path_glodapv2_2021  <- "/nfs/kryo/work/updata/glodapv2_2021/"
path_glodapv2_CRM  <- "/nfs/kryo/work/updata/glodapv2_CRM/"
path_crossover <- "/nfs/kryo/work/updata/glodapv2_crossover"

path_preprocessing  <- paste(path_root, "/observations/preprocessing/", sep = "")

1 Read files

1.1 Adjusted data

Main data source for this project is GLODAPv2.2021_Merged_Master_File.csv downloaded from https://www.ncei.noaa.gov/data/oceans/ncei/ocads/data/0237935/GLODAPv2.2021_Merged_Master_File.csv on Aug 30, 2021.

GLODAP <-
  read_csv(
    paste(
      path_glodapv2_2021,
      "GLODAPv2.2021_Merged_Master_File_20210830.csv",
      sep = ""
    ),
    na = "-9999",
    col_types = cols(.default = col_double())
  )


GLODAP <- GLODAP %>%
  rename_with(~str_remove(., 'G2'))

1.2 Adjustment table

GLODAP_adjustments <-
  read_csv(
    paste(
      path_glodapv2_2021,
      "GLODAPv2.2021_adjustments_last_updated_on_2021_05_10.csv",
      sep = ""
    ),
    na = c("-666", "-777", "-888", "-999"),
    skip = 2
  )

1.3 Expocodes

GLODAP_expocodes <-
  read_tsv(
    paste(
      path_glodapv2_2021,
      "EXPOCODES.txt",
      sep = ""
    ),
    col_names = c("cruise", "cruise_expocode")
  )

1.4 Crossover tables

# tables from glodapv2, provided by Steven van Heuven

glodapv2_xover_files <- fs::dir_ls(paste0(path_crossover, "/glodapv2"))

glodapv2_xover <- glodapv2_xover_files %>%
  map_dfr(read_csv, .id = "parameter")

glodapv2_xover <- glodapv2_xover %>%
  mutate(parameter = str_remove(parameter, ".csv"),
         parameter = str_sub(parameter, -3))


glodapv2_xover <- glodapv2_xover %>%
  mutate(parameter = recode(parameter,
                            "ALK" = "talk",
                            "DIC" = "tco2",
                            "NO3" = "nitrate",
                            "_O2" = "oxygen",
                            "PO4" = "phosphate",
                            "SAL" = "salinity",
                            "SIL" = "silicate"))

# Note: In the files provided by Steven von Heuven
# the column names sigma_ratio and sigma_offset_sd were swapped

glodapv2_xover_absolute <- glodapv2_xover %>%
  filter(parameter %in% c("salinity", "talk", "tco2")) %>%
  select(parameter,
         offset = sigma_offset,
         offset_sd = sigma_ratio,
         cruise_A = CruiseA_EXPOCODE,
         cruise_B = CruiseB_EXPOCODE)

glodapv2_xover_ratio <- glodapv2_xover %>%
  filter(!(parameter %in% c("salinity", "talk", "tco2"))) %>%
  select(parameter,
         offset = sigma_offset_sd,
         offset_sd = sigma_ratio_sd,
         cruise_A = CruiseA_EXPOCODE,
         cruise_B = CruiseB_EXPOCODE)

glodapv2_xover <- bind_rows(
  glodapv2_xover_absolute,
  glodapv2_xover_ratio
)


rm(glodapv2_xover_files, glodapv2_2021_xover_files,
   glodapv2_xover_absolute, glodapv2_xover_ratio)

# tables created between glodapv2 and glodapv2.2021
# provided by Nico Lange

glodapv2_2021_xover_files <- fs::dir_ls(paste0(path_crossover, "/glodapv2_2021"))

glodapv2_2021_xover <- glodapv2_2021_xover_files %>%
  map_dfr(readxl::read_excel)

glodapv2_2021_xover <- glodapv2_2021_xover %>%
  rename(parameter = Parameter) %>%
  mutate(parameter = recode(parameter,
                            "alkalinity" = "talk")) %>%
  filter(
    parameter %in%
      c(
        "tco2",
        "nitrate",
        "oxygen",
        "phosphate",
        "salinity",
        "silicate",
        "talk"
      )
  )


glodapv2_2021_xover <- glodapv2_2021_xover %>%
  rename(offset = Offset,
         offset_sd = Std,
         cruise_A = Cruise_A,
         cruise_B = Cruise_B)


# tables for data not qc'ed in the regular GLODAP release
# provided by Nico Lange

glodapv2_2021_xover_files_add <-
  fs::dir_ls(paste0(path_crossover, "/glodapv2_2021_additional_crossover"))

glodapv2_2021_xover_add <- glodapv2_2021_xover_files_add %>%
  map_dfr(readxl::read_excel)

glodapv2_2021_xover_add <- glodapv2_2021_xover_add %>%
  rename(parameter = Parameter) %>%
  mutate(parameter = recode(parameter,
                            "alkalinity" = "talk"))


glodapv2_2021_xover_add <- glodapv2_2021_xover_add %>%
  rename(offset = Offset,
         offset_sd = Std,
         cruise_A = Cruise_A,
         cruise_B = Cruise_B)

1.5 Missing/flagged cruises

GLODAP_cruises_missing <-
  read_csv(
    paste(
      path_glodapv2_2021,
      "GLODAPv2.2021_major_cruises_missing_flagged.csv",
      sep = ""
    )
  )

1.6 IO CRM data

IO_CRM_meas <-
  read_csv(
    paste(
      path_glodapv2_CRM,
      "/Millero_1998_Tab2.csv",
      sep = ""
    )
  )

CRM_ref <-
  read_csv(
    paste(
      path_glodapv2_CRM,
      "/Dickson_CRM_reference_values_20211215.csv",
      sep = ""
    )
  )

2 Data preparation

2.1 Correct qc flag

From an email conversation with Nico Lange

Yes, we are aware of these faulty(!) calculated TA data (using DIC and fCO2). It is linked to v2.2020 where we’ve added fCO2 to the “missing carbon calculation matrix”. Overall, including fCO2 in these calculations has worked great to fill some missing carbon gaps. However, for this cruise in particular the fCO2 values have most likely been converted wrongly to 20°C and are thus off! The problem of this all is that we haven’t really done a 2nd QC on the fCO2 values neither have we defined the corresponding “G2fCO2qc” variable, hence for the sake of consistency we kept all fCO2 values in. Again and unfortunately, in this particular case it led to the bad calculations of TA data…. We plan to do a full 2nd QC on all (!) fCO2 data for v3.

But you have indeed found a flaw in our merging script, as the corresponding calculated TA values should not have received a 2nd QC flag of 1! I missed out on adding a line to our merging script to accommodate for the non-existence of 2nd fCO2 flags in the carbon calculation matrix.

So long story short: Thank you very much for finding this flaw and letting me know of it!

and

Yes, the all calculated TA data from cruise 695 should have a talkqc of 0 (as they are based upon un QC’d fCO2 data…).

And no (thanks to your hint and questions), I figured that this wrongly assigned 2nd QC flag is a problem for all calculated carbon data, which used fCO2 for the calculations. However, luckily this is not really often the case.

You can check if thats the case by looking at which other carbon parameters are measured, i.e. by checking their primary flags (e.g. G2talkf, G2tco2f and G2phts25p0f and G2fco2f). If only two are measured and one of them is fCO2, it means that the other carbon parameters (the ones with a primary flag of 0) are calculated using fCO2. Hence, for these instances no 2nd QC is done and the corresponding qc flag should be 0 and not 1.

GLODAP_qc_check <- GLODAP %>%
  filter(cruise == 717) %>%
  count(talkqc)

# calculate number of measured co2 system variables

GLODAP <- GLODAP %>%
  mutate(measured_CO2_vars = rowSums(select(., c(
    tco2f, talkf, fco2f, phts25p0f
  )) == 2))

# identify cruises on which talk/tco2 was calculated

talk_qc_error_cruises <- GLODAP %>%
  select(cruise, tco2:phtsqc, measured_CO2_vars) %>%
  filter(measured_CO2_vars == 2,
         fco2f == 2,
         talkf == 0) %>%
  distinct(cruise, talkf, talkqc, fco2f)

tco2_qc_error_cruises <- GLODAP %>%
  select(cruise, tco2:phtsqc, measured_CO2_vars) %>%
  filter(measured_CO2_vars == 2,
         fco2f == 2,
         tco2f == 0) %>%
  distinct(cruise, tco2f, tco2qc, fco2f)

talk_qc_error_cruises %>%
  write_csv("data/talk_qc_error_cruises_GLODAPv2_2021.csv")

tco2_qc_error_cruises %>%
  write_csv("data/tco2_qc_error_cruises_GLODAPv2_2021.csv")

rm(talk_qc_error_cruises, tco2_qc_error_cruises)


# set qc = 0 for tco2 and talk values calculated from fco2

GLODAP <- GLODAP %>%
  mutate(tco2qc = if_else(measured_CO2_vars == 2 &
                            fco2f == 2 & tco2f == 0,
                          0,
                          tco2qc))

GLODAP <- GLODAP %>%
  mutate(talkqc = if_else(measured_CO2_vars == 2 &
                            fco2f == 2 & talkf == 0,
                          0,
                          talkqc))

GLODAP <- GLODAP %>%
  select(-measured_CO2_vars)

# calculate number of measured co2 system variables

GLODAP <- GLODAP %>%
  mutate(measured_CO2_vars = rowSums(select(., c(
    tco2f, talkf, fco2f, phts25p0f
  )) == 2))

# identify cruises on which talk/tco2 was calculated

tco2_talk_calc <- GLODAP %>%
  select(cruise, tco2:phtsqc, measured_CO2_vars) %>%
  filter(measured_CO2_vars == 2,
         fco2f == 2,
         phts25p0f == 2)

GLODAP <- GLODAP %>%
  select(-measured_CO2_vars)

2.2 Harmonize nomenclature

# create date column
GLODAP <- GLODAP %>%
  mutate(date = ymd(paste(year, month, day))) %>%
  relocate(date)

# harmonize column names
GLODAP <- GLODAP  %>%
  rename(sal = salinity,
         temp = temperature)

# harmonize coordinates
GLODAP <- GLODAP  %>%
  rename(lon = longitude,
         lat = latitude) %>%
  mutate(lon = if_else(lon < 20, lon + 360, lon))

2.3 Horizontal gridding

For merging with other data sets, all observations were grouped into latitude intervals of:

• 1° x 1°

GLODAP <- m_grid_horizontal(GLODAP)

2.4 Apply basin mask

# use only three basin to assign general basin mask
# ie this is not specific to the MLR fitting
basinmask_5 <- basinmask %>%
  filter(MLR_basins == "5") %>%
  select(lat, lon, basin)

basinmask <- basinmask %>%
  filter(MLR_basins == "2") %>%
  select(lat, lon, basin_AIP)

GLODAP <- inner_join(GLODAP, basinmask)

2.5 Add row number

GLODAP <- GLODAP  %>%
  mutate(row_number = row_number()) %>%
  relocate(row_number)

2.6 Split CO2 and tracers

# remove irrelevant columns
GLODAP <- GLODAP %>%
  select(-c(region,
            month:minute,
            maxsampdepth, sigma0:sigma4,
            nitrite:nitritef))


GLODAP_tracer <- GLODAP %>%
  select(row_number:gamma,
         cfc11:sf6f,
         basin_AIP)

# select relevant columns
GLODAP <- GLODAP %>%
  select(row_number:talkqc,
         basin_AIP)

2.7 Subset measured data

2.7.1 tco2

The vast majority of rows is removed due to missing tco2 observations.

