in the policy function? -- Which norm? -- .hi-blue[Our rule for class:] convergence is when the maximum relative change in value on the grid is < 0.001% --- # Step 4: Construct the grid and basis matrix The function `cheb_nodes` constructs the grid on `\([-1,1]\)` -- Recall: `$$x_k = cos\left(\frac{2k-1}{2n}\pi\right),\,\, k = 1,...,n$$` -- ```julia cheb_nodes(n) = cos.(pi * (2*(1:n) .- 1)./(2n)) ``` ``` ## cheb_nodes (generic function with 1 method) ``` ```julia grid = cheb_nodes(params.num_points) # [-1, 1] grid ``` ``` ## 7-element Array{Float64,1}: ## 0.9749279121818236 ## 0.7818314824680298 ## 0.4338837391175582 ## 6.123233995736766e-17 ## -0.43388373911755806 ## -0.7818314824680297 ## -0.9749279121818236 ``` --- # Step 4: Construct the grid and basis matrix But we need to expand the grid from `\([-1,1]\)` to our actual capital domain -- ```julia expand_grid(grid, params) = (1 .+ grid)*(params.capital_upper - params.capital_lower)/2 .+ params.capital_lower ``` ``` ## expand_grid (generic function with 1 method) ``` ```julia capital_grid = expand_grid(grid, params) ``` ``` ## 7-element Array{Float64,1}: ## 0.2586443471450049 ## 0.2459545728087113 ## 0.2230883895732961 ## 0.19457472546386706 ## 0.16606106135443804 ## 0.14319487811902284 ## 0.13050510378272925 ``` --- # Step 4: Construct the grid and basis matrix Use `cheb_polys` to construct the basis matrix ```julia # Chebyshev polynomial function function cheb_polys(x, n) if n == 0 return 1 # T_0(x) = 1 elseif n == 1 return x # T_1(x) = x else cheb_recursion(x, n) = 2x.*cheb_polys.(x, n - 1) .- cheb_polys.(x, n - 2) return cheb_recursion(x, n) # T_n(x) = 2xT_{n-1}(x) - T_{n-2}(x) end end; ``` --- # Step 4a: Pre-invert your basis matrix .hi-blue[Pro tip:] you will be using the *exact same* basis matrix in each loop iteration to recover the coefficients: just pre-invert it to save time because inverting the same matrix every loop is costly (especially when large) ```julia basis_matrix = [cheb_polys.(grid, n) for n = 0:params.num_points - 1]; basis_matrix = hcat(basis_matrix...) ``` ``` ## 7×7 Array{Float64,2}: ## 1.0 0.974928 0.900969 … 0.62349 0.433884 0.222521 ## 1.0 0.781831 0.222521 -0.900969 -0.974928 -0.62349 ## 1.0 0.433884 -0.62349 -0.222521 0.781831 0.900969 ## 1.0 6.12323e-17 -1.0 1.0 3.06162e-16 -1.0 ## 1.0 -0.433884 -0.62349 -0.222521 -0.781831 0.900969 ## 1.0 -0.781831 0.222521 … -0.900969 0.974928 -0.62349 ## 1.0 -0.974928 0.900969 0.62349 -0.433884 0.222521 ``` ```julia basis_inverse = basis_matrix\I ``` ``` ## 7×7 Array{Float64,2}: ## 0.142857 0.142857 0.142857 … 0.142857 0.142857 0.142857 ## 0.278551 0.22338 0.123967 -0.123967 -0.22338 -0.278551 ## 0.25742 0.0635774 -0.17814 -0.17814 0.0635774 0.25742 ## 0.22338 -0.123967 -0.278551 0.278551 0.123967 -0.22338 ## 0.17814 -0.25742 -0.0635774 -0.0635774 -0.25742 0.17814 ## 0.123967 -0.278551 0.22338 … -0.22338 0.278551 -0.123967 ## 0.0635774 -0.17814 0.25742 0.25742 -0.17814 0.0635774 ``` --- # Step 4b: Evaluate the continuation value To loop and maximize the Bellman at each grid point we need a function `eval_value_function(coefficients, capital, params)` that lets us evaluate the continuation value given a vector of coefficients `coefficients`, a vector of capital nodes `capital`, and the parameters `params` to scale capital back into `\([-1,1]\)` -- It needs to: 1. Scale capital back into `\([-1,1]\)` 2. Use the coefficients and Chebyshev polynomials to evaluate the value function --- # Step 4b: Evaluate the continuation value Here's a simple way to do it: -- ```julia shrink_grid(capital) = 2*(capital - params.capital_lower)/(params.capital_upper - params.capital_lower) - 1; eval_value_function(coefficients, capital, params) = coefficients' * [cheb_polys.(shrink_grid(capital), n) for n = 0:params.num_points - 1]; ``` The top function inherits `params` from the bottom function --- # Step 5: Inner loop over grid points Construct a function that loops over the grid points and solves the Bellman given `\(\Gamma(x;b^{(p)})\)` Pseudocode: ``` for each grid point: define the Bellman as a closure so it can take in parameters maximize the Bellman by choosing consumption with the optimize function store maximize value in a vector end return vector of maximized values ``` --- # Step 5: Inner loop over grid points ```julia function loop_grid(params, basis_inverse, basis_matrix, grid, capital_grid, coefficients) max_value = similar(coefficients); # initialized max value vector # Inner loop over grid points for (iteration, capital) in enumerate(capital_grid) # Define Bellman as a closure function bellman(consumption) capital_next = capital^params.alpha - consumption # Next period state cont_value = eval_value_function(coefficients, capital_next, params) # Continuation value value_out = (consumption)^(1-params.eta)/(1-params.eta) + params.beta*cont_value # Utility + continuation value return -value_out end; results = optimize(bellman, 0.00*capital^params.alpha, 0.99*capital^params.alpha) # maximize Bellman max_value[iteration] = -Optim.minimum(results) # Store max value in vector end return max_value end ``` ``` ## loop_grid (generic function with 1 method) ``` --- # Step 5: Outer loop iterating on Bellman ```julia function solve_vfi(params, basis_inverse, basis_matrix, grid, capital_grid, coefficients) iteration = 1 error = 1e10; max_value = similar(coefficients); value_prev = .1*ones(params.num_points); coefficients_store = Vector{Vector}(undef, 1) coefficients_store[1] = coefficients while error > params.tolerance # Outer loop iterating on Bellman eq max_value = loop_grid(params, basis_inverse, basis_matrix, grid, capital_grid, coefficients) # Inner loop coefficients = basis_inverse*max_value # \Psi \ y, recover coefficients error = maximum(abs.((max_value - value_prev)./(value_prev))) # compute error value_prev = deepcopy(max_value) # save previous values if mod(iteration, 5) == 0 println("Maximum Error of $(error) on iteration $(iteration).") append!