Creative Programming: Interaction

Lecture 4 (17 Feb)

Table of contents

• (Re)visiting slides?
• Course improvements
• Angle recap
  • Push & Pop
  • Straight angles
  • Translate
  • Rotate
  • For-loop
  • Flower!
• The World of Functions
  • Shape functions
  • Vertices
  • Extra: Round vertices
  • Repeatedly drawing shapes
  • Functions
  • Function syntax
  • Function calling
  • Function return
  • Custom function
  • Flowers and functions
  • Flower forest
• Mouse
  • What we have seen so far
  • Events
  • Mouse events
  • Programming with mouse events
  • Mouse event parameters
  • Easing
  • Easing example
  • Extra: Mouse state outside of events
  • Mousing around
• Keyboard
  • Keyboard events
  • Key and keyCode
  • Key example
  • A useful snippet
  • Programming with keyboard events
  • Extra: Key state outside of events
  • Key controls
  • Alphabet

The first slide of every lecture introduces what we can make with the things we learn this week! This slideshow we will iteratively build up to a bouncing ball sketch that uses variables, conditions, loops, and arrays.

(Re)visiting slides?

This is where you can find the narration notes. Some slides don’t have any notes (especially this first week) as notes are typically reserved for slides that explain technical concepts.

You can jump to any slide with the menu to the (bottom) left.

Did you miss a slide or want to revisit? Open the narration tab while studying to get an explanation of difficult slides.

Course improvements

• Thank you for your feedback!
• We have had the fundamentals so we will have more time on practicing in class
• There is now a coding reference on GitHub with details on what we have covered so far

Angle recap

Push & Pop

Push and pop are used to save and restore the current drawing state, which includes transformations like translation and rotation, as well as styles like fill and stroke. This allows us to make temporary changes to the drawing state without affecting the rest of our sketch.

• Properties like fill() and stroke() affects all subsequent shapes
• push() and pop() allow us to save and restore the current drawing state
• Any changes you make between push() and pop() will not affect the drawing state outside of that block

Straight angles

We have already seen this last lecture, but there was not enough time to go into detail. We will now look at how to draw angled rectangles, which we need for our flower sketch.

• If we just use rect(), we can only get rectangles on straight angles
• Without angled rectangles our flower sketch would look like this:

Translate

It is most common to push and to translate to a nice location before drawing, and using pop to reset the origin after drawing. This way we can draw multiple shapes on different locations without worrying about the transformations affecting each other.

• In order to rotate we need to set the origin using translate()
• translate(x, y) moves the origin to the specified (x, y) position
• For a flower we would for example want to move the origin to the center

Rotate

Rotating without translating first would rotate the entire coordinate system around the top left corner, which is usually not what we want. By translating first, we can rotate around a specific point, such as the center of our flower.

• With our new origin we can now rotate our shapes using rotate()
• rotate(angle) rotates the coordinate system by the specified angle
• Make sure to use angleMode(DEGREES) first if you want to use degrees

For-loop

We will keep repeating for-loops whenever possible. Whenever you find yourself in need of repeating code, think about how you can use a for-loop to automate the repetition. This will save you a lot of time and make your code cleaner and more efficient.

• We can automate the drawing of multiple petals using a for-loop
• By rotating the coordinate system by a fixed angle in each iteration, we can create a circular pattern of petals

Flower!

Feel free to use the previous sketches as a starting point for your flower sketch. You can experiment with different numbers of petals, sizes, and colours to create your own unique flower design.

Class Assignment: Flower!

1. Create a flower sketch using translate(), rotate(), and a for-loop to draw multiple petals
2. Can you make it so that you can quickly change the location (x,y) and number of petals?
3. Can you make the petals spin using frameCount?

The World of Functions

Shape functions

• rect() and ellipse() are examples of functions that draw shapes on the canvas
• What if we want to repeatedly draw a custom shape?