GLODAP <- GLODAP %>%
  filter(!is.na(tco2))

2.7.2 tracer

Rows are removed if no tracer observation is available.

GLODAP_tracer <- GLODAP_tracer %>%
  filter(if_any(
    c(
      cfc11,
      cfc12,
      cfc113,
      ccl4,
      sf6,
      pcfc11,
      pcfc12,
      pcfc113,
      pccl4,
      psf6
    ),
    ~ !is.na(.)
  ))

2.8 Create clean observations grid

2.8.1 tco2

GLODAP_obs_grid <- GLODAP %>%
  count(lat, lon)

GLODAP_grid_year <- GLODAP %>%
  count(lat, lon, year)

map +
  geom_raster(data = GLODAP_grid_year,
              aes(lon, lat)) +
  facet_wrap(~ year, ncol=3)

Past versions of grid_by_year-1.png

Version	Author	Date
dc8d958	jens-daniel-mueller	2021-10-20

2.8.2 tracer

GLODAP_obs_grid_tracer <- GLODAP_tracer %>%
  count(lat, lon)

GLODAP_grid_year_tracer <- GLODAP_tracer %>%
  count(lat, lon, year)

map +
  geom_raster(data = GLODAP_grid_year_tracer,
              aes(lon, lat)) +
  facet_wrap(~ year, ncol=3)

Past versions of grid_by_year_tracer-1.png

Version	Author	Date
2a50fa9	jens-daniel-mueller	2021-10-28

3 Flagging

3.1 qc

qc_flag <- full_join(
  GLODAP,
  GLODAP_expocodes
)

qc_flag <- qc_flag %>%
  mutate(decade = cut(
    year,
    seq(1990, 2020, 10),
    right = FALSE,
    labels = c("1990-1999", "2000-2009", "2010-2019")
  ),
  .after = year) %>%
  filter(!is.na(decade)) %>%
  select(lon, lat, basin_AIP, decade, cruise_expocode, ends_with("qc")) %>%
  pivot_longer(ends_with("qc"),
               names_to = "parameter",
               values_to = "value")

qc_flag_grid <- qc_flag %>%
  count(lon, lat, decade, parameter, value)

p_qc_flag_map <- qc_flag_grid %>%
  group_split(value) %>%
  # head(1) %>%
  map(
    ~map +
  geom_tile(data = .x,
            aes(lon, lat, fill=n)) +
  facet_grid(parameter ~ decade) +
  labs(title = paste("qc flag =", unique(.x$value))) +
    scale_fill_viridis_c(option = "magma",
                         direction = -1,
                         trans = "log10")
  )

p_qc_flag_map

[[1]]

Past versions of qc_flagging-1.png

Version	Author	Date
daa43b9	jens-daniel-mueller	2021-12-06

[[2]]

Past versions of qc_flagging-2.png

Version	Author	Date
daa43b9	jens-daniel-mueller	2021-12-06

pdf("output/qc_flag_coverage_maps.pdf")
p_qc_flag_map

[[1]]

[[2]]

dev.off()

png
  2

qc_flag %>%
  filter(basin_AIP == "Pacific",
         decade == "1990-1999") %>%
  count(cruise_expocode, parameter, value) %>%
  arrange(value, -n) %>%
  write_csv("output/Pacific_1990_qc_by_cruise_and_parameter.csv")

rm(qc_flag, qc_flag_grid, p_qc_flag_map)

3.2 f

f_flag <- full_join(
  GLODAP,
  GLODAP_expocodes
)

f_flag <- f_flag %>%
  mutate(decade = cut(
    year,
    seq(1990, 2020, 10),
    right = FALSE,
    labels = c("1990-1999", "2000-2009", "2010-2019")
  ),
  .after = year) %>%
  filter(!is.na(decade)) %>%
  select(lon, lat, basin_AIP, decade, cruise_expocode, ends_with("f")) %>%
  pivot_longer(ends_with("f"),
               names_to = "parameter",
               values_to = "value")

f_flag_grid <- f_flag %>%
  count(lon, lat, decade, parameter, value)

p_f_flag_map <- f_flag_grid %>%
  group_split(value) %>%
  # head(1) %>%
  map(
    ~map +
  geom_tile(data = .x,
            aes(lon, lat, fill=n)) +
  facet_grid(parameter ~ decade) +
  labs(title = paste("f flag =", unique(.x$value))) +
    scale_fill_viridis_c(option = "magma",
                         direction = -1,
                         trans = "log10")
  )

p_f_flag_map

[[1]]

Past versions of f_flagging-1.png

Version	Author	Date
de20732	jens-daniel-mueller	2021-12-08

[[2]]

Past versions of f_flagging-2.png

Version	Author	Date
de20732	jens-daniel-mueller	2021-12-08

[[3]]

Past versions of f_flagging-3.png

Version	Author	Date
de20732	jens-daniel-mueller	2021-12-08

pdf("output/f_flag_coverage_maps.pdf")
p_f_flag_map

[[1]]

[[2]]

[[3]]

dev.off()

png
  2

f_flag %>%
  filter(basin_AIP == "Pacific",
         decade == "1990-1999") %>%
  count(cruise_expocode, parameter, value) %>%
  arrange(value, -n) %>%
  write_csv("output/Pacific_1990_f_by_cruise_and_parameter.csv")

rm(f_flag, f_flag_grid, p_f_flag_map)

4 Data loss

loss_all <- full_join(
  GLODAP,
  GLODAP_expocodes
)

loss_all <- loss_all %>%
  mutate(decade = cut(
    year,
    seq(1989, 2019, 10),
    right = FALSE,
    labels = c("1989-1999", "2000-2009", "2010-2019")
  ),
  .after = year) %>%
  filter(!is.na(decade))

map +
  geom_tile(data = loss_all %>% distinct(lon, lat, decade),
            aes(lon, lat)) +
  facet_grid(decade ~ .)

Past versions of data_loss_prepartion-1.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

loss <- loss_all %>%
  filter(if_all(ends_with("f"), ~ . != 9))

loss_all_n <- loss_all %>%
  count(basin_AIP, decade)

loss_n <- loss %>%
  count(basin_AIP, decade)

4.1 qc

loss_qc <- loss %>%
  select(lon, lat, basin_AIP, decade, cruise_expocode, ends_with("qc")) %>%
  pivot_longer(ends_with("qc"),
               names_to = "parameter",
               values_to = "value") %>%
  mutate(parameter = str_remove(parameter, "qc"))

loss_qc <- loss_qc %>%
  count(cruise_expocode, basin_AIP, decade, parameter, value) %>%
  pivot_wider(
    names_from = value,
    names_prefix = "qc_",
    values_from = n,
    values_fill = 0
  ) %>%
  mutate(n_cruise = qc_0 + qc_1,
         category = if_else(qc_0 <= 0.1 * (n_cruise), "OK", "loss"))

loss_qc_cruise <- loss_qc %>%
  mutate(parameter_class = if_else(
    parameter %in% c("tco2", "talk", "phosphate"),
    "target",
    "predictor"
  )) %>%
  count(cruise_expocode,
        basin_AIP,
        decade,
        n_cruise,
        parameter_class,
        category) %>%
  pivot_wider(names_from = category,
              values_from = n,
              values_fill = 0) %>%
  select(-OK) %>%
  pivot_wider(names_from = parameter_class,
              values_from = loss) %>%
  group_by(basin_AIP, decade) %>%
  mutate(rank_n_cruise = rank(-n_cruise)) %>%
  ungroup()

loss_qc_cruise <- full_join(loss_qc_cruise, loss_n)

loss_qc_cruise <- loss_qc_cruise %>%
  mutate(n_cruise_rel = 100 * n_cruise / n) %>%
  arrange(basin_AIP, decade, -n_cruise_rel) %>%
  group_by(basin_AIP, decade) %>%
  mutate(n_cruise_rel_cum = cumsum(n_cruise_rel)) %>%
  ungroup() %>%
  select(-n)

loss_qc_cruise <- loss_qc_cruise %>%
  pivot_longer(predictor:target,
               names_to = "parameter_class",
               values_to = "loss") %>%
  mutate(loss = as.factor(loss))

grey_plasma <- c("grey80", viridisLite::plasma(4))

loss_qc_cruise <- loss_qc_cruise %>%
  filter(n_cruise_rel >= 3)

loss_qc_cruise %>%
  group_split(basin_AIP) %>%
  # head(3) %>%
  map(
    ~ ggplot(data = .x,
             aes(rank_n_cruise, n_cruise_rel, fill = loss)) +
      geom_point(shape = 21, size = 2) +
      scale_fill_manual(values = grey_plasma,
                        name = "variables missing") +
      facet_grid(decade ~ parameter_class) +
      labs(title = paste("basin_AIP:", unique(.x$basin_AIP))) +
      ylim(0, NA)
  )

[[1]]

Past versions of qc_loss-1.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
be0850d	jens-daniel-mueller	2021-12-16
ce6cdae	jens-daniel-mueller	2021-12-15

[[2]]

Past versions of qc_loss-2.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
be0850d	jens-daniel-mueller	2021-12-16
ce6cdae	jens-daniel-mueller	2021-12-15

[[3]]

Past versions of qc_loss-3.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
be0850d	jens-daniel-mueller	2021-12-16
ce6cdae	jens-daniel-mueller	2021-12-15

loss_qc_cruise %>%
  filter(loss != 0) %>%
  select(basin_AIP, decade, parameter_class, rank_n_cruise, cruise_expocode) %>%
  arrange(basin_AIP, decade, parameter_class, rank_n_cruise) %>%
  kable() %>%
  kable_styling() %>%
  scroll_box(height = "300px")

basin_AIP	decade	parameter_class	rank_n_cruise	cruise_expocode
Atlantic	1989-1999	target	11	06MT19900123
Atlantic	1989-1999	target	12	33LK19960415
Atlantic	1989-1999	target	13	33MW19930704
Atlantic	2000-2009	predictor	7	35TH20010823
Atlantic	2000-2009	predictor	13	33RO20070710
Atlantic	2000-2009	target	7	35TH20010823
Atlantic	2000-2009	target	8	74DI20040404
Atlantic	2000-2009	target	9	35TH20080610
Atlantic	2000-2009	target	11	35TH20040604
Atlantic	2000-2009	target	12	35TH20020611
Atlantic	2010-2019	predictor	5	74EQ20151206
Indian	1989-1999	target	11	320619960503
Pacific	1989-1999	predictor	2	31DS19940126
Pacific	1989-1999	predictor	4	31DS19920907
Pacific	1989-1999	target	4	31DS19920907
Pacific	1989-1999	target	6	316N19930222
Pacific	1989-1999	target	7	316N19921006
Pacific	1989-1999	target	8	90KD19920214
Pacific	1989-1999	target	11	316N19921204

loss_grid <- loss %>% distinct(lon, lat, cruise_expocode)

loss_qc_grid <- left_join(loss_qc_cruise,
                          loss_grid)

map +
  geom_tile(data = loss_qc_grid,
            aes(lon, lat, fill = loss)) +
  facet_grid(decade ~ parameter_class) +
  scale_fill_manual(values = grey_plasma)