(coefficients_store, [coefficients]) end iteration += 1 end return coefficients, max_value, coefficients_store end ``` ``` ## solve_vfi (generic function with 1 method) ``` --- # Step 5: Outer loop iterating on Bellman ```julia solution_coeffs, max_value, intermediate_coefficients = solve_vfi(params, basis_inverse, basis_matrix, grid, capital_grid, coefficients) ``` ``` ## Maximum Error of 0.3301919884226087 on iteration 5. ## Maximum Error of 0.1080139919745119 on iteration 10. ## Maximum Error of 0.05647917855011529 on iteration 15. ## Maximum Error of 0.034833389245083224 on iteration 20. ## Maximum Error of 0.02328643376111153 on iteration 25. ## Maximum Error of 0.016301543092581427 on iteration 30. ## Maximum Error of 0.011747480470414 on iteration 35. ## Maximum Error of 0.008631245645920336 on iteration 40. ## Maximum Error of 0.006427690604127001 on iteration 45. ## Maximum Error of 0.0048330736842455225 on iteration 50. ## Maximum Error of 0.0036597148900624123 on iteration 55. ## Maximum Error of 0.002785692376976503 on iteration 60. ## Maximum Error of 0.0021286867102129677 on iteration 65. ## Maximum Error of 0.0016314249677370316 on iteration 70. ## Maximum Error of 0.0012531160571391219 on iteration 75. ## Maximum Error of 0.000964170879127405 on iteration 80. ## Maximum Error of 0.0007428166750767927 on iteration 85. ## Maximum Error of 0.0005728521498806172 on iteration 90. ## Maximum Error of 0.0004421161961630202 on iteration 95. ## Maximum Error of 0.00034141814527728653 on iteration 100. ## Maximum Error of 0.0002637753971325223 on iteration 105. ## Maximum Error of 0.00020386108209645033 on iteration 110. ## Maximum Error of 0.00015759845903308656 on iteration 115. ## Maximum Error of 0.00012185979301915734 on iteration 120. ``` ``` ## ([-200.6291758538632, 9.991472391067802, -1.2278992641150595, 0.17379460460092133, -0.0262119101944549, 0.003954006913225783, -0.0007409750421256689], [-191.87342361439286, -193.14594489252312, -195.68963652528421, -199.42674752490046, -204.02721963808617, -208.61071718644223, -211.6305415954132], Array{T,1} where T[[0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], [-36.8589490106075, 6.259861237095166, -0.8221318972861571, 0.11882022830526928, -0.01784945487786871, 0.00269203315390687, -0.00037520235134058666], [-74.87645132736965, 8.931829874526976, -1.1238227131298792, 0.1608047649285531, -0.024292798807126204, 0.0039027323348115317, -0.0006447123917387998], [-103.80959945589598, 9.68901311684359, -1.1994026067805663, 0.1705609554663461, -0.0255481405498017, 0.003969430583547151, -0.0007161344250450341], [-125.9200308753978, 9.904403319377032, -1.219552059022945, 0.17300404781584788, -0.026010058299306138, 0.0039595903769296115, -0.0007341995822489622], [-142.9397465762615, 9.966570886453908, -1.2253830534940988, 0.1735771626051843, -0.02615385493585265, 0.003955453304666179, -0.0007391283603670473], [-156.08276002781142, 9.984453747414598, -1.2271575579534755, 0.1737309439806367, -0.02619527771992125, 0.003954320282257839, -0.0007404618310982158], [-166.2448607828197, 9.989518053393965, -1.2276872050894383, 0.1737761442042398, -0.026207193540553675, 0.003954072102075656, -0.0007408314670129812], [-174.10590746285365, 9.990932110798063, -1.2278398648722586, 0.17378937493059254, -0.026210590152359714, 0.003954021287697174, -0.0007409350663660774], [-180.18802216175297, 9.991323564318797, -1.2278828039994707, 0.1737931465991167, -0.026211544200975823, 0.003954010369653815, -0.0007409639787887556] … [-196.52576254532732, 9.991472327014705, -1.2278992569992653, 0.17379460396753643, -0.02621191003608203, 0.0039540069145189705, -0.0007409750373632562], [-197.5358441489631, 9.991472373473798, -1.2278992621604772, 0.17379460442691652, -0.026211910150955475, 0.0039540069135881595, -0.0007409750408040594], [-198.3174260190019, 9.991472386235223, -1.2278992635781947, 0.17379460455315154, -0.026211910182489362, 0.00395400691330039, -0.0007409750417757266], [-198.92219916559213, 9.991472389740558, -1.2278992639676147, 0.17379460458784024, -0.02621191019120772, 0.003954006913229335, -0.0007409750420261929], [-199.39016109641344, 9.991472390703436, -1.2278992640745656, 0.17379460459731177, -0.026211910193559618, 0.0039540069132151245, -0.0007409750420777073], [-199.75226111754048, 9.991472390967878, -1.227899264103975, 0.17379460459993368, -0.02621191019424174, 0.003954006913200914, -0.0007409750421203398], [-200.0324472112422, 9.991472391040567, -1.2278992641120254, 0.17379460460063711, -0.026211910194398058, 0.003954006913229335, -0.0007409750421185635], [-200.24924986946957, 9.991472391060476, -1.227899264114292, 0.1737946046008929, -0.026211910194433585, 0.0039540069131902555, -0.0007409750420972472], [-200.41700763359654, 9.99147239106594, -1.2278992641148818, 0.1737946046008929, -0.026211910194390953, 0.00395400691322223, -0.0007409750421132344], [-200.54681539359328, 9.991472391067411, -1.2278992641150026, 0.17379460460090712, -0.0262119101944549, 0.003954006913208019, -0.0007409750421345507]]) ``` --- # Now lets plot our solutions ```julia capital_levels = range(params.capital_lower, params.capital_upper, length = 100); eval_points = shrink_grid.(capital_levels); solution = similar(intermediate_coefficients); # Compute optimal value at all capital grid points for (iteration, coeffs) in enumerate(intermediate_coefficients) solution[iteration] = [coeffs' * [cheb_polys.(capital, n) for n = 0:params.num_points - 1] for capital in eval_points]; end ``` --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-12-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-13-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-14-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-15-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-16-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-17-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-18-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-19-J1.png" width="800" /> --- # Plot the value function iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-20-J1.png" width="800" /> --- # Plot the final value function <img src="7_solution_methods_files/figure-html/unnamed-chunk-21-J1.png" width="800" /> --- # Now lets try simulating ```julia function simulate_model(params, solution_coeffs, time_horizon = 100) capital_store = zeros(time_horizon + 1) consumption_store = zeros(time_horizon) capital_store[1] = params.k_0 for t = 1:time_horizon capital = capital_store[t] function bellman(consumption) capital_next = capital^params.alpha - consumption capital_next_scaled = shrink_grid(capital_next) cont_value = solution_coeffs' * [cheb_polys.(capital_next_scaled, n) for n = 0:params.num_points - 1] value_out = (consumption)^(1-params.eta)/(1-params.eta) + params.beta*cont_value return -value_out end; results = optimize(bellman, 0.0, capital^params.alpha) consumption_store[t] = Optim.minimizer(results) capital_store[t+1] = capital^params.alpha - consumption_store[t] end return consumption_store, capital_store end; ``` --- # Now lets try simulating <img src="7_solution_methods_files/figure-html/unnamed-chunk-23-J1.png" width="800" /> --- # The consumption policy function ```julia capital_levels = range(params.capital_lower, params.capital_upper, length = 100); consumption = similar(capital_levels); # Compute optimal consumption at all capital grid points for (iteration, capital) in enumerate(capital_levels) function bellman(consumption) capital_next = capital^params.alpha - consumption capital_next_scaled = shrink_grid(capital_next) cont_value = solution_coeffs' * [cheb_polys.