Vertices

Vertices are nice but can be confusing. Make sure to start and end your shape with beginShape() and endShape(CLOSE), and to define every vertex with vertex(x, y). If you forget to do this, you might end up with unexpected results or errors in your code.

• We can define custom shapes with vertices
• Start and end your shape with beginShape() and endShape(CLOSE)
• Define every vertex with vertex(x, y)

Extra: Round vertices

This is an extra slide that was not covered in class, but a student asked about it in class. The bezierCurve function is quite tricky to use, but it can create some really nice curves if you get the hang of it. It is definitely worth experimenting with if you want to add some extra flair to your shapes.

• We can also round the corners of our shapes via bezierVertex()
• This function takes two control points and an anchor point, which defines a curve between the previous vertex and the anchor point
• bezierVertex(x1, y1, x2, y2, x3, y3) where (x1, y1) and (x2, y2) are the control points and (x3, y3) is the final destination anchor point

Repeatedly drawing shapes

• Vertex definitions take up a lot of space
• If we want to draw multiple shapes, we clutter the code quickly
• Solution: functions

Functions

Functions are one of the last big “fundamentals” that we will cover. They are essential for writing clean and efficient code, and they allow us to break down complex problems into smaller, more manageable pieces. By using functions, we can reuse code and avoid repetition, which makes our programs easier to read and maintain.

• Functions are reusable blocks of code that perform a specific task
• They allow us to organize our code and avoid repetition
• rect() and ellipse() are examples of built-in functions, but we can also create our own custom functions!

Function syntax

• Functions have a name and take a list of parameters(inputs):

function functionName(a, b, c){
  // code to be executed
}

• In this above example, (a, b, c) are the parameters of the function. These are essentially variables for within the function’s scope

Function calling

• We can now call the function like this:

functionName(1, 2, 3);

• In this case, we are passing the values 1, 2, and 3 as arguments to the function, which will be assigned to the parameters a, b, and c respectively when the function is executed

Function return

• Functions can also return a value using the return keyword
• This allows us to use the output of a function in other parts of our code

function add(a, b){
  return a + b;
}

• This example adds two numbers and returns the result. We can use this function like this:

let sum = add(5, 10);
console.log(sum); // Output: 15

Custom function

• Going back to our vertex example, we can move this code to a function
• If we use parameters, we can reuse the function to draw multiple shapes on different locations

Flowers and functions

• We can now use our custom function to draw multiple flowers on the canvas
• Move the flower drawing code to a function and use parameters to specify the location and number of petals

Flower forest

For the starting slide I’ve also added colour and rotation.

Class Assignment: Flower forest

1. Move flower code from the previous assignment to a function
2. Make it so that you can specify the location and number of petals as parameters
3. Use this function to draw a flower forest with multiple flowers on the canvas
4. Can you add more parameters? For example, can you specify the size of the flower or the colours?

Mouse

What we have seen so far

• We have used mouseX and mouseY to make our sketches interactive
• We also used pmouseX and pmouseY to get the previous mouse position
• Can we do more with the mouse?

Events

• setup() is a built-in function that happens when the program starts
• Some built-in functions are called automatically when certain events happen
• For example, mousePressed() is called whenever the mouse is pressed
• We can define our own mousePressed() function to specify what should happen when the mouse is pressed

Mouse events

• mousePressed(): called when the mouse button is pressed
• mouseReleased(): called when the mouse button is released
• mouseClicked(): called when the mouse button is clicked
• mouseMoved(): called when the mouse is moved
• mouseDragged(): called when the mouse is dragged (moved while down)
• mouseWheel(): called when the mouse wheel is scrolled.
  • End with return false; to prevent page scrolling

Programming with mouse events

• Let us look at some of these events in action

Mouse event parameters

• Some mouse events also have parameters that provide additional information about the event
• For example, the mouseWheel() event has an optional event parameter that contains information about the scroll amount and direction
  • The speed and direction of the scroll can be accessed with event.delta
• Check out the (p5.js) reference for more details on mouse events and their parameters

Easing

Should be noted that you can use this for any number, not just positions. For example, you could use easing to smoothly change the size of an object or the colour over time.