Past versions of qc_loss_maps-1.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
be0850d	jens-daniel-mueller	2021-12-16

loss_qc_grid %>% filter(loss != 0) %>%
  group_split(parameter_class, decade) %>%
  # head(1) %>%
  map(
    ~ map +
      geom_tile(data = .x,
                aes(lon, lat, fill = cruise_expocode)) +
      scale_fill_brewer(palette = "Paired") +
      facet_grid(decade ~ parameter_class)
  )

[[1]]

Past versions of qc_loss_maps-2.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[2]]

Past versions of qc_loss_maps-3.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[3]]

Past versions of qc_loss_maps-4.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[4]]

Past versions of qc_loss_maps-5.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[5]]

Past versions of qc_loss_maps-6.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

4.2 f

loss_f <- loss %>%
  select(lon, lat, basin_AIP, decade, cruise_expocode, ends_with("f")) %>%
  pivot_longer(ends_with("f"),
               names_to = "parameter",
               values_to = "value") %>%
  mutate(parameter = str_remove(parameter, "f"))

loss_f <- loss_f %>%
  count(cruise_expocode, basin_AIP, decade, parameter, value) %>%
  pivot_wider(
    names_from = value,
    names_prefix = "f_",
    values_from = n,
    values_fill = 0
  ) %>%
  mutate(n_cruise = f_0 + f_2,
         category = if_else(f_0 <= 0.1 * (n_cruise), "OK", "loss"))

loss_f_cruise <- loss_f %>%
  mutate(parameter_class = if_else(
    parameter %in% c("tco2", "talk", "phosphate"),
    "target",
    "predictor"
  )) %>%
  count(cruise_expocode,
        basin_AIP,
        decade,
        n_cruise,
        parameter_class,
        category) %>%
  pivot_wider(names_from = category,
              values_from = n,
              values_fill = 0) %>%
  select(-OK) %>%
  pivot_wider(names_from = parameter_class,
              values_from = loss) %>%
  group_by(basin_AIP, decade) %>%
  mutate(rank_n_cruise = rank(-n_cruise)) %>%
  ungroup()

loss_f_cruise <- full_join(loss_f_cruise, loss_n)

loss_f_cruise <- loss_f_cruise %>%
  mutate(n_cruise_rel = 100 * n_cruise / n) %>%
  arrange(basin_AIP, decade, -n_cruise_rel) %>%
  group_by(basin_AIP, decade) %>%
  mutate(n_cruise_rel_cum = cumsum(n_cruise_rel)) %>%
  ungroup() %>%
  select(-n)

loss_f_cruise <- loss_f_cruise %>%
  pivot_longer(predictor:target,
               names_to = "parameter_class",
               values_to = "loss") %>%
  mutate(loss = as.factor(loss))

grey_plasma <- c("grey80", viridisLite::plasma(4))

loss_f_cruise <- loss_f_cruise %>%
    filter(n_cruise_rel >= 3)

loss_f_cruise %>%
  # filter(n_cruise_rel_cum <= 90) %>%
  group_split(basin_AIP) %>%
  # head(1) %>%
  map(
    ~ ggplot(data = .x,
             aes(rank_n_cruise, n_cruise, fill = loss)) +
      geom_point(shape = 21, size = 2) +
      scale_fill_manual(values = grey_plasma,
                        name = "variables missing") +
      facet_grid(decade ~ parameter_class) +
      labs(title = paste("basin_AIP:", unique(.x$basin_AIP))) +
      ylim(0, NA)
  )

[[1]]

Past versions of f_loss-1.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
ce6cdae	jens-daniel-mueller	2021-12-15

[[2]]

Past versions of f_loss-2.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
ce6cdae	jens-daniel-mueller	2021-12-15

[[3]]

Past versions of f_loss-3.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
ce6cdae	jens-daniel-mueller	2021-12-15

loss_f_cruise %>%
  filter(loss != 0) %>%
  select(basin_AIP, decade, parameter_class, rank_n_cruise, cruise_expocode) %>%
  arrange(basin_AIP, decade, parameter_class, rank_n_cruise) %>%
  kable() %>%
  kable_styling() %>%
  scroll_box(height = "300px")

basin_AIP	decade	parameter_class	rank_n_cruise	cruise_expocode
Atlantic	1989-1999	target	1	323019940104
Atlantic	1989-1999	target	7	33RO19980123
Atlantic	1989-1999	target	9	35A319950113
Atlantic	1989-1999	target	11	06MT19900123
Atlantic	1989-1999	target	12	33LK19960415
Atlantic	1989-1999	target	13	33MW19930704
Atlantic	2000-2009	target	7	35TH20010823
Atlantic	2000-2009	target	8	74DI20040404
Atlantic	2000-2009	target	9	35TH20080610
Atlantic	2000-2009	target	11	35TH20040604
Atlantic	2000-2009	target	12	35TH20020611
Atlantic	2010-2019	target	10	33RO20110926
Indian	1989-1999	target	11	320619960503
Indian	2000-2009	target	2	33RR20080204
Pacific	1989-1999	target	3	31DS19960105
Pacific	1989-1999	target	6	316N19930222
Pacific	1989-1999	target	7	316N19921006
Pacific	1989-1999	target	8	90KD19920214
Pacific	1989-1999	target	11	316N19921204
Pacific	2000-2009	target	1	33RO20071215
Pacific	2010-2019	target	1	318M20091121
Pacific	2010-2019	target	5	320620170703

loss_grid <- loss %>% distinct(lon, lat, cruise_expocode)

loss_f_grid <- left_join(loss_f_cruise,
                          loss_grid)
map +
  geom_tile(data = loss_f_grid,
            aes(lon, lat, fill = loss)) +
  facet_grid(decade ~ parameter_class) +
  scale_fill_manual(values = grey_plasma)

Past versions of f_loss_maps-1.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16
163f976	jens-daniel-mueller	2021-12-16
be0850d	jens-daniel-mueller	2021-12-16

loss_f_grid %>% filter(loss != 0) %>%
  group_split(parameter_class, decade) %>%
  # head(1) %>%
  map(
    ~ map +
      geom_tile(data = .x,
                aes(lon, lat, fill = cruise_expocode)) +
      scale_fill_brewer(palette = "Paired") +
      facet_grid(decade ~ parameter_class)
  )

[[1]]

Past versions of f_loss_maps-2.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[2]]

Past versions of f_loss_maps-3.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[3]]

Past versions of f_loss_maps-4.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

4.3 f == 9

loss_f9 <- loss_all %>%
  select(lon, lat, basin_AIP, decade, cruise_expocode, ends_with("f")) %>%
  pivot_longer(ends_with("f"),
               names_to = "parameter",
               values_to = "value") %>%
  mutate(parameter = str_remove(parameter, "f"))

loss_f9 <- loss_f9 %>%
  count(cruise_expocode, basin_AIP, decade, parameter, value) %>%
  pivot_wider(
    names_from = value,
    names_prefix = "f_",
    values_from = n,
    values_fill = 0
  ) %>%
  mutate(n_cruise = f_0 + f_2 + f_9,
         category = if_else(f_9 <= 0.1 * (n_cruise), "OK", "loss"))

loss_f9_cruise <- loss_f9 %>%
  mutate(parameter_class = if_else(
    parameter %in% c("tco2", "talk", "phosphate"),
    "target",
    "predictor"
  )) %>%
  count(cruise_expocode,
        basin_AIP,
        decade,
        n_cruise,
        parameter_class,
        category) %>%
  pivot_wider(names_from = category,
              values_from = n,
              values_fill = 0) %>%
  select(-OK) %>%
  pivot_wider(names_from = parameter_class,
              values_from = loss) %>%
  group_by(basin_AIP, decade) %>%
  mutate(rank_n_cruise = rank(-n_cruise)) %>%
  ungroup()

loss_f9_cruise <- full_join(loss_f9_cruise, loss_all_n)

loss_f9_cruise <- loss_f9_cruise %>%
  mutate(n_cruise_rel = 100 * n_cruise / n) %>%
  arrange(basin_AIP, decade, -n_cruise_rel) %>%
  group_by(basin_AIP, decade) %>%
  mutate(n_cruise_rel_cum = cumsum(n_cruise_rel)) %>%
  ungroup() %>%
  select(-n)

loss_f9_cruise <- loss_f9_cruise %>%
  pivot_longer(predictor:target,
               names_to = "parameter_class",
               values_to = "loss") %>%
  mutate(loss = as.factor(loss))

grey_plasma <- c("grey80", viridisLite::plasma(4))

loss_f9_cruise <- loss_f9_cruise %>%
    filter(n_cruise_rel >= 3)

loss_f9_cruise %>%
  group_split(basin_AIP) %>%
  # head(1) %>%
  map(
    ~ ggplot(data = .x,
             aes(rank_n_cruise, n_cruise, fill = loss)) +
      geom_point(shape = 21, size = 2) +
      scale_fill_manual(values = grey_plasma,
                        name = "variables missing") +
      facet_grid(decade ~ parameter_class) +
      labs(title = paste("basin_AIP:", unique(.x$basin_AIP))) +
      ylim(0, NA)
  )

[[1]]

Past versions of f9_loss-1.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16

[[2]]

Past versions of f9_loss-2.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16

[[3]]

Past versions of f9_loss-3.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16

loss_f9_cruise %>%
  filter(loss != 0) %>%
  select(basin_AIP, decade, parameter_class, rank_n_cruise, cruise_expocode) %>%
  arrange(basin_AIP, decade, parameter_class, rank_n_cruise) %>%
  kable() %>%
  kable_styling() %>%
  scroll_box(height = "300px")

basin_AIP	decade	parameter_class	rank_n_cruise	cruise_expocode
Atlantic	1989-1999	predictor	2	316N19871123
Atlantic	1989-1999	predictor	4	06AQ19980328
Atlantic	1989-1999	predictor	6	74DI19970807
Atlantic	1989-1999	target	2	316N19871123
Atlantic	1989-1999	target	3	33RO19980123
Atlantic	1989-1999	target	4	06AQ19980328
Atlantic	1989-1999	target	6	74DI19970807
Atlantic	1989-1999	target	7	33MW19930704
Atlantic	2000-2009	target	1	33RO20050111
Atlantic	2000-2009	target	2	33RO20030604
Atlantic	2000-2009	target	3	06AQ20050122
Atlantic	2000-2009	target	4	06AQ20080210
Atlantic	2000-2009	target	5	35TH19990712
Atlantic	2010-2019	predictor	10	06M220170104
Atlantic	2010-2019	predictor	11	06AQ20120107
Atlantic	2010-2019	target	3	33RO20110926
Atlantic	2010-2019	target	6	29HE20130320
Atlantic	2010-2019	target	10	06M220170104
Indian	1989-1999	predictor	1	316N19951202
Indian	1989-1999	predictor	3	316N19950310
Indian	1989-1999	predictor	7	35MF19960220
Indian	1989-1999	target	1	316N19951202
Indian	1989-1999	target	5	316N19941201
Indian	1989-1999	target	8	320619960503
Indian	1989-1999	target	10	316N19950611
Indian	1989-1999	target	12	35MF19930123
Indian	2000-2009	predictor	9	09AR20071216
Indian	2000-2009	target	6	09AR20060102
Indian	2010-2019	predictor	7	09AR20141205
Indian	2010-2019	target	7	09AR20141205
Pacific	1989-1999	predictor	6	33MW19920224
Pacific	1989-1999	target	1	316N19920502
Pacific	1989-1999	target	6	33MW19920224
Pacific	1989-1999	target	8	316N19921006
Pacific	2000-2009	predictor	6	325020060213

loss_all_grid <- loss_all %>% distinct(lon, lat, cruise_expocode)

loss_f9_grid <- left_join(loss_f9_cruise,
                          loss_all_grid)
map +
  geom_tile(data = loss_f9_grid,
            aes(lon, lat, fill = loss)) +
  facet_grid(decade ~ parameter_class) +
  scale_fill_manual(values = grey_plasma)