(capital_next_scaled, n) for n = 0:params.num_points - 1] value_out = (consumption)^(1-params.eta)/(1-params.eta) + params.beta*cont_value return -value_out end results = optimize(bellman, 0., capital^params.alpha) consumption[iteration] = Optim.minimizer(results) end; ``` --- # The consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-25-J1.png" width="800" /> --- # Method 2: Fixed point iteration In FPI we generally approximate a *policy function* with some flexible functional form `\(\Gamma(k_t;b)\)` where `\(b\)` is a vector of coefficients -- FPI re-casts equilibrium conditions of the model as a fixed point -- We then perform multi-dimensional function iteration to solve for the fixed point -- This ends up being very simple and it works on any dimension function -- It is also does not bear a terrible computational cost and is derivative-free -- The drawback is that it will not always converge and is generally unstable -- This can be solved by .hi-blue[damping] --- # Eq condition: Euler equation Often we will iterate on the Euler equation which for our problem is `$$u'(c_t) = \beta u'(c_{t+1}) f'(k_{t+1})$$` -- We need to put this in a fixed point form in order to iterate on it `$$c_t = u'^{(-1)}\left(\beta u'(c_{t+1}) f'(k_{t+1})\right)$$` -- How do we solve this? --- # Eq condition: Euler equation `$$c_t = u'^{(-1)}\left(\beta u'(c_{t+1}) f'(k_{t+1})\right)$$` We approximate the consumption policy function `\(c_{t} = C(k_t)\)` with some flexible functional form `\(\Psi(k_t; b)\)` -- We have defined `\(c_{t}\)` in two ways, once as an outcome of the policy function, and once as an equilibrium condition -- Now we can form our consumption policy function as a fixed point by substituting `\(C(k_t)\)` into the the Euler fixed point as follows `$$C(k_t) = u'^{(-1)}\left(\beta u'(C(k_{t+1})) f'(k_{t+1}(C(k_t),k_t))\right)$$` --- # Method 2: Fixed point iteration The algorithm has 6 steps, very similar to VFI --- # Method 2: Fixed point iteration .hi-blue[Step 1:] Select the number of collocation points in each dimension and the domain of the approximation space -- .hi-blue[Step 2:] Select an initial vector of coefficients `\(b_0\)` with the same number of elements as the collocation grid -- .hi-blue[Step 3:] Select a rule for convergence -- .hi-blue[Step 4:] Construct the grid and basis matrix --- # Method 2: Fixed point iteration .hi-blue[Step 5:] While convergence criterion `\(>\)` tolerance **(outer loop)** + Start iteration `\(p\)` + For each grid point **(inner loop)** + Substitute `\(C(k_{t+1};b^{(p)})\)` into the right hand side of the Euler fixed point + Recover the LHS values of consumption at each grid point + Fit the polynomial to the values and recover a new vector of coefficients `\(\hat{b}^{(p+1)}\)`. + Compute the vector of coefficients `\(b^{(p+1)}\)` for iteration `\(p+1\)` by `\(b^{(p+1)} = (1-\gamma) b^{(p)} + \gamma \hat{b}^{(p+1)}\)` where `\(\gamma \in (0,1).\)` (damping) -- .hi-blue[Step 6:] Error check your approximation Notice: we did not have to perform a maximization step .hi-red[anywhere], this leads to big speed gains --- # Step 1: Select the number of points and domain Put everything in a **named tuple** to make passing things easier ```julia using LinearAlgebra using Optim using Plots params_fpi = (alpha = 0.75, beta = 0.95, eta = 2, damp = 0.7, steady_state = (0.75*0.95)^(1/(1-0.75)), k_0 = (0.75*0.95)^(1/(1-0.75))*0.5, capital_upper = (0.75*0.95)^(1/(1-0.75))*1.5, capital_lower = (0.75*0.95)^(1/(1-0.75))*0.5, num_points = 5, tolerance = 0.00001) ``` ``` ## (alpha = 0.75, beta = 0.95, eta = 2, damp = 0.7, steady_state = 0.25771486816406236, k_0 = 0.12885743408203118, capital_upper = 0.3865723022460935, capital_lower = 0.12885743408203118, num_points = 5, tolerance = 1.0e-5) ``` ```julia shrink_grid(capital) = 2*(capital - params_fpi.capital_lower)/(params_fpi.capital_upper - params_fpi.capital_lower) - 1 ``` ``` ## shrink_grid (generic function with 1 method) ``` --- # Step 2: Select an initial vector of coefficients `\(b_0\)` ```julia coefficients = zeros(params_fpi.num_points) ``` ``` ## 5-element Array{Float64,1}: ## 0.0 ## 0.0 ## 0.0 ## 0.0 ## 0.0 ``` --- # Step 3: Select a convergence rule Rule: maximum change in consumption on the grid < 0.001% --- # Step 4: Construct the grid and basis matrix The function `cheb_nodes` constructs the grid on `\([-1,1]\)` -- Recall: `$$x_k = cos\left(\frac{2k-1}{2n}\pi\right),\,\, k = 1,...,n$$` -- ```julia cheb_nodes(n) = cos.(pi * (2*(1:n) .- 1)./(2n)) ``` ``` ## cheb_nodes (generic function with 1 method) ``` ```julia grid = cheb_nodes(params_fpi.num_points) # [-1, 1] grid ``` ``` ## 5-element Array{Float64,1}: ## 0.9510565162951535 ## 0.5877852522924731 ## 6.123233995736766e-17 ## -0.587785252292473 ## -0.9510565162951535 ``` --- # Step 4: Construct the grid and basis matrix But we need to expand the grid from `\([-1,1]\)` to our actual capital domain -- ```julia expand_grid(grid, params_fpi) = (1 .+ grid)*(params_fpi.capital_upper - params_fpi.capital_lower)/2 .+ params_fpi.capital_lower ``` ``` ## expand_grid (generic function with 1 method) ``` ```julia capital_grid = expand_grid(grid, params_fpi) ``` ``` ## 5-element Array{Float64,1}: ## 0.3802655705208513 ## 0.33345536756572974 ## 0.2577148681640623 ## 0.18197436876239492 ## 0.1351641658072734 ``` --- # Step 4: Construct the grid and basis matrix Use `cheb_polys` to construct the basis matrix ```julia # Chebyshev polynomial function function cheb_polys(x, n) if n == 0 return 1 # T_0(x) = 1 elseif n == 1 return x # T_1(x) = x else cheb_recursion(x, n) = 2x.*cheb_polys.(x, n - 1) .- cheb_polys.(x, n - 2) return cheb_recursion(x, n) # T_n(x) = 2xT_{n-1}(x) - T_{n-2}(x) end end; ``` --- # Step 4a: Pre-invert your basis matrix .hi-blue[Pro tip:] you will be using the *exact same* basis matrix in each loop iteration to recover the coefficients: just pre-invert it to save time because inverting the same matrix every loop is costly (especially when large) ```julia basis_matrix = [cheb_polys.(grid, n) for n = 0:params_fpi.num_points - 1]; basis_matrix = hcat(basis_matrix...) ``` ``` ## 5×5 Array{Float64,2}: ## 1.0 0.951057 0.809017 0.587785 0.309017 ## 1.0 0.587785 -0.309017 -0.951057 -0.809017 ## 1.0 6.12323e-17 -1.0 -1.83697e-16 1.0 ## 1.0 -0.587785 -0.309017 0.951057 -0.809017 ## 1.0 -0.951057 0.809017 -0.587785 0.309017 ``` ```julia basis_inverse = basis_matrix\I ``` ``` ## 5×5 Array{Float64,2}: ## 0.2 0.2 0.2 0.2 0.2 ## 0.380423 0.235114 5.55112e-17 -0.235114 -0.380423 ## 0.323607 -0.123607 -0.4 -0.123607 0.323607 ## 0.235114 -0.380423 -8.32667e-17 0.380423 -0.235114 ## 0.123607 -0.323607 0.4 -0.323607 0.123607 ``` --- # Step 4b: Evaluate the policy function To loop and maximize the Bellman at each grid point we need a function `eval_policy_function(coefficients, capital, params_fpi)` that lets us evaluate the policy function given a vector of coefficients `coefficients`, a vector of capital nodes `capital`, and the parameters `params_fpi` to scale capital back into `\([-1,1]\)` -- It needs to: 1. Scale capital back into `\([-1,1]\)` 2. Use the coefficients and Chebyshev polynomials to evaluate the value function --- # Step 4b: Evaluate the policy function Here's a simple way to do it: -- ```julia shrink_grid(capital) = 2*(capital - params_fpi.capital_lower)/(params_fpi.capital_upper - params_fpi.capital_lower) - 1; eval_policy_function(coefficients, capital, params_fpi) = coefficients' * [cheb_polys.