• Easing is a technique used to create smooth animations by gradually changing a value over time
• Instead of instantly changing a value to a new target, we can “ease” towards the new one

let currentValue = 0;
function draw() {
  let targetValue = 100; // The value we want to reach
  currentValue = 0.9 * currentValue + 0.1 * targetValue; // Easing towards the target value
}

• Here we replace 10% of the location with the target location in each frame, which creates a smooth transition towards the target.

Easing example

In this example we ease a circle towards the mouse position. The circle will smoothly follow the mouse around the canvas.

Extra: Mouse state outside of events

This slide was not covered in class, but it is a useful function to know about if you want to check the state of the mouse outside of the event functions.

• If you want to check the state of the mouse outside of the event functions, you can use the mouseIsPressed variable
• This variable is true if the mouse is currently being pressed, and false otherwise
• mouseButton contains the value of the mouse button that is currently being pressed (LEFT, RIGHT, or CENTER)

function draw() {
  if (mouseIsPressed) {
    console.log(mouseButton); // Output: LEFT, RIGHT, or CENTER depending on which button is pressed
  }
}

Mousing around

One nice idea is to try to make it so that you have to click on a specific rectangle.

Class Assignment: Mousing around

1. Create an interactive sketch, or modify a previous one, with two different mouse events
2. Experiment with the parameters of the mouse events to create interesting interactions
3. Can you make the mouse wheel change the size of things in your sketch?

Keyboard

Keyboard events

• Similar to mouse events, there are also keyboard events that we can use to make our sketches interactive
• keyPressed(): called when a key is pressed
• keyReleased(): called when a key is released
• keyTyped(): called when a key is typed (pressed and released)
• These events update key and keyCode, two variables that contain information about the key that was pressed
• Check out the (p5.js) reference for more details on keyboard events and their parameters

Key and keyCode

• key contains the value of the key that was pressed as a string. For example, if you press the ‘a’ key, key will be ‘a’
• keyCode contains the numeric code of the key that was pressed. For example, the ‘a’ key has a keyCode of 65
  • Some keys have variables that hold their keycodes, such as SPACE, ENTER, and LEFT_ARROW.

Key example

• In the snippet below we check whether the ‘a’ key, space bar, or left arrow key is pressed and do something in each case

function keyPressed() {
  if (key == 'a') {
    // Do something when the 'a' key is pressed
  } else if (keyCode == 32) { // We could have also used SPACE instead of 32
    // Do something when the space bar (keyCode 32) is pressed
  } else if (keyCode == LEFT_ARROW) {
    // Do something when the left arrow key is pressed
  }
}

A useful snippet

This is a really useful piece of code that you can use for debugging purposes. In class we will also run this code in Processing and see how to debug pieces of code with logging.

• We prefer using key for letter keys and keyCode for special keys
• With a small tool, though, we can find the keycode for any key

Programming with keyboard events

• Let us look at some of these events in action

Extra: Key state outside of events

This slide was not covered in class, but it is a useful function to know about if you want to check the state of the keyboard outside of the event functions.

• If you want to check the state of the keyboard outside of the event functions, you can use the keyIsDown() function
• This function takes a key code as an argument and returns true if that key is currently being pressed, and false otherwise

function draw() {
  if (keyIsDown(LEFT_ARROW)) {
    // Do something while the left arrow key is being pressed
  }
}

Key controls

Very common for games and other interactive sketches that need control of a character.

• One of the most common uses of keyboard input is to control an object
• In this example, we can move the ball with the arrow keys

Alphabet

Class Assignment: Alphabet

1. Create a sketch that responds to keyboard input by displaying the key variable on the canvas
2. Make an array with the letters of the alphabet (or another word). Make it so the user has to type the letters in the correct order.
3. Can you make it so that the user has to type the letters in reverse order? Or in a random order?