Past versions of f9_loss_maps-1.png

Version	Author	Date
6aa4b75	jens-daniel-mueller	2021-12-16

loss_f9_grid %>% filter(loss != 0) %>%
  group_split(parameter_class, decade) %>%
  # head(1) %>%
  map(
    ~ map +
      geom_tile(data = .x,
                aes(lon, lat, fill = cruise_expocode)) +
      scale_fill_brewer(palette = "Paired") +
      facet_grid(decade ~ parameter_class)
  )

[[1]]

Past versions of f9_loss_maps-2.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[2]]

Past versions of f9_loss_maps-3.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[3]]

Past versions of f9_loss_maps-4.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[4]]

Past versions of f9_loss_maps-5.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[5]]

Past versions of f9_loss_maps-6.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

[[6]]

Past versions of f9_loss_maps-7.png

Version	Author	Date
e810585	jens-daniel-mueller	2021-12-16

4.4 Overview

expocodes_missing <- GLODAP_cruises_missing %>%
  distinct(cruise_expocode) %>%
  pull()

missing_cruise_grid <- loss_all %>%
  filter(cruise_expocode %in% expocodes_missing) %>%
  distinct(cruise_expocode, decade, lon, lat)

missing_cruise_grid %>%
  group_split(decade) %>%
  # head(1) %>%
  map(
    ~ map +
      geom_tile(data = .x,
                aes(lon, lat, fill = str_sub(
                  cruise_expocode, 1, 4
                ))) +
      facet_grid(decade ~ .) +
      scale_fill_brewer(palette = "Paired",
                        name = "RV")
  )

[[1]]

Past versions of overview-1.png

Version	Author	Date
00227e6	jens-daniel-mueller	2021-12-20

[[2]]

Past versions of overview-2.png

Version	Author	Date
00227e6	jens-daniel-mueller	2021-12-20

[[3]]

Past versions of overview-3.png

Version	Author	Date
00227e6	jens-daniel-mueller	2021-12-20

4.5 P18 phosphate

P18 <- full_join(
  GLODAP,
  GLODAP_expocodes
)

P18 <- P18 %>%
  filter(cruise_expocode %in% c("33RO20161119",
                                "33RO20071215",
                                "31DS19940126"))

P18 %>%
  ggplot(aes(date, lat)) +
  geom_point() +
  facet_grid() +
  facet_wrap(cruise_expocode ~., scales = "free_x", ncol = 1)

Past versions of P18_nitrate-1.png

Version	Author	Date
70923f2	jens-daniel-mueller	2021-12-14
b68b58e	jens-daniel-mueller	2021-12-13

P18 %>%
  filter(!is.na(nitrate)) %>%
  ggplot(aes(lat, depth, col= nitrate)) +
  geom_point() +
  scale_color_viridis_c() +
  scale_y_reverse() +
  facet_grid(cruise_expocode ~.)

Past versions of P18_nitrate-2.png

Version	Author	Date
70923f2	jens-daniel-mueller	2021-12-14
b68b58e	jens-daniel-mueller	2021-12-13

P18_grid <- P18 %>%
  select(lat, lon, depth, cruise_expocode, nitrate) %>%
  mutate(depth = as.numeric(as.character(cut(depth,
                     seq(0,1e4, 500),
                     seq(250,1e4,500))))) %>%
  group_by(lat, depth, cruise_expocode) %>%
  summarise(nitrate = mean(nitrate, na.rm=TRUE)) %>%
  ungroup()

P18_grid %>%
  ggplot(aes(lat, depth, col= nitrate)) +
  geom_point() +
  scale_color_viridis_c() +
  scale_y_reverse() +
  facet_grid(cruise_expocode ~.)

Past versions of P18_nitrate-3.png

Version	Author	Date
70923f2	jens-daniel-mueller	2021-12-14
b68b58e	jens-daniel-mueller	2021-12-13

P18_grid_offset <- P18_grid %>%
  pivot_wider(names_from = cruise_expocode,
              values_from = nitrate) %>%
  mutate(delta_nitrate_1994_2007 = (`31DS19940126` - `33RO20071215`) / `33RO20071215`,
         delta_nitrate_1994_2016 = (`31DS19940126` - `33RO20161119`) / `33RO20071215`,
         delta_nitrate_2007_2016 = (`33RO20071215` - `33RO20161119`) / `33RO20071215`) %>%
  select(lat, depth, starts_with("delta")) %>%
  pivot_longer(starts_with("delta"),
               values_to = "delta_nitrate",
               names_to = "years",
               names_prefix = "delta_nitrate_") %>%
  filter(delta_nitrate > -20,
         depth > 1500)

P18_grid_offset %>%
  ggplot(aes(lat, depth, col= delta_nitrate)) +
  geom_point() +
  scale_color_divergent() +
  scale_y_reverse() +
  facet_grid(years ~.)

Past versions of P18_nitrate-4.png

Version	Author	Date
70923f2	jens-daniel-mueller	2021-12-14

P18_grid_offset %>%
  group_by(lat, years) %>%
  summarise(delta_nitrate = mean(delta_nitrate, na.rm = TRUE)) %>%
  ungroup() %>%
  ggplot(aes(lat, delta_nitrate, col = years, fill = years)) +
  geom_hline(yintercept = 0) +
  stat_smooth(method = "lm", formula = y ~ x + I(x ^ 2)) +
  geom_point() +
  geom_line()

Past versions of P18_nitrate-5.png

Version	Author	Date
70923f2	jens-daniel-mueller	2021-12-14

rm(P18, P18_grid)

4.6 A16

A16 <- full_join(
  GLODAP,
  GLODAP_expocodes
)

A16 <- A16 %>%
  filter(cruise_expocode %in% c(
    "33MW19930704" #A16N-1993
    ))

map +
  geom_tile(data = A16 %>% distinct(lon, lat),
            aes(lon, lat))

Past versions of A16-1.png

Version	Author	Date
70923f2	jens-daniel-mueller	2021-12-14

A16 %>%
  select(ends_with(c("qc"))) %>%
  pivot_longer(everything(),
               names_to = "flag",
               values_to = "value") %>%
  distinct(flag, value)

# A tibble: 9 × 2
  flag        value
  <chr>       <dbl>
1 salinityqc      1
2 oxygenqc        1
3 nitrateqc       1
4 silicateqc      1
5 phosphateqc     1
6 tco2qc          1
7 talkqc          1
8 talkqc          0
9 tco2qc          0

rm(A16)

5 Adjustments

Typically, the reasons for multiple expocode entries of the same cruise in the adjustment table list are:

1. The cruise adjustments are different for different station, i.e. station split (e.g. 316N19821201)

-> How to merge? Based on first and last station? Cruise_ID not in GLODAP merged master file.

2. The cruise adjustments are different for different legs (e.g. 316N19871123.6) but have been merged into one cruise (316N19871123) for the product

-> How to merge? Based on first and last station?

3. The cruise adjustments have been updated/changed through the versions, here always look for the most recent entry (see table below) (e.g. 320620180309)

For the expocodes not listed in the expocode list the reason is that INDIGO has been splitted into three cruises: 35MF1985-1987 and the same holds for SAVE (316N1987 - 6legs). Further 49HH20011208 has been assigned wrongly and corrected to 49HH20011127.

Remove expocode INDIGO and maintain only 35MF19850224. Remove expocode SAVE and maintain only 316N1987.

GLODAP_adjustments <- GLODAP_adjustments %>%
  select(cruise_expocode,
         first_station, last_station,
         version,
         calculated_carbon_parameter,
         ends_with("_adj")) %>%
  rename(talk_adj = alkalinity_adj)

# Remove cruises INDIGO and SAVE

GLODAP_adjustments <-
  GLODAP_adjustments %>%
  filter(!(cruise_expocode %in% c("INDIGO", "SAVE")))

# correct expocode 49HH20011208 to 49HH20011127

GLODAP_adjustments <-
  GLODAP_adjustments %>%
  mutate(cruise_expocode = if_else(
    cruise_expocode == "49HH20011208",
    "49HH20011127",
    cruise_expocode
  ))


# select latest adjustment versions

GLODAP_adjustments <-
  GLODAP_adjustments %>%
  group_by(cruise_expocode, first_station) %>%
  mutate(n = n(),
         version_max = max(version)) %>%
  ungroup() %>%
  filter(version == version_max | is.na(version)) %>%
  select(-c(version_max, version, n))

# harmonize multiple cruise expocodes of 316N1987

GLODAP_adjustments <- GLODAP_adjustments %>%
  # filter(str_detect(cruise_expocode, "\\.")) %>%
  mutate(cruise_expocode = str_split(cruise_expocode,
                                     "\\.",
                                     simplify = TRUE)[,1])

# correct one wrong last_cruise label

GLODAP_adjustments <- GLODAP_adjustments %>%
  mutate(
    last_station = if_else(
      cruise_expocode == "318M20091121" &
        first_station == 1,
      127,
      last_station
    )
  )

# merge with expocode table
GLODAP_adjustments <- full_join(GLODAP_adjustments, GLODAP_expocodes) %>%
  relocate(cruise)



GLODAP_adjustments_NA_cruises <-
  GLODAP_adjustments %>%
  filter(is.na(cruise))

GLODAP_adjustments_duplicated_cruises <-
  GLODAP_adjustments %>%
  group_by(cruise_expocode, cruise) %>%
  mutate(n = n()) %>%
  ungroup() %>%
  filter(n != 1)


GLODAP_adjustments %>%
  pivot_longer(salinity_adj:c13_adj,
               names_to = "parameter",
               values_to = "adjustment") %>%
  ggplot(aes(adjustment)) +
  geom_histogram() +
  scale_y_log10() +
  facet_wrap(~ parameter, scales = "free_x")

Past versions of prepare_adjustments-1.png

Version	Author	Date
6d6a23e	jens-daniel-mueller	2021-11-01

6 Crossover analysis

GLODAP <-
  left_join(GLODAP,
            GLODAP_adjustments %>%
              distinct(cruise, cruise_expocode))

6.1 Histograms

GLODAP_adjustments_long <- GLODAP_adjustments %>%
  select(
    cruise_expocode,
    first_station,
    last_station,
    tco2_adj,
    talk_adj,
    phosphate_adj,
    nitrate_adj,
    oxygen_adj,
    silicate_adj,
    salinity_adj
  ) %>%
  pivot_longer(tco2_adj:salinity_adj,
               names_to = "parameter",
               values_to = "adjustment") %>%
  mutate(parameter = str_remove(parameter, "_adj"))

p_adjustment_histo <- GLODAP_adjustments_long %>%
  ggplot(aes(adjustment)) +
  geom_histogram() +
  scale_y_log10() +
  facet_wrap(~ parameter, scales = "free_x", ncol = 1)

p_xover_histo <-
  ggplot() +
  geom_histogram(data = glodapv2_xover,
                 aes(offset)) +
  labs(title = "v2") +
  scale_y_log10() +
  facet_wrap(~ parameter, scales = "free_x", ncol = 1)

p_xover_histo_2021 <-
  ggplot() +
  geom_histogram(data = glodapv2_2021_xover,
                 aes(offset)) +
  labs(title = "v2_2021") +
  scale_y_log10() +
  facet_wrap(~ parameter, scales = "free_x", ncol = 1)

p_xover_histo + p_xover_histo_2021 + p_adjustment_histo

Past versions of crossover_histograms-1.png

Version	Author	Date
a87f8c7	jens-daniel-mueller	2021-12-20
d5ef2c6	jens-daniel-mueller	2021-12-20

rm(p_xover_histo, p_xover_histo_2021, p_adjustment_histo)