(shrink_grid(capital), n) for n = 0:params_fpi.num_points - 1]; ``` The top function inherits `params_fpi` from the bottom function --- # Step 5: Loop Construct the Euler fixed point function ```julia function consumption_euler(params_fpi, capital, coefficients) # RHS: Current consumption given current capital consumption = eval_policy_function(coefficients, capital, params_fpi) # RHS: Next period's capital given current capital and consumption capital_next = capital^params_fpi.alpha - consumption # RHS: Next period's consumption given current capital and consumption consumption_next = eval_policy_function(coefficients, capital_next, params_fpi) consumption_next = max(1e-10, consumption_next) # LHS: Next period's consumption from Euler equation consumption_lhs = ( params_fpi.beta * consumption_next^(-params_fpi.eta) * params_fpi.alpha*(capital_next).^(params_fpi.alpha-1) ).^(-1/params_fpi.eta) return consumption_lhs end ``` ``` ## consumption_euler (generic function with 1 method) ``` --- # Step 5: Loop Construct a function that loops over the grid points and solves the Euler given `\(\Psi(x;b^{(p)})\)` ```julia function loop_grid_fpi(params_fpi, basis_inverse, basis_matrix, grid, capital_grid, coefficients) consumption = similar(coefficients) # Compute next period's consumption from the Euler equation for (iteration, capital) in enumerate(capital_grid) consumption[iteration] = consumption_euler(params_fpi, capital, coefficients) end return consumption end ``` ``` ## loop_grid_fpi (generic function with 1 method) ``` --- # Step 5: Loop ```julia function solve_fpi(params_fpi, basis_inverse, basis_matrix, grid, capital_grid, coefficients) error = 1e10 iteration = 1 consumption = similar(coefficients) consumption_prev, coefficients_prev = similar(coefficients), similar(coefficients) coefficients_store = Vector{Vector}(undef, 1) coefficients_store[1] = coefficients while error > params_fpi.tolerance consumption = loop_grid_fpi(params_fpi, basis_inverse, basis_matrix, grid, capital_grid, coefficients) if iteration > 1 coefficients = params_fpi.damp*(basis_inverse*consumption) + (1 - params_fpi.damp)*coefficients_prev else coefficients = basis_inverse*consumption end error = maximum(abs.((consumption - consumption_prev)./(consumption_prev))) coefficients_prev, consumption_prev = deepcopy(coefficients), deepcopy(consumption) if mod(iteration, 5) == 0 println("Maximum Error of $(error) on iteration $(iteration).") append!(coefficients_store, [coefficients]) end iteration += 1 end return coefficients, consumption, coefficients_store end ``` ``` ## solve_fpi (generic function with 1 method) ``` --- # Step 5: Loop ```julia solution_coeffs, consumption, intermediate_coefficients = solve_fpi(params_fpi, basis_inverse, basis_matrix, grid, capital_grid, coefficients) ``` ``` ## Maximum Error of 0.06899533243794735 on iteration 5. ## Maximum Error of 1.481484091434361 on iteration 10. ## Maximum Error of 0.7160886352974187 on iteration 15. ## Maximum Error of 0.3030829029947649 on iteration 20. ## Maximum Error of 0.1747314280387973 on iteration 25. ## Maximum Error of 505.49415653346773 on iteration 30. ## Maximum Error of 1.193581540407262 on iteration 35. ## Maximum Error of 0.2847765742028598 on iteration 40. ## Maximum Error of 0.1953733398047281 on iteration 45. ## Maximum Error of 236164.34258207615 on iteration 50. ## Maximum Error of 1.4738022100415356 on iteration 55. ## Maximum Error of 0.38721294652038635 on iteration 60. ## Maximum Error of 0.21074834398476477 on iteration 65. ## Maximum Error of 0.23613685495903153 on iteration 70. ## Maximum Error of 4.722253097188453 on iteration 75. ## Maximum Error of 0.03764118069395616 on iteration 80. ## Maximum Error of 0.007970939090958102 on iteration 85. ## Maximum Error of 0.0025735627849945903 on iteration 90. ## Maximum Error of 0.0009352774342816211 on iteration 95. ## Maximum Error of 0.0003237453048973147 on iteration 100. ## Maximum Error of 0.00010972350926806329 on iteration 105. ## Maximum Error of 3.685905281539792e-5 on iteration 110. ## Maximum Error of 1.2336267929334763e-5 on iteration 115. ``` ``` ## ([0.10216143756493291, 0.030492616130876768, -0.0018615048468132258, 0.0002412084612514174, -3.673979487435926e-5], [0.12978669111539357, 0.12046064710918444, 0.10398662400247835, 0.08507298585014693, 0.07150233223860529], Array{T,1} where T[[0.0, 0.0, 0.0, 0.0, 0.0], [1.2763130221485964e-10, 7.183782174427739e-12, -5.1738097170530396e-12, -2.5864997862853625e-13, -8.831154889933433e-14], [5.317142229921049e-10, 5.527847778513712e-10, 1.6703532060316548e-10, 1.8141243875066817e-11, -1.447815296122337e-13], [8.316967352701557e-9, 5.1875398530251166e-9, 2.0308557486015783e-10, -1.1491354530189611e-11, 1.7095212937975535e-12], [3.386275892864933e-8, 1.2764008226603924e-8, -3.091246647800147e-10, 4.0250161382908916e-11, -1.1414762945221957e-11], [7.52422641928251e-8, 1.0570161284975366e-8, -4.436605014141635e-9, -1.174432549622199e-10, -4.947771112908894e-11], [3.5815259527248966e-8, -1.4472091279968585e-8, 1.834736552630338e-8, 5.228523646511384e-9, -1.5039924808248198e-10], [8.649742496094897e-7, 6.24025102132348e-7, 2.5809596059877958e-8, -5.853265390446539e-9, 3.605947196166565e-10], [3.557675838337089e-6, 1.2735910170908482e-6, -3.0722078466656094e-8, 1.0900582853788604e-8, -1.2927503422953689e-9], [8.396083635269678e-6, 1.5757179125057394e-6, -4.34579079208472e-7, -2.0463275140734446e-8, -5.01406374442219e-9] … [0.014880293346307229, -0.0012599250822342666, -0.0016020724342596764, -7.459264578786532e-5, -2.116862090455988e-5], [0.06056412987240832, 0.05723653749340376, -0.002784166148579988, -0.004137596592328633, 0.0038802212866255025], [0.09274367453966734, 0.02965908339159335, -0.0016114105549141255, 0.00024575125177950144, -3.150220775509663e-5], [0.09883950641207304, 0.02942554740820863, -0.001774882853544672, 0.00023321088845588143, -3.695484542590681e-5], [0.10100737679048473, 0.030003914490261078, -0.0018414718812655218, 0.00023999644919096, -3.7123219490591355e-5], [0.10177119243335409, 0.03030979782120775, -0.0018570023721880147, 0.00024112552978790023, -3.6907250737000245e-5], [0.10203276998407984, 0.03042983416898875, -0.0018604002640126983, 0.00024122771243408221, -3.679946836529483e-5], [0.10212100280888622, 0.03047255019091084, -0.0018612121452150179, 0.0002412205464725234, -3.675909294053858e-5], [0.10215057465288752, 0.03048718729579106, -0.001861432535354346, 0.00024121237383887737, -3.6745039179336284e-5], [0.10216046106906573, 0.030492126707819756, -0.0018614985832312249, 0.00024120883727619163, -3.674026850712608e-5]]) ``` --- # Now lets plot our solutions ```julia capital_levels = range(params_fpi.capital_lower, params_fpi.capital_upper, length = 100); eval_points = shrink_grid.(capital_levels); solution = similar(intermediate_coefficients); for (iteration, coeffs) in enumerate(intermediate_coefficients) solution[iteration] = [coeffs'*[cheb_polys.(capital, n) for n = 0:params_fpi.num_points - 1] for capital in eval_points]; end ``` --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-38-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-39-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-40-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-41-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-42-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-43-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-44-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-45-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-46-J1.png" width="800" /> --- # Plot the final consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-47-J1.png" width="800" /> --- # Now lets try simulating ```julia function simulate_model(params, solution_coeffs, time_horizon = 100) capital_store = zeros(time_horizon + 1) consumption_store = zeros(time_horizon) capital_store[1] = params.k_0 for t = 1:time_horizon capital = capital_store[t] consumption_store[t] = consumption_euler(params, capital, solution_coeffs) capital_store[t+1] = capital^params.alpha - consumption_store[t] end return consumption_store, capital_store end ``` ``` ## simulate_model (generic function with 2 methods) ``` --- # Now lets try simulating ```julia time_horizon = 100; consumption, capital = simulate_model(params_fpi, solution_coeffs, time_horizon); plot(1:time_horizon, consumption, color = :red, linewidth = 4.0, tickfontsize = 14, guidefontsize = 14, label = "Consumption", legend = :right, grid = false, size = (500, 300)); plot!(1:time_horizon, capital[1:end-1], color = :blue, linewidth = 4.0, linestyle = :dash, label = "Capital"); plot!(1:time_horizon, params_fpi.steady_state*ones(time_horizon), color = :purple, linewidth = 2.0, linestyle = :dot, label = "Steady State Capital") ``` <img src="7_solution_methods_files/figure-html/unnamed-chunk-49-J1.png" width="667" /> --- # Method 3: Time iteration In time iteration we approximate the *policy function* with some flexible functional form `\(\Psi(k_t;b)\)` where `\(b\)` is a vector of coefficients -- The difference vs FPI is we use root-finding techniques on our `\(n\)` node collocation grid where we search for the .hi-red[scalar] `\(c^{(p+1)}(k_t)\)` that solves `$$u'(c^{(p+1)}(k^j_t)) = \beta u'(C^{(p)}(f(k^j_t)-c^{(p+1)}(k^j_t))) f'(f(k^i_t)-c^{(p+1)}(k^j_t)) \,\,\,\, \text{for j } = 1,...,n$$` -- `\(C^{(p)}()\)` is our current approximation to the policy function, and we are searching for a .hi-red[scalar] `\(c^{(p+1)}(k^j_t)\)`, given our collocation node `\(k_t^j\)`, that solves the Euler equation root-finding problem -- In the Euler equation `\(c^{(p+1)}\)` corresponds to today's policy function while `\(C^{(p)}\)` corresponds to tomorrow's policy function: we are searching for today's policy that satisfies the Euler equation --- # Method 3: Time iteration As we iterate and `\(p\)` increases, `\(C^{(p)}(k)\)` should converge because of a *monotonicity property* -- If `\(C'^{(p)}(k) > 0\)`, and `\(C^{(p)}(k) < C^{(p-1)}(k)\)`, then `\(C^{(p+1)}(k) < C^{(p)}(k)\)` and `\(C'^{(p+1)}(k) > 0\)` -- It preserves the (first-order) shape of the policy function so it is reliable and convergent -- Unfortunately time iteration tends to be slow, especially as the number of dimensions grows --- # Method 3: Time iteration .hi-blue[Step 1:] Select the number of collocation points in each dimension and the domain of the approximation space -- .hi-blue[Step 2:] Select an initial vector of coefficients `\(b_0\)` with the same number of elements as the collocation grid, and initial guesses for consumption for the root-finder -- .hi-blue[Step 3:] Select a rule for convergence -- .hi-blue[Step 4:] Construct the grid and basis matrix --- # Method 3: Time iteration .hi-blue[Step 5:] While convergence criterion `\(>\)` tolerance **(outer loop)** + Start iteration `\(p\)` + For each grid point **(inner loop)** + Substitute `\(C(k^j_{t+1};b^{(p)})\)` in for `\(t+1\)` consumption + Recover the `\(c^{(p+1)}(k^j_t) \in \mathbb{R}\)` scalar values that satisfy the equation + Fit the polynomial to the values and recover a new vector of coefficients `\(\hat{b}^{(p+1)}\)` + Compute the vector of coefficients `\(b^{(p+1)}\)` for iteration `\(p+1\)` by `\(b^{(p+1)} = (1-\gamma) b^{(p)} + \gamma \hat{b}^{(p+1)}\)` where `\(\gamma \in (0,1)\)` (damping) + Error check your approximation --- # Step 1: Select the number of points and domain Put everything in a **named tuple** to make passing things easier ```julia using LinearAlgebra using Optim using Plots using Roots params_ti = (alpha = 0.75, beta = 0.95, eta = 2, damp = 0.7, steady_state = (0.75*0.95)^(1/(1-0.75)), k_0 = (0.75*0.95)^(1/(1-0.75))*0.5, capital_upper = (0.75*0.95)^(1/(1-0.75))*1.5, capital_lower = (0.75*0.95)^(1/(1-0.75))*0.5, num_points = 5, tolerance = 0.00001) ``` ``` ## (alpha = 0.75, beta = 0.95, eta = 2, damp = 0.7, steady_state = 0.25771486816406236, k_0 = 0.12885743408203118, capital_upper = 0.3865723022460935, capital_lower = 0.12885743408203118, num_points = 5, tolerance = 1.0e-5) ``` ```julia shrink_grid(capital) = 2*(capital - params_ti.capital_lower)/(params_ti.capital_upper - params_ti.capital_lower) - 1 ``` ``` ## shrink_grid (generic function with 1 method) ``` --- # Step 2: Select an initial vector of coefficients `\(b_0\)` In some cases you might have a good guess (e.g. increasing and concave so you know the second value is positive, third value is negative, rest maybe set to zero) -- Other cases you might not, guessing zeros effectively turns the initial iteration into a static problem, the second iteration into a 2 period problem, and so on -- ```julia coefficients = zeros(params_ti.num_points) ``` ``` ## 5-element Array{Float64,1}: ## 0.0 ## 0.0 ## 0.0 ## 0.0 ## 0.0 ``` --- # Step 3: Select a convergence rule There's a lot of potential options here to determine convergence of the function -- Relative or absolute change? Or both? -- Change in the value function? Change in the policy function? -- Which norm? -- .hi-blue[Our rule for class:] convergence is when the maximum relative change in value on the grid is < 0.001% --- # Step 4: Construct the grid and basis matrix The function `cheb_nodes` constructs the grid on `\([-1,1]\)` -- Recall: `$$x_k = cos\left(\frac{2k-1}{2n}\pi\right),\,\, k = 1,...,n$$` -- ```julia cheb_nodes(n) = cos.