6.2 Adjustment correction

glodapv2_xover <- left_join(
  glodapv2_xover,
  GLODAP_adjustments_long %>%
    select(
      cruise_A = cruise_expocode,
      parameter,
      first_station_A = first_station,
      last_station_A = last_station,
      adjustment_A = adjustment
    )
)

glodapv2_xover <- left_join(
  glodapv2_xover,
  GLODAP_adjustments_long %>%
    select(
      cruise_B = cruise_expocode,
      parameter,
      first_station_B = first_station,
      last_station_B = last_station,
      adjustment_B = adjustment
    )
)

glodapv2_xover <- glodapv2_xover  %>%
  mutate(offset_adj =
           if_else(parameter %in% c("salinity", "talk", "tco2"),
                   offset + adjustment_A - adjustment_B,
                   offset * adjustment_A / adjustment_B))

glodapv2_2021_xover <- left_join(
  glodapv2_2021_xover,
  GLODAP_adjustments_long %>%
    select(
      cruise_A = cruise_expocode,
      parameter,
      first_station_A = first_station,
      last_station_A = last_station,
      adjustment_A = adjustment
    )
)

glodapv2_2021_xover <- left_join(
  glodapv2_2021_xover,
  GLODAP_adjustments_long %>%
    select(
      cruise_B = cruise_expocode,
      parameter,
      first_station_B = first_station,
      last_station_B = last_station,
      adjustment_B = adjustment
    )
)

glodapv2_2021_xover <- glodapv2_2021_xover  %>%
  mutate(offset_adj =
           if_else(parameter %in% c("salinity", "talk", "tco2"),
                   offset + adjustment_A,
                   offset * adjustment_A))


xover <- bind_rows(glodapv2_xover,
                   glodapv2_2021_xover)

6.3 Missing/flagged data

hline_intercept <-
  tibble(parameter = unique(xover$parameter)) %>%
  mutate(intercept = if_else(parameter %in% c("salinity", "talk", "tco2"),
                             0,
                             1))

for (i_expocodes_missing in expocodes_missing) {
  # i_expocodes_missing <- expocodes_missing[1]

  cruise <- GLODAP %>%
    filter(cruise_expocode == i_expocodes_missing) %>%
    rename(salinity = sal)

  parameter_qc <- loss_qc %>%
    filter(cruise_expocode == i_expocodes_missing,
           category == "loss")

  print(parameter_qc)

  parameter_qc <- parameter_qc %>%
    pull(parameter)

  if (length(parameter_qc) > 0) {
    parameter_qc <- parameter_qc %>% str_c(.,"qc")
  }

  parameter_f <- loss_f %>%
    filter(cruise_expocode == i_expocodes_missing,
           category == "loss")

  print(parameter_f)

  parameter_f <- parameter_f %>%
    pull(parameter)

  if (length(parameter_f) > 0) {
    parameter_f <- parameter_f %>% str_c(.,"f")
  }

  parameter_f9 <- loss_f9 %>%
    filter(cruise_expocode == i_expocodes_missing,
           category == "loss")

  print(parameter_f9)

  parameter_f9 <- parameter_f9 %>%
    pull(parameter)

  if (length(parameter_f9) > 0) {
    parameter_f9 <- parameter_f9 %>% str_c(.,"f")
  }

  parameter_check <-
    unique(c(parameter_qc, parameter_f, parameter_f9))

  print(parameter_check)

  rm(parameter_qc, parameter_f, parameter_f9)

  xover_cruise_A <- xover %>%
    filter(cruise_A %in% i_expocodes_missing)

  xover_cruise_B <- xover %>%
    filter(cruise_B %in% i_expocodes_missing)

  xover_cruise_B_rev <- xover_cruise_B %>%
    rename(
      cruise_A_back = cruise_A,
      cruise_A = cruise_B,
      adjustment_A_back = adjustment_A,
      adjustment_A = adjustment_B
    ) %>%
    rename(cruise_B = cruise_A_back,
           adjustment_B = adjustment_A_back) %>%
    mutate(
      offset = if_else(
        parameter %in% c("salinity", "talk", "tco2"),
        -offset,
        1 / offset
      ),
      offset_adj = if_else(
        parameter %in% c("salinity", "talk", "tco2"),
        -offset_adj,
        1 / offset_adj
      )
    )

  xover_cruise <- bind_rows(xover_cruise_A,
                            xover_cruise_B_rev)

  xover_cruise <- xover_cruise %>%
    mutate(dateA = ymd(str_sub(cruise_A, 5, 12)),
           dateB = ymd(str_sub(cruise_B, 5, 12)))


  # xover_cruise <- xover_cruise %>%
  #   mutate(RV = str_sub(cruise_B, 1, 4))

  for (i_parameter_check in parameter_check) {
    # i_parameter_check <- parameter_check[1]

    cruise_flag_count <- cruise %>%
      count(lon, lat, !!sym(i_parameter_check)) %>%
      group_by(lon, lat) %>%
      mutate(n_rel = 100 * n / sum(n)) %>%
      ungroup()

    print(
      map +
        geom_tile(data = cruise_flag_count,
                  aes(lon, lat, fill = n_rel)) +
        scale_fill_viridis_c(option = "magma",
                             direction = -1) +
        facet_wrap(i_parameter_check, ncol = 2) +
        labs(title = i_expocodes_missing,
             subtitle = i_parameter_check)
    )

    i_parameter_check_var <- str_remove(i_parameter_check, "f")
    i_parameter_check_var <- str_remove(i_parameter_check_var, "qc")

    print(
      cruise %>%
        ggplot(aes(!!sym(i_parameter_check_var), depth, fill=station)) +
        geom_point(alpha = 0.2, shape = 21) +
        scale_fill_viridis_c() +
        scale_y_reverse() +
        facet_wrap(i_parameter_check, ncol = 2) +
        labs(title = i_expocodes_missing,
             subtitle = i_parameter_check)
    )

  }

  p_crossover_ts <- xover_cruise %>%
    ggplot(aes(dateB, offset_adj)) +
    geom_vline(xintercept = ymd(str_sub(i_expocodes_missing, 5)),
               col = "red") +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_point() +
    facet_grid(parameter ~ ., scales = "free_y") +
    labs(title = i_expocodes_missing,
         subtitle = str_c(parameter_check, collapse = "+")) +
    theme(
      legend.position = "bottom",
      legend.direction = "vertical",
      axis.title.x = element_blank()
    )

  xover_cruise_decade <- xover_cruise %>%
    mutate(decade = cut(
      year(dateB),
      c(1989, 1999, 2009, 2019),
      labels = c("1989-1999", "2000-2009", "2010-2019")
    )) %>%
    filter(!is.na(decade),
           !is.na(offset_adj)) %>%
    group_by(parameter, decade) %>%
    mutate(n = n()) %>%
    ungroup() %>%
    filter(n > 2)


  p_crossover_decadal <-
    ggplot() +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_violin(
      data = xover_cruise_decade,
      aes(x = decade, y = offset_adj),
      fill = "gold"
    ) +
    geom_boxplot(
      data = xover_cruise_decade,
      aes(x = decade, y = offset_adj),
      width = 0.2
    ) +
    labs(title = "Decadal averages") +
    facet_grid(parameter ~ ., scales = "free_y") +
    theme(axis.title.x = element_blank(),
          axis.text.x = element_text(angle = 90))

  print(
  p_crossover_ts + p_crossover_decadal +
    plot_layout(widths = c(2, 1))
  )

  rm(p_crossover_ts, p_crossover_decadal)

}

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 320620170703    Pacific   2010-2019 talk       2809   449     3258 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "talkf"

Past versions of crossover_missing_flagged_data-1.png

Version	Author	Date
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-2.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-3.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 323019940104    Atlantic  1989-1999 talk       2393   539     2932 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "talkf"

Past versions of crossover_missing_flagged_data-4.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-5.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-6.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 325020060213    Pacific   2000-… aou        2236   349     0     2585 loss
[1] "aouf"

Past versions of crossover_missing_flagged_data-7.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-8.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-9.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 4 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 06AQ19980328    Atlantic  1989-… nitrate    1343   706     9     2058 loss
2 06AQ19980328    Atlantic  1989-… phosphate  1347   707     4     2058 loss
3 06AQ19980328    Atlantic  1989-… silicate   1348   708     2     2058 loss
4 06AQ19980328    Atlantic  1989-… talk          0  2058     0     2058 loss
[1] "nitratef"   "phosphatef" "silicatef"  "talkf"

Past versions of crossover_missing_flagged_data-10.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-11.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-12.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-13.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-14.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-15.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-16.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-17.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-18.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

# A tibble: 2 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 06MT19900123    Atlantic  1989-1999 talk        660     0      660 loss
2 06MT19900123    Pacific   1989-1999 talk          9     0        9 loss
# A tibble: 2 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 06MT19900123    Atlantic  1989-1999 talk          0   660      660 loss
2 06MT19900123    Pacific   1989-1999 talk          0     9        9 loss
# A tibble: 3 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 06MT19900123    Atlantic  1989-… talk          0   324   667      991 loss
2 06MT19900123    Pacific   1989-… aou         233    62     0      295 loss
3 06MT19900123    Pacific   1989-… talk          0   282    13      295 loss
[1] "talkqc" "talkf"  "aouf"

Past versions of crossover_missing_flagged_data-19.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-20.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-21.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-22.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-23.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-24.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-25.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 2 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 316N19871123    Atlantic  1989-… aou        2554   344     0     2898 loss
2 316N19871123    Atlantic  1989-… talk       1870  1028     0     2898 loss
[1] "aouf"  "talkf"

Past versions of crossover_missing_flagged_data-26.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-27.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-28.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-29.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-30.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 316N19920502    Pacific   1989-1999 talk        570     0      570 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 316N19920502    Pacific   1989-1999 talk          0   570      570 loss
# A tibble: 2 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 316N19920502    Pacific   1989-… phosphate  2676   376    29     3081 loss
2 316N19920502    Pacific   1989-… talk          0  2508   573     3081 loss
[1] "talkqc"     "talkf"      "phosphatef"

Past versions of crossover_missing_flagged_data-31.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-32.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-33.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20
7f65d3a	jens-daniel-mueller	2021-12-20
6106236	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-34.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-35.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-36.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-37.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 316N19921006    Pacific   1989-1999 talk       1352     0     1352 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 316N19921006    Pacific   1989-1999 talk          0  1352     1352 loss
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 316N19921006    Pacific   1989-… talk          0   175  1359     1534 loss
[1] "talkqc" "talkf"

Past versions of crossover_missing_flagged_data-38.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-39.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-40.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-41.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-42.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 316N19941201    Indian    1989-… talk       1705   466     0     2171 loss
[1] "talkf"