(pi * (2*(1:n) .- 1)./(2n)) ``` ``` ## cheb_nodes (generic function with 1 method) ``` ```julia grid = cheb_nodes(params_ti.num_points) # [-1, 1] grid ``` ``` ## 5-element Array{Float64,1}: ## 0.9510565162951535 ## 0.5877852522924731 ## 6.123233995736766e-17 ## -0.587785252292473 ## -0.9510565162951535 ``` --- # Step 4: Construct the grid and basis matrix But we need to expand the grid from `\([-1,1]\)` to our actual capital domain -- ```julia expand_grid(grid, params_ti) = (1 .+ grid)*(params_ti.capital_upper - params_ti.capital_lower)/2 .+ params_ti.capital_lower ``` ``` ## expand_grid (generic function with 1 method) ``` ```julia capital_grid = expand_grid(grid, params_ti) ``` ``` ## 5-element Array{Float64,1}: ## 0.3802655705208513 ## 0.33345536756572974 ## 0.2577148681640623 ## 0.18197436876239492 ## 0.1351641658072734 ``` --- # Step 4: Construct the grid and basis matrix Use `cheb_polys` to construct the basis matrix ```julia # Chebyshev polynomial function function cheb_polys(x, n) if n == 0 return 1 # T_0(x) = 1 elseif n == 1 return x # T_1(x) = x else cheb_recursion(x, n) = 2x.*cheb_polys.(x, n - 1) .- cheb_polys.(x, n - 2) return cheb_recursion(x, n) # T_n(x) = 2xT_{n-1}(x) - T_{n-2}(x) end end; ``` --- # Step 4a: Pre-invert your basis matrix .hi-blue[Pro tip:] you will be using the *exact same* basis matrix in each loop iteration to recover the coefficients: just pre-invert it to save time because inverting the same matrix every loop is costly (especially when large) ```julia basis_matrix = [cheb_polys.(grid, n) for n = 0:params_ti.num_points - 1]; basis_matrix = hcat(basis_matrix...) ``` ``` ## 5×5 Array{Float64,2}: ## 1.0 0.951057 0.809017 0.587785 0.309017 ## 1.0 0.587785 -0.309017 -0.951057 -0.809017 ## 1.0 6.12323e-17 -1.0 -1.83697e-16 1.0 ## 1.0 -0.587785 -0.309017 0.951057 -0.809017 ## 1.0 -0.951057 0.809017 -0.587785 0.309017 ``` ```julia basis_inverse = basis_matrix\I ``` ``` ## 5×5 Array{Float64,2}: ## 0.2 0.2 0.2 0.2 0.2 ## 0.380423 0.235114 5.55112e-17 -0.235114 -0.380423 ## 0.323607 -0.123607 -0.4 -0.123607 0.323607 ## 0.235114 -0.380423 -8.32667e-17 0.380423 -0.235114 ## 0.123607 -0.323607 0.4 -0.323607 0.123607 ``` --- # Step 4b: Evaluate the policy function To loop and maximize the Bellman at each grid point we need a function `eval_policy_function(coefficients, capital, params_ti)` that lets us evaluate the continuation value given a vector of coefficients `coefficients`, a vector of capital nodes `capital`, and the parameters `params_ti` to scale capital back into `\([-1,1]\)` -- It needs to: 1. Scale capital back into `\([-1,1]\)` 2. Use the coefficients and Chebyshev polynomials to evaluate the value function --- # Step 4b: Evaluate the continuation value Here's a simple way to do it: -- ```julia shrink_grid(capital) = 2*(capital - params_ti.capital_lower)/(params_ti.capital_upper - params_ti.capital_lower) - 1; eval_policy_function(coefficients, capital, params_ti) = coefficients' * [cheb_polys.(shrink_grid(capital), n) for n = 0:params_ti.num_points - 1]; ``` The top function inherits `params_ti` from the bottom function --- # Step 5: Loop Construct a function that loops over the grid points and solves the Euler given `\(\Psi(x;b^{(p)})\)` ```julia function loop_grid_ti(params_ti, basis_inverse, basis_matrix, grid, capital_grid, coefficients) consumption = similar(coefficients) for (iteration, capital) in enumerate(capital_grid) function consumption_euler(consumption_guess) capital_next = capital^params_ti.alpha - consumption_guess # Next period consumption based on policy approximant consumption_next = eval_policy_function(coefficients, capital_next, params_ti) consumption_next = max(1e-10, consumption_next) # Organize Euler so it's g(c,k) = 0 euler_error = consumption_guess^(-params_ti.eta) / (params_ti.beta*consumption_next^(-params_ti.eta)*params_ti.alpha*(capital_next)^(params_ti.alpha - 1)) - 1 return euler_error end # Search over consumption such that Euler = 0 consumption[iteration] = fzero(consumption_euler, 0., capital) end return consumption end ``` ``` ## loop_grid_ti (generic function with 1 method) ``` --- # Step 5: Loop ```julia function solve_ti(params_ti, basis_inverse, basis_matrix, grid, capital_grid, coefficients) error = 1e10 iteration = 1 consumption = similar(coefficients) consumption_prev, coefficients_prev = similar(coefficients), similar(coefficients) coefficients_store = Vector{Vector}(undef, 1) coefficients_store[1] = coefficients while error > params_ti.tolerance consumption = loop_grid_ti(params_ti, basis_inverse, basis_matrix, grid, capital_grid, coefficients) if iteration > 1 coefficients = params_ti.damp*(basis_inverse*consumption) + (1 - params_ti.damp)*coefficients_prev else coefficients = basis_inverse*consumption end error = maximum(abs.((consumption - consumption_prev)./(consumption_prev))) consumption_prev, coefficients_prev = deepcopy(consumption), deepcopy(coefficients) if mod(iteration, 5) == 0 println("Maximum Error of $(error) on iteration $(iteration).") append!(coefficients_store, [coefficients]) end iteration += 1 end return coefficients, consumption, coefficients_store end ``` ``` ## solve_ti (generic function with 1 method) ``` --- # Step 5: Loop ```julia solution_coeffs, consumption, intermediate_coefficients = solve_ti(params_ti, basis_inverse, basis_matrix, grid, capital_grid, coefficients) ``` ``` ## Maximum Error of 0.06899533243252934 on iteration 5. ## Maximum Error of 1.481484067728511 on iteration 10. ## Maximum Error of 0.7160885861973345 on iteration 15. ## Maximum Error of 0.3030828724582769 on iteration 20. ## Maximum Error of 0.17473143140005473 on iteration 25. ## Maximum Error of 505.4805245124472 on iteration 30. ## Maximum Error of 1.193558398749873 on iteration 35. ## Maximum Error of 0.28476702156043676 on iteration 40. ## Maximum Error of 0.19536671877310902 on iteration 45. ## Maximum Error of 235825.18031971727 on iteration 50. ## Maximum Error of 1.4632905297050023 on iteration 55. ## Maximum Error of 0.3819128797728578 on iteration 60. ## Maximum Error of 0.2069777248265044 on iteration 65. ## Maximum Error of 0.2882977765088428 on iteration 70. ## Maximum Error of 1.5557188732619867 on iteration 75. ## Maximum Error of 0.20172230910005298 on iteration 80. ## Maximum Error of 0.06127838612896111 on iteration 85. ## Maximum Error of 0.028153777682640414 on iteration 90. ## Maximum Error of 0.014466543089840038 on iteration 95. ## Maximum Error of 0.006878960963739522 on iteration 100. ## Maximum Error of 0.003130222595497513 on iteration 105. ## Maximum Error of 0.001391461005386054 on iteration 110. ## Maximum Error of 0.0006111544900213002 on iteration 115. ## Maximum Error of 0.00026681831311659726 on iteration 120. ## Maximum Error of 0.00011614043376537828 on iteration 125. ## Maximum Error of 5.047881962395737e-5 on iteration 130. ## Maximum Error of 2.1923791129685817e-5 on iteration 135. ## Maximum Error of 9.518360650356241e-6 on iteration 140. ``` ``` ## ([0.10216025688175603, 0.030492240762756, -0.0018614730785602319, 0.0002412050526698486, -3.673940758425717e-5], [0.12978513558181665, 0.120459207876453, 0.10398539694181286, 0.08507201135884981, 0.07150154187804965], Array{T,1} where T[[0.0, 0.0, 0.0, 0.0, 0.0], [1.276313022082098e-10, 7.183782173526791e-12, -5.1738097180129495e-12, -2.5864997905351185e-13, -8.831154896937806e-14], [5.317142136502967e-10, 5.527847639739073e-10, 1.6703531496499355e-10, 1.8141242726804023e-11, -1.4478161076640903e-13], [8.316966371969167e-9, 5.18753915343869e-9, 2.0308553662549534e-10, -1.1491350952729583e-11, 1.7095210124630882e-12], [3.386275145017677e-8, 1.2764005373987535e-8, -3.0912462874207683e-10, 4.0250155043961724e-11, -1.1414759632199032e-11], [7.52422466539421e-8, 1.057016474990513e-8, -4.436603667835434e-9, -1.1744349926279e-10, -4.947772660433226e-11], [3.5814952980292754e-8, -1.4472521472050847e-8, 1.8347071102204086e-8, 5.2283868000856916e-9, -1.5042279183557698e-10], [8.649173370341168e-7, 6.23976511971795e-7, 2.580472512479873e-8, -5.8530576443756555e-9, 3.6058883046539203e-10], [3.5573111138957096e-6, 1.2734335635389533e-6, -3.0722754197916816e-8, 1.0899793501970388e-8, -1.292670762307699e-9], [8.394998791841883e-6, 1.5754988650395768e-6, -4.3452939029739223e-7, -2.0464224738503144e-8, -5.013974305135995e-9] … [0.0937722121997489, 0.027049729315754424, -0.0017387008487714786, 0.00022715074679682435, -3.8481841856618996e-5], [0.09828586835137634, 0.028819431842777576, -0.0018084381167883102, 0.0002370462002013028, -3.7730003683528356e-5], [0.10043008020063873, 0.029723588228166724, -0.0018394468427340885, 0.00023995653980080382, -3.7218854408817556e-5], [0.10140171061061844, 0.030149857542289698, -0.001852360245859877, 0.00024079574250233525, -3.6957483395931e-5], [0.10183187323362813, 0.030342720870865328, -0.0018576775097620402, 0.00024105811168629785, -3.683563041501696e-5], [0.1020202511316293, 0.0304281893808404, -0.0018598919520605756, 0.0002411489742540459, -3.678086910692431e-5], [0.10210233687095274, 0.03046567454426408, -0.0018608274951932573, 0.00024118324939464226, -3.6756664109979044e-5], [0.10213802583793859, 0.030482029928345013, -0.0018612270529681154, 0.0002411969602829308, -3.674605381205512e-5], [0.10215352705674494, 0.03048914745670296, -0.0018613988826236723, 0.00024120264584137242, -3.674142338781434e-5], [0.10216025688175603, 0.030492240762756, -0.0018614730785602319, 0.0002412050526698486, -3.673940758425717e-5]]) ``` --- # Now lets plot our solutions ```julia capital_levels = range(params_ti.capital_lower, params_ti.capital_upper, length = 100); eval_points = shrink_grid.(capital_levels); solution = similar(intermediate_coefficients); for (iteration, coeffs) in enumerate(intermediate_coefficients) solution[iteration] = [coeffs' * [cheb_polys.(capital, n) for n = 0:params_ti.num_points - 1] for capital in eval_points]; end ``` --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-61-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-62-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-63-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-64-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-65-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-66-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-67-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-68-J1.png" width="800" /> --- # Plot the consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-69-J1.png" width="800" /> --- # Plot the final consumption policy function <img src="7_solution_methods_files/figure-html/unnamed-chunk-70-J1.png" width="800" /> --- # Now lets try simulating ```julia function simulate_model(params_ti, solution_coeffs, time_horizon = 100) capital_store = zeros(time_horizon + 1) consumption_store = zeros(time_horizon) capital_store[1] = params_ti.k_0 for t = 1:time_horizon capital = capital_store[t] consumption_store[t] = eval_policy_function(solution_coeffs, capital, params_ti) capital_store[t+1] = capital^params_ti.alpha - consumption_store[t] end return consumption_store, capital_store end; ``` --- # Now lets try simulating ```julia time_horizon = 100; consumption, capital = simulate_model(params_ti, solution_coeffs, time_horizon); plot(1:time_horizon, consumption, color = :red, linewidth = 4.0, tickfontsize = 14, guidefontsize = 14, label = "Consumption", legend = :right, grid = false, size = (500, 300)); plot!(1:time_horizon, capital[1:end-1], color = :blue, linewidth = 4.0, linestyle = :dash, label = "Capital"); plot!(1:time_horizon, params_ti.steady_state*ones(time_horizon), color = :purple, linewidth = 2.0, linestyle = :dot, label = "Steady State Capital") ``` <img src="7_solution_methods_files/figure-html/unnamed-chunk-72-J1.png" width="667" /> --- # A short overview of discretization + VFI When we use discretization methods we create a grid on our state space, typically evenly spaced -- This becomes our .hi-blue[actual] state space, not just collocation points -- How does it work? --- # A short overview of discretization + VFI The discretized state space implies a discretized control space -- If there are only a finite number of states tomorrow conditional on the current state, then there is only a finite number of valid controls -- This makes solving easy! -- Search over all possible controls today until you find the one that yields the highest value of the RHS of the Bellman: just requires looping and a max operator -- The maximized value is the new value of this discretized state -- 3 loops now: outer VFI loop, middle capital grid loop, inner consumption loop --- # Discretizing the state space ```julia using LinearAlgebra using Optim using Plots params_dis = (alpha = 0.75, beta = 0.95, eta = 2, steady_state = (0.75*0.95)^(1/(1 - 0.75)), k_0 = (0.75*0.95)^(1/(1 - 0.75))*.75, capital_upper = (0.75*0.95)^(1/(1 - 0.75))*1.5, capital_lower = (0.75*0.95)^(1/(1 - 0.75))/2, tolerance = 0.0001, max_iterations = 1000) ``` ``` ## (alpha = 0.75, beta = 0.95, eta = 2, steady_state = 0.25771486816406236, k_0 = 0.19328615112304676, capital_upper = 0.3865723022460935, capital_lower = 0.12885743408203118, tolerance = 0.0001, max_iterations = 1000) ``` --- # Discretizing the state space ```julia function iterate_value(grid, params) grid_size = size(grid, 1) V, V_prev = zeros(grid_size, 1), zeros(grid_size, 1) V_store = Array{Float64}(undef, grid_size, params.max_iterations) max_diff = 1e10 it = 1 while max_diff > params.tolerance && it <= params.max_iterations # iterate on the value function for (iteration, grid_point) in enumerate(grid) # iterate across the capital grid # possible consumption values (output + remaining capital - capital next period) c_vec = grid_point.