Past versions of crossover_missing_flagged_data-43.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-44.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-45.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 2 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 316N19950310    Indian    1989-… aou        1958   439     0     2397 loss
2 316N19950310    Indian    1989-… salinity   1989   394    14     2397 loss
[1] "aouf"      "salinityf"

Past versions of crossover_missing_flagged_data-46.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-47.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-48.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-49.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-50.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 316N19950611    Indian    1989-… talk       1657   264     0     1921 loss
[1] "talkf"

Past versions of crossover_missing_flagged_data-51.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-52.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-53.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 2 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 318M20091121    Pacific   2010-2019 talk       4159  1041     5200 loss
2 318M20091121    Pacific   2010-2019 tco2       4332   868     5200 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "talkf" "tco2f"

Past versions of crossover_missing_flagged_data-54.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-55.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-56.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-57.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-58.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 31DS19940126    Pacific   1989-1999 nitrate    2873     0     2873 loss
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "nitrateqc"

Past versions of crossover_missing_flagged_data-59.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-60.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-61.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 31DS19960105    Pacific   1989-1999 talk       2395   282     2677 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "talkf"

Past versions of crossover_missing_flagged_data-62.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-63.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-64.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 33MW19930704    Atlantic  1989-1999 talk         78   545      623 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 33MW19930704    Atlantic  1989-1999 talk        500   123      623 loss
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 33MW19930704    Atlantic  1989-… phosphate   671  1146     1     1818 loss
[1] "talkqc"     "talkf"      "phosphatef"

Past versions of crossover_missing_flagged_data-65.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-66.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-67.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-68.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-69.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-70.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-71.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 33RO19980123    Atlantic  1989-1999 talk        864   385     1249 loss
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 33RO19980123    Atlantic  1989-… phosphate  1430   661     5     2096 loss
[1] "talkf"      "phosphatef"

Past versions of crossover_missing_flagged_data-72.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-73.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-74.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-75.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-76.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 33RO20071215    Pacific   2000-2009 talk       3549   951     4500 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "talkf"

Past versions of crossover_missing_flagged_data-77.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-78.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-79.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 33RO20110926    Atlantic  2010-2019 tco2        842   283     1125 loss
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 33RO20110926    Atlantic  2010-… phosphate  1239  1304     1     2544 loss
[1] "tco2f"      "phosphatef"

Past versions of crossover_missing_flagged_data-80.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-81.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-82.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-83.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-84.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 33RR20080204    Indian    2000-2009 tco2       1720   405     2125 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "tco2f"

Past versions of crossover_missing_flagged_data-85.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-86.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-87.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35A319950113    Atlantic  1989-1999 tco2        733   162      895 loss
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 35A319950113    Atlantic  1989-… aou         900   198     0     1098 loss
[1] "tco2f" "aouf"

Past versions of crossover_missing_flagged_data-88.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-89.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-90.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-91.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

Past versions of crossover_missing_flagged_data-92.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21
2704ff6	jens-daniel-mueller	2021-12-20

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 35MF19930123    Indian    1989-… phosphate     0  1436     0     1436 loss
[1] "phosphatef"

Past versions of crossover_missing_flagged_data-93.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-94.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-95.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 35MF19960220    Indian    1989-… silicate   1630   350    24     2004 loss
[1] "silicatef"

Past versions of crossover_missing_flagged_data-96.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-97.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-98.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35TH20020611    Atlantic  2000-2009 tco2        926     0      926 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35TH20020611    Atlantic  2000-2009 tco2          0   926      926 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "tco2qc" "tco2f"

Past versions of crossover_missing_flagged_data-99.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-100.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-101.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-102.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-103.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35TH20040604    Atlantic  2000-2009 tco2        928     0      928 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35TH20040604    Atlantic  2000-2009 tco2          0   928      928 loss
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 35TH20040604    Atlantic  2000-… nitrate     926   110    14     1050 loss
[1] "tco2qc"   "tco2f"    "nitratef"

Past versions of crossover_missing_flagged_data-104.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-105.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-106.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-107.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-108.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-109.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-110.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35TH20080610    Atlantic  2000-2009 tco2       1032     0     1032 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 35TH20080610    Atlantic  2000-2009 tco2          0  1032     1032 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "tco2qc" "tco2f"

Past versions of crossover_missing_flagged_data-111.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-112.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-113.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-114.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-115.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 3 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 74DI19970807    Atlantic  1989-… nitrate    1650   274    12     1936 loss
2 74DI19970807    Atlantic  1989-… phosphate     0  1936     0     1936 loss
3 74DI19970807    Atlantic  1989-… silicate   1649   262    25     1936 loss
[1] "nitratef"   "phosphatef" "silicatef"

Past versions of crossover_missing_flagged_data-116.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-117.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-118.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-119.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-120.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-121.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-122.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 74DI20040404    Atlantic  2000-2009 talk        110   948     1058 loss
# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 74DI20040404    Atlantic  2000-2009 talk        948   110     1058 loss
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "talkqc" "talkf"

Past versions of crossover_missing_flagged_data-123.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-124.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-125.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-126.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-127.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 1 × 8
  cruise_expocode basin_AIP decade    parameter  qc_0  qc_1 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 74EQ20151206    Atlantic  2010-2019 nitrate    1844     0     1844 loss
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 9
# … with 9 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_9 <int>, f_0 <int>, n_cruise <int>,
#   category <chr>
[1] "nitrateqc"

Past versions of crossover_missing_flagged_data-128.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-129.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-130.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 33RO20030604    Atlantic  2000-… phosphate     0  2487     0     2487 loss
[1] "phosphatef"

Past versions of crossover_missing_flagged_data-131.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-132.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-133.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 33RO20050111    Atlantic  2000-… phosphate     0  2546     0     2546 loss
[1] "phosphatef"

Past versions of crossover_missing_flagged_data-134.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-135.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-136.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 3 × 8
  cruise_expocode basin_AIP decade    parameter   f_2   f_0 n_cruise category
  <chr>           <chr>     <fct>     <chr>     <int> <int>    <int> <chr>
1 06AQ20080210    Pacific   2000-2009 nitrate      48    17       65 loss
2 06AQ20080210    Pacific   2000-2009 phosphate    48    17       65 loss
3 06AQ20080210    Pacific   2000-2009 silicate     48    17       65 loss
# A tibble: 5 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 06AQ20080210    Atlantic  2000-… talk       1144   778     0     1922 loss
2 06AQ20080210    Pacific   2000-… nitrate      62    31    24      117 loss
3 06AQ20080210    Pacific   2000-… phosphate    62    31    24      117 loss
4 06AQ20080210    Pacific   2000-… silicate     62    31    24      117 loss
5 06AQ20080210    Pacific   2000-… talk         74    43     0      117 loss
[1] "nitratef"   "phosphatef" "silicatef"  "talkf"

Past versions of crossover_missing_flagged_data-137.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-138.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-139.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-140.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-141.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-142.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-143.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-144.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-145.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 06AQ20050122    Atlantic  2000-… talk          0  2248     0     2248 loss
[1] "talkf"

Past versions of crossover_missing_flagged_data-146.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-147.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-148.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, qc_0 <int>, qc_1 <int>, n_cruise <int>, category <chr>
# A tibble: 0 × 8
# … with 8 variables: cruise_expocode <chr>, basin_AIP <chr>, decade <fct>,
#   parameter <chr>, f_2 <int>, f_0 <int>, n_cruise <int>, category <chr>
# A tibble: 1 × 9
  cruise_expocode basin_AIP decade parameter   f_2   f_9   f_0 n_cruise category
  <chr>           <chr>     <fct>  <chr>     <int> <int> <int>    <int> <chr>
1 29HE20130320    Atlantic  2010-… phosphate     0  2256     0     2256 loss
[1] "phosphatef"

Past versions of crossover_missing_flagged_data-149.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-150.png

Version	Author	Date
fcff192	jens-daniel-mueller	2021-12-21

Past versions of crossover_missing_flagged_data-151.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
fcff192	jens-daniel-mueller	2021-12-21

6.4 IO 1990 data

IO_1990_expocodes <- GLODAP %>%
  filter(str_detect(cruise_expocode, "316N199") &
           basin_AIP == "Indian") %>%
  distinct(cruise_expocode) %>%
  pull()

xover_IO_1990_A <- xover %>%
  filter(cruise_A %in% IO_1990_expocodes)

xover_IO_1990_B <- xover %>%
  filter(cruise_B %in% IO_1990_expocodes)

xover_IO_1990_B_rev <- xover_IO_1990_B %>%
  rename(
    cruise_A_back = cruise_A,
    cruise_A = cruise_B,
    adjustment_A_back = adjustment_A,
    adjustment_A = adjustment_B
  ) %>%
  rename(cruise_B = cruise_A_back,
         adjustment_B = adjustment_A_back) %>%
  mutate(
    offset = if_else(parameter %in% c("salinity", "talk", "tco2"),
                     -offset,
                     1/offset),
    offset_adj = if_else(
      parameter %in% c("salinity", "talk", "tco2"),
      -offset_adj,
      1/offset_adj
    )
  )

xover_IO_1990 <- bind_rows(xover_IO_1990_A,
                           xover_IO_1990_B_rev)

xover_IO_1990 <- xover_IO_1990 %>%
  mutate(dateA = ymd(str_sub(cruise_A, 5, 12)),
         dateB = ymd(str_sub(cruise_B, 5, 12)))


xover_IO_1990 <- xover_IO_1990 %>%
  mutate(RV = if_else(str_detect(cruise_B, "316N"),
                      "316N",
                      "other"))


xover_IO_1990_decade <- xover_IO_1990 %>%
    mutate(decade = cut(
      year(dateB),
      c(1989, 1999, 2009, 2019),
      labels = c("1989-1999", "2000-2009", "2010-2019")
    )) %>%
    filter(!is.na(decade),
           !is.na(offset_adj),
           !is.na(offset),
           RV != "316N") %>%
  arrange(dateB)


xover_IO_1990_decade %>%
  group_by(parameter, decade) %>%
  summarise(offset_adj_mean = mean(offset_adj, na.rm = TRUE),
            offset_adj_median = median(offset_adj, na.rm = TRUE)) %>%
  ungroup() %>%
  kable() %>%
  kable_styling() %>%
  scroll_box(height = "300px")

parameter	decade	offset_adj_mean	offset_adj_median
nitrate	1989-1999	0.9957851	0.9952475
nitrate	2000-2009	1.0018716	1.0034000
nitrate	2010-2019	0.9942423	0.9954335
oxygen	1989-1999	0.9951297	0.9961500
oxygen	2000-2009	0.9984347	1.0003001
oxygen	2010-2019	0.9992518	0.9981748
phosphate	1989-1999	0.9916439	0.9953220
phosphate	2000-2009	1.0050862	1.0052750
phosphate	2010-2019	1.0016116	1.0031516
salinity	1989-1999	-0.0014211	-0.0011000
salinity	2000-2009	-0.0009812	-0.0012000
salinity	2010-2019	-0.0008173	-0.0009442
silicate	1989-1999	0.9963137	0.9996248
silicate	2000-2009	1.0045634	1.0058000
silicate	2010-2019	1.0076910	1.0101825
talk	1989-1999	2.8826300	3.2700000
talk	2000-2009	2.9318063	3.4280000
talk	2010-2019	3.3860085	3.8736858
tco2	1989-1999	-0.7060357	-0.3462000
tco2	2000-2009	-2.6973312	-2.5524500
tco2	2010-2019	-2.0787148	-1.9810457

p_crossover_ts <- xover_IO_1990 %>%
  ggplot(aes(dateB, offset, col = RV)) +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  geom_point(shape = 21) +
  scale_color_brewer(palette = "Set1") +
  facet_grid(parameter ~ ., scales = "free_y") +
  labs(title = "Crossover 316N199XXXXX") +
  theme(
    legend.position = "bottom",
    legend.direction = "vertical",
    axis.title.x = element_blank()
  )

p_crossover_decadal <-
  ggplot() +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  geom_violin(data = xover_IO_1990_decade,
               aes(x = decade, y = offset), fill="gold") +
  geom_boxplot(data = xover_IO_1990_decade,
               aes(x = decade, y = offset),
               width = 0.2) +
  facet_grid(parameter ~ ., scales = "free_y") +
  labs(title = "Decadal offsets") +
  theme(axis.title.x = element_blank(),
        axis.text.x = element_text(angle = 90))


p_crossover_ts + p_crossover_decadal +
  plot_layout(widths = c(2, 1))