^params.alpha .- grid value_max = -Inf # find consumption that maximizes the right hand side of the Bellman, search over ones with positive consumption for (it_inner, consumption) in enumerate(c_vec[c_vec .> 0]) # iterate across possible consumption values value_temp = consumption^(1 - params.eta)/(1 - params.eta) + params.beta*V[it_inner] value_max = max(value_temp, value_max) end V[iteration] = value_max end max_diff = maximum(abs.(V .- V_prev)) if mod(it,10) == 0 println("Current maximum value difference at iteration $it is $max_diff.") end V_prev = copy(V) V_store[:,it] = V if it == params.max_iterations println("Hit maximum iterations") break end it += 1 end V_store = V_store[:, 1:it-1] return V, V_store end ``` ``` ## iterate_value (generic function with 1 method) ``` --- # Discretizing the state space ```julia max_diff = maximum(abs.((V .- V_prev)./V_prev)) if mod(it,10) == 0 println("Current maximum value difference at iteration $it is $max_diff.") end V_prev = copy(V) V_store[:,it] = V if it == params.max_iterations println("Hit maximum iterations") break end it += 1 end V_store = V_store[:, 1:it-1] return V, V_store end ``` --- # Discretizing the state space ```julia grid_size = 3; grid = collect(range(params_dis.capital_lower, stop = params_dis.capital_upper, length = grid_size)) ``` ``` ## 3-element Array{Float64,1}: ## 0.12885743408203118 ## 0.25771486816406236 ## 0.3865723022460935 ``` ```julia value, v_store = @time iterate_value(grid, params_dis) ``` ``` ## Current maximum value difference at iteration 10 is 7.310316889342374. ## Current maximum value difference at iteration 20 is 4.376956759187493. ## Current maximum value difference at iteration 30 is 2.6206456931746516. ## Current maximum value difference at iteration 40 is 1.5690773811596443. ## Current maximum value difference at iteration 50 is 0.9394645886236788. ## Current maximum value difference at iteration 60 is 0.5624921523154001. ## Current maximum value difference at iteration 70 is 0.33678482962292833. ## Current maximum value difference at iteration 80 is 0.20164551807033604. ## Current maximum value difference at iteration 90 is 0.12073262030057208. ## Current maximum value difference at iteration 100 is 0.07228707954499214. ## Current maximum value difference at iteration 110 is 0.043280944753263384. ## Current maximum value difference at iteration 120 is 0.0259139003889004. ## Current maximum value difference at iteration 130 is 0.015515609402569908. ## Current maximum value difference at iteration 140 is 0.009289768484109118. ## Current maximum value difference at iteration 150 is 0.005562127548415674. ## Current maximum value difference at iteration 160 is 0.0033302512239856696. ## Current maximum value difference at iteration 170 is 0.0019939444247540905. ## Current maximum value difference at iteration 180 is 0.0011938481818845048. ## Current maximum value difference at iteration 190 is 0.0007148010063247057. ## Current maximum value difference at iteration 200 is 0.00042797776669090126. ## Current maximum value difference at iteration 210 is 0.0002562460981039294. ## Current maximum value difference at iteration 220 is 0.00015342400445206295. ## 0.150962 seconds (455.00 k allocations: 25.278 MiB, 6.89% gc time) ``` ``` ## ([-231.9798759489783; -192.32427374317618; -187.00837177812517], [-11.599085658067757 -22.618217033232128 … -231.97977925359004 -231.9798759489783; -9.616289844742465 -18.751765197247806 … -192.32419357729867 -192.32427374317618; -9.644703799156582 -18.807172408355335 … -187.00829562054153 -187.00837177812517]) ``` --- # The value function: every 20 iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-77-J1.png" width="800" /> --- # The value function: final <img src="7_solution_methods_files/figure-html/unnamed-chunk-78-J1.png" width="800" /> --- # Discretizing the state space ```julia grid_size = 100; grid = collect(range(params_dis.capital_lower, stop = params_dis.capital_upper, length = grid_size)); value, v_store = @time iterate_value(grid, params_dis) ``` ``` ## Current maximum value difference at iteration 10 is 6.914720355073825. ## Current maximum value difference at iteration 20 is 3.8092197025250414. ## Current maximum value difference at iteration 30 is 2.221007019891772. ## Current maximum value difference at iteration 40 is 1.3164056274758593. ## Current maximum value difference at iteration 50 is 0.7840556792955624. ## Current maximum value difference at iteration 60 is 0.4679885486935973. ## Current maximum value difference at iteration 70 is 0.27994507576624983. ## Current maximum value difference at iteration 80 is 0.16751908240780722. ## Current maximum value difference at iteration 90 is 0.1002998626648548. ## Current maximum value difference at iteration 100 is 0.05997003214901042. ## Current maximum value difference at iteration 110 is 0.03590627349490205. ## Current maximum value difference at iteration 120 is 0.0214984122918338. ## Current maximum value difference at iteration 130 is 0.01287189357412899. ## Current maximum value difference at iteration 140 is 0.007706878160803399. ## Current maximum value difference at iteration 150 is 0.004614392641116183. ## Current maximum value difference at iteration 160 is 0.0027628073264054365. ## Current maximum value difference at iteration 170 is 0.0016541948023416353. ## Current maximum value difference at iteration 180 is 0.0009904275328835865. ## Current maximum value difference at iteration 190 is 0.0005930055496037312. ## Current maximum value difference at iteration 200 is 0.00035505432774129986. ## Current maximum value difference at iteration 210 is 0.00021258414147951044. ## Current maximum value difference at iteration 220 is 0.0001272819782229817. ## 0.151063 seconds (159.38 k allocations: 132.604 MiB, 19.39% gc time) ``` ``` ## ([-212.42908333245703; -211.7639543138398; … ; -183.072370381581; -182.92812836469787], [-11.599085658067757 -22.618217033232128 … -212.42898484408866 -212.42908333245703; -11.512646026583107 -22.44965975183706 … -211.76385582547144 -211.7639543138398; … ; -9.63308569160569 -18.784517098631092 … -183.07232481286312 -183.072370381581; -9.644703799156582 -18.807172408355335 … -182.92808279597998 -182.92812836469787]) ``` --- # The value function: every 20 iterations <img src="7_solution_methods_files/figure-html/unnamed-chunk-80-J1.png" width="800" /> --- # The value function: final <img src="7_solution_methods_files/figure-html/unnamed-chunk-81-J1.png" width="800" />