Past versions of crossover_analysis_data-1.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
a87f8c7	jens-daniel-mueller	2021-12-20
d5ef2c6	jens-daniel-mueller	2021-12-20
00227e6	jens-daniel-mueller	2021-12-20

rm(p_crossover_ts, p_crossover_decadal)

p_crossover_ts <- xover_IO_1990 %>%
  ggplot(aes(dateB, offset_adj, col = RV)) +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  geom_point(shape = 21) +
  scale_color_brewer(palette = "Set1") +
  facet_grid(parameter ~ ., scales = "free_y") +
  labs(title = "Crossover 316N199XXXXX") +
  theme(
    legend.position = "bottom",
    legend.direction = "vertical",
    axis.title.x = element_blank()
  )

p_crossover_decadal <-
  ggplot() +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  geom_violin(data = xover_IO_1990_decade,
               aes(x = decade, y = offset_adj), fill="gold") +
  geom_boxplot(data = xover_IO_1990_decade,
               aes(x = decade, y = offset_adj),
               width = 0.2) +
  facet_grid(parameter ~ ., scales = "free_y") +
  labs(title = "Decadal offsets") +
  theme(axis.title.x = element_blank(),
        axis.text.x = element_text(angle = 90))

  ggplot() +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  # geom_violin(data = xover_IO_1990 %>%
  #               filter(year(dateB) >= 2000, year(dateB) < 2010),
  #              aes(x = "2000-2009", y = offset_adj), fill="gold") +
  geom_boxplot(data = xover_IO_1990 %>%
                filter(year(dateB) >= 2000, year(dateB) < 2010),
               aes(x = "2000-2009", y = offset_adj),
               width = 0.2) +
  facet_grid(parameter ~ ., scales = "free_y") +
  labs(title = "Decadal offsets") +
  theme(axis.title.x = element_blank(),
        axis.text.x = element_text(angle = 90))

Past versions of crossover_analysis_data-2.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
a87f8c7	jens-daniel-mueller	2021-12-20
d5ef2c6	jens-daniel-mueller	2021-12-20
00227e6	jens-daniel-mueller	2021-12-20

p_crossover_ts + p_crossover_decadal +
  plot_layout(widths = c(2, 1))

Past versions of crossover_analysis_data-3.png

Version	Author	Date
51ec1fe	jens-daniel-mueller	2021-12-23
d5ef2c6	jens-daniel-mueller	2021-12-20
00227e6	jens-daniel-mueller	2021-12-20

rm(p_crossover_ts, p_crossover_decadal)

6.5 5 basin decadal

basinmask_5 <- basinmask_5 %>%
  mutate(
    basin = str_replace(basin, "_", ". "),
    basin = fct_relevel(
      basin,
      "N. Pacific",
      "S. Pacific",
      "N. Atlantic",
      "S. Atlantic",
      "Indian"
    )
  )

for (i_basin in unique(basinmask_5$basin)) {
  # i_basin <- unique(basinmask_5$basin)[5]

  expocodes_subbasin <- inner_join(GLODAP, basinmask_5) %>%
    filter(basin == i_basin)

  print(
  map +
    geom_tile(data = expocodes_subbasin %>% distinct(lon, lat),
              aes(lon, lat)) +
    labs(title = i_basin)
  )

  expocodes_subbasin_qc <- expocodes_subbasin %>%
    select(row_number, cruise_expocode, ends_with("qc")) %>%
    pivot_longer(ends_with("qc"),
                 names_to = "parameter",
                 values_to = "value") %>%
    filter(value == 1) %>%
    pivot_wider(names_from = parameter,
                values_from = value) %>%
    count(cruise_expocode)

  expocodes_subbasin_f <- expocodes_subbasin %>%
    select(row_number, cruise_expocode, ends_with("f")) %>%
    pivot_longer(ends_with("f"),
                 names_to = "parameter",
                 values_to = "value") %>%
    filter(value == 2) %>%
    pivot_wider(names_from = parameter,
                values_from = value) %>%
    count(cruise_expocode)

  expocodes_subbasin <- inner_join(expocodes_subbasin_f, expocodes_subbasin_qc) %>%
    group_by(cruise_expocode) %>%
    summarise(n = min(n)) %>%
    ungroup()

  rm(expocodes_subbasin_f, expocodes_subbasin_qc)

  xover_subbasin <- xover %>%
    filter(
      cruise_A %in% expocodes_subbasin$cruise_expocode &
        cruise_B %in% expocodes_subbasin$cruise_expocode
    )


  xover_subbasin <- xover_subbasin %>%
    mutate(dateA = year(ymd(str_sub(cruise_A, 5, 12))),
           dateB = year(ymd(str_sub(cruise_B, 5, 12))))


  for (i_cruise_expocode in expocodes_subbasin$cruise_expocode){
    # i_cruise_expocode <- expocodes_subbasin$cruise_expocode[1]

    xover_cruise_A <- xover_subbasin %>%
      filter(cruise_A == i_cruise_expocode)

    xover_cruise_B <- xover_subbasin %>%
      filter(cruise_B == i_cruise_expocode)

    xover_cruise_B_rev <- xover_cruise_B %>%
      rename(
        cruise_A_back = cruise_A,
        cruise_A = cruise_B,
        dateA_back = dateA,
        dateA = dateB,
        adjustment_A_back = adjustment_A,
        adjustment_A = adjustment_B
      ) %>%
      rename(cruise_B = cruise_A_back,
             dateB = dateA_back,
             adjustment_B = adjustment_A_back) %>%
      mutate(
        offset = if_else(
          parameter %in% c("salinity", "talk", "tco2"),
          -offset,
          1 / offset
        ),
        offset_adj = if_else(
          parameter %in% c("salinity", "talk", "tco2"),
          -offset_adj,
          1 / offset_adj
        )
      )

    xover_cruise <- bind_rows(xover_cruise_A,
                              xover_cruise_B_rev)

    rm(xover_cruise_A, xover_cruise_B, xover_cruise_B_rev)

    xover_cruise <- xover_cruise %>%
      group_by(cruise_A, cruise_B, dateA, dateB, parameter) %>%
      summarise(offset = mean(offset, na.rm = TRUE),
                offset_adj = mean(offset_adj, na.rm = TRUE)) %>%
      ungroup()


    xover_cruise <- left_join(xover_cruise,
                              expocodes_subbasin %>% rename(cruise_B = cruise_expocode))

    xover_cruise <- xover_cruise %>%
      mutate(decade = cut(
        dateB,
        c(1989, 1999, 2009, 2019),
        labels = c("1990-1999", "2000-2009", "2010-2019")
      )) %>%
      filter(!is.na(decade),
             !is.na(offset_adj),
             !is.na(offset)) %>%
      arrange(dateB, dateA)

    xover_cruise_stats <- xover_cruise %>%
      group_by(parameter, dateA, decade) %>%
      summarise(
        offset_adj_mean = mean(offset_adj, na.rm = TRUE),
        offset_adj_sd = sd(offset_adj, na.rm = TRUE),
        offset_adj_mean_weighted = weighted.mean(x = offset_adj, w = n, na.rm = TRUE),
        offset_adj_median = median(offset_adj, na.rm = TRUE)
      )

    xover_cruise_stats <- xover_cruise_stats %>%
      mutate(basin = i_basin,
             cruise_expocode = i_cruise_expocode)

    if (exists("xover_cruise_stats_all")) {
      xover_cruise_stats_all <-
        bind_rows(xover_cruise_stats_all, xover_cruise_stats)
    }

    if (!exists("xover_cruise_stats_all")) {
      xover_cruise_stats_all <- xover_cruise_stats
    }

  }



  for (i_decade_start in seq(1990, 2010, 10)) {
    # i_decade_start <- seq(1990, 2010, 10)[3]

    xover_subbasin_A <- xover_subbasin %>%
      filter(dateA >= i_decade_start & dateA < i_decade_start + 10)

    xover_subbasin_B <- xover_subbasin %>%
      filter(dateB >= i_decade_start & dateB < i_decade_start + 10)

    xover_subbasin_B_rev <- xover_subbasin_B %>%
      rename(
        cruise_A_back = cruise_A,
        cruise_A = cruise_B,
        dateA_back = dateA,
        dateA = dateB,
        adjustment_A_back = adjustment_A,
        adjustment_A = adjustment_B
      ) %>%
      rename(cruise_B = cruise_A_back,
             dateB = dateA_back,
             adjustment_B = adjustment_A_back) %>%
      mutate(
        offset = if_else(
          parameter %in% c("salinity", "talk", "tco2"),
          -offset,
          1 / offset
        ),
        offset_adj = if_else(
          parameter %in% c("salinity", "talk", "tco2"),
          -offset_adj,
          1 / offset_adj
        )
      )

    xover_subbasin_decade <- bind_rows(xover_subbasin_A,
                          xover_subbasin_B_rev)

    rm(xover_subbasin_A, xover_subbasin_B, xover_subbasin_B_rev)


    xover_subbasin_decade <- left_join(xover_subbasin_decade,
                          expocodes_subbasin %>% rename(cruise_A = cruise_expocode,
                                                  n_A = n))
    xover_subbasin_decade <- left_join(xover_subbasin_decade,
                          expocodes_subbasin %>% rename(cruise_B = cruise_expocode,
                                                  n_B = n))

    xover_subbasin_decade <- xover_subbasin_decade %>%
      mutate(n = n_A + n_B) %>%
      select(-starts_with("n_"))

    xover_subbasin_decade <- xover_subbasin_decade %>%
      mutate(decade = cut(
        dateB,
        c(1989, 1999, 2009, 2019),
        labels = c("1990-1999", "2000-2009", "2010-2019")
      )) %>%
      filter(!is.na(decade),
             !is.na(offset_adj),
             !is.na(offset)) %>%
      arrange(dateB, dateA)

    xover_subbasin_decade_stats <- xover_subbasin_decade %>%
      group_by(parameter, decade) %>%
      summarise(
        offset_adj_mean = mean(offset_adj, na.rm = TRUE),
        offset_adj_sd = sd(offset_adj, na.rm = TRUE),
        offset_adj_mean_weighted = weighted.mean(x = offset_adj, w = n, na.rm = TRUE),
        offset_adj_median = median(offset_adj, na.rm = TRUE)
      )

    xover_subbasin_decade_stats <- xover_subbasin_decade_stats %>%
      mutate(basin = i_basin,
             decade_start = i_decade_start)

    if (exists("xover_subbasin_decade_stats_all")) {
      xover_subbasin_decade_stats_all <-
        bind_rows(xover_subbasin_decade_stats_all, xover_subbasin_decade_stats)
    }

    if (!exists("xover_subbasin_decade_stats_all")) {
      xover_subbasin_decade_stats_all <- xover_subbasin_decade_stats
    }


    print(
      xover_subbasin_decade_stats %>%
        kable(caption = paste0(i_basin, " | ", i_decade_start, "s")) %>%
        kable_styling() %>%
        scroll_box(height = "300px")
    )


    p_crossover_ts <- xover_subbasin_decade %>%
      ggplot(aes(dateB, offset_adj)) +
      geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
      geom_point(shape = 21) +
      scale_color_brewer(palette = "Set1") +
      facet_grid(parameter ~ ., scales = "free_y") +
      labs(title = paste0(i_basin, " | ", i_decade_start, "s")) +
      theme(
        legend.position = "bottom",
        legend.direction = "vertical",
        axis.title.x = element_blank()
      )

    p_crossover_decadal <-
      ggplot() +
      geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
      geom_violin(data = xover_subbasin_decade,
                  aes(x = decade, y = offset_adj),
                  fill = "gold") +
      geom_boxplot(data = xover_subbasin_decade,
                   aes(x = decade, y = offset_adj),
                   width = 0.2) +
      facet_grid(parameter ~ ., scales = "free_y") +
      labs(title = "Decadal offsets") +
      theme(axis.title.x = element_blank(),
            axis.text.x = element_text(angle = 90))

    print(p_crossover_ts + p_crossover_decadal +
            plot_layout(widths = c(2, 1)))

    rm(p_crossover_ts, p_crossover_decadal)

  }
}

Past versions of crossover_analysis_5_basin_decadal-1.png

Version	Author	Date
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

S. Pacific | 1990s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0000910	0.0135540	1.0000372	1.0000002	S. Pacific	1990
nitrate	2000-2009	0.9987923	0.0125895	0.9997011	1.0004168	S. Pacific	1990
nitrate	2010-2019	0.9967609	0.0114346	0.9983688	0.9976484	S. Pacific	1990
oxygen	1990-1999	1.0021247	0.0675069	1.0012006	1.0000000	S. Pacific	1990
oxygen	2000-2009	1.0015645	0.0124248	1.0010338	1.0010930	S. Pacific	1990
oxygen	2010-2019	1.0062411	0.0248566	1.0092096	0.9999971	S. Pacific	1990
phosphate	1990-1999	1.0001459	0.0171707	1.0000378	1.0000000	S. Pacific	1990
phosphate	2000-2009	1.0048570	0.0130865	1.0057215	1.0030322	S. Pacific	1990
phosphate	2010-2019	1.0073893	0.0107726	1.0084500	1.0067516	S. Pacific	1990
salinity	1990-1999	0.0000000	0.0027627	0.0000000	0.0000000	S. Pacific	1990
salinity	2000-2009	-0.0004555	0.0017727	-0.0001972	0.0000000	S. Pacific	1990
salinity	2010-2019	0.0006308	0.0018835	0.0005616	0.0003744	S. Pacific	1990
silicate	1990-1999	1.0001243	0.0158518	1.0000261	1.0000000	S. Pacific	1990
silicate	2000-2009	0.9984605	0.0134817	0.9980534	0.9973000	S. Pacific	1990
silicate	2010-2019	0.9965859	0.0119938	0.9956523	0.9967000	S. Pacific	1990
talk	1990-1999	0.0000000	5.9961838	0.0000000	0.0000000	S. Pacific	1990
talk	2000-2009	-1.9069189	9.3838907	-2.2407446	0.9474929	S. Pacific	1990
talk	2010-2019	1.7413708	3.7810331	1.5103407	1.7398016	S. Pacific	1990
tco2	1990-1999	0.0000000	3.2332682	0.0000000	0.0000000	S. Pacific	1990
tco2	2000-2009	-0.5338567	2.7115335	-0.4998497	-0.7950000	S. Pacific	1990
tco2	2010-2019	-1.2565001	1.6924134	-0.9928463	-1.0330440	S. Pacific	1990

Past versions of crossover_analysis_5_basin_decadal-2.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

S. Pacific | 2000s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0013699	0.0128325	1.0003412	0.9995834	S. Pacific	2000
nitrate	2000-2009	1.0000257	0.0071848	1.0000169	1.0000000	S. Pacific	2000
nitrate	2010-2019	1.0018432	0.0064809	1.0032042	1.0010000	S. Pacific	2000
oxygen	1990-1999	0.9985873	0.0121170	0.9990006	0.9989082	S. Pacific	2000
oxygen	2000-2009	1.0001226	0.0156835	1.0000061	1.0000000	S. Pacific	2000
oxygen	2010-2019	1.0048498	0.0187485	1.0077504	1.0008366	S. Pacific	2000
phosphate	1990-1999	0.9953337	0.0129161	0.9944604	0.9969770	S. Pacific	2000
phosphate	2000-2009	1.0001405	0.0167878	1.0000473	1.0000000	S. Pacific	2000
phosphate	2010-2019	1.0023287	0.0107479	1.0075652	1.0017836	S. Pacific	2000
salinity	1990-1999	0.0004555	0.0017727	0.0001972	0.0000000	S. Pacific	2000
salinity	2000-2009	0.0000000	0.0017937	0.0000000	0.0000000	S. Pacific	2000
salinity	2010-2019	0.0013737	0.0017565	0.0007828	0.0011662	S. Pacific	2000
silicate	1990-1999	1.0017204	0.0133112	1.0020400	1.0027073	S. Pacific	2000
silicate	2000-2009	1.0000616	0.0111178	1.0000493	1.0000000	S. Pacific	2000
silicate	2010-2019	0.9971455	0.0139991	0.9957033	0.9966471	S. Pacific	2000
talk	1990-1999	1.9069189	9.3838907	2.2407446	-0.9474929	S. Pacific	2000
talk	2000-2009	0.0000000	3.6173404	0.0000000	0.0000000	S. Pacific	2000
talk	2010-2019	0.4102622	2.6715271	0.3930889	0.0754311	S. Pacific	2000
tco2	1990-1999	0.5338567	2.7115335	0.4998497	0.7950000	S. Pacific	2000
tco2	2000-2009	0.0000000	3.0902109	0.0000000	0.0000000	S. Pacific	2000
tco2	2010-2019	-0.5040925	2.7686106	-0.1939446	-0.4672284	S. Pacific	2000

Past versions of crossover_analysis_5_basin_decadal-3.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

S. Pacific | 2010s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0033810	0.0116295	1.0017172	1.0023572	S. Pacific	2010
nitrate	2000-2009	0.9982013	0.0064228	0.9968501	0.9990010	S. Pacific	2010
nitrate	2010-2019	1.0000207	0.0065305	1.0000299	1.0000000	S. Pacific	2010
oxygen	1990-1999	0.9943415	0.0223399	0.9915882	1.0000030	S. Pacific	2010
oxygen	2000-2009	0.9954891	0.0170950	0.9928671	0.9991641	S. Pacific	2010
oxygen	2010-2019	1.0001594	0.0180072	1.0006474	1.0000000	S. Pacific	2010
phosphate	1990-1999	0.9927765	0.0105861	0.9917255	0.9932937	S. Pacific	2010
phosphate	2000-2009	0.9977907	0.0107224	0.9925594	0.9982195	S. Pacific	2010
phosphate	2010-2019	1.0000294	0.0077158	1.0000333	1.0000001	S. Pacific	2010
salinity	1990-1999	-0.0006308	0.0018835	-0.0005616	-0.0003744	S. Pacific	2010
salinity	2000-2009	-0.0013737	0.0017565	-0.0007828	-0.0011662	S. Pacific	2010
salinity	2010-2019	0.0000000	0.0012701	0.0000000	0.0000000	S. Pacific	2010
silicate	1990-1999	1.0035691	0.0120731	1.0045246	1.0033109	S. Pacific	2010
silicate	2000-2009	1.0030595	0.0141461	1.0045904	1.0033641	S. Pacific	2010
silicate	2010-2019	1.0000484	0.0099059	1.0001006	1.0000001	S. Pacific	2010
talk	1990-1999	-1.7413708	3.7810331	-1.5103407	-1.7398016	S. Pacific	2010
talk	2000-2009	-0.4102622	2.6715271	-0.3930889	-0.0754311	S. Pacific	2010
talk	2010-2019	0.0000000	1.7840793	0.0000000	0.0000000	S. Pacific	2010
tco2	1990-1999	1.2565001	1.6924134	0.9928463	1.0330440	S. Pacific	2010
tco2	2000-2009	0.5040925	2.7686106	0.1939446	0.4672284	S. Pacific	2010
tco2	2010-2019	0.0000000	1.7742321	0.0000000	0.0000000	S. Pacific	2010

Past versions of crossover_analysis_5_basin_decadal-4.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Past versions of crossover_analysis_5_basin_decadal-5.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

S. Atlantic | 1990s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0002255	0.0213952	1.0002590	1.0000000	S. Atlantic	1990
nitrate	2000-2009	0.9988906	0.0322295	1.0001052	0.9991074	S. Atlantic	1990
nitrate	2010-2019	0.9998354	0.0164189	0.9986441	1.0007948	S. Atlantic	1990
oxygen	1990-1999	1.0000180	0.0060272	1.0000184	1.0000000	S. Atlantic	1990
oxygen	2000-2009	0.9999171	0.0092378	0.9987831	1.0003251	S. Atlantic	1990
oxygen	2010-2019	1.0021150	0.0087339	1.0016508	1.0015458	S. Atlantic	1990
phosphate	1990-1999	1.0001246	0.0159302	1.0001229	1.0000001	S. Atlantic	1990
phosphate	2000-2009	1.0004472	0.0207214	1.0008675	1.0003532	S. Atlantic	1990
phosphate	2010-2019	1.0041425	0.0288342	1.0018979	1.0036383	S. Atlantic	1990
salinity	1990-1999	0.0000000	0.0034319	0.0000000	0.0000000	S. Atlantic	1990
salinity	2000-2009	-0.0011322	0.0055341	-0.0009565	-0.0010000	S. Atlantic	1990
salinity	2010-2019	0.0004036	0.0029662	0.0001912	0.0004000	S. Atlantic	1990
silicate	1990-1999	1.0003375	0.0261537	1.0003305	1.0000004	S. Atlantic	1990
silicate	2000-2009	0.9901491	0.0375113	0.9922513	0.9935912	S. Atlantic	1990
silicate	2010-2019	0.9900532	0.0264099	0.9861078	0.9948350	S. Atlantic	1990
talk	1990-1999	0.0000000	1.3604734	0.0000000	0.0000000	S. Atlantic	1990
talk	2000-2009	-1.8070750	3.1753371	-2.1275570	-1.4167500	S. Atlantic	1990
talk	2010-2019	-0.5974985	2.7863374	-0.5783019	-0.8136912	S. Atlantic	1990
tco2	1990-1999	0.0000000	2.5388364	0.0000000	0.0000000	S. Atlantic	1990
tco2	2000-2009	-1.0285789	2.5567809	-1.1192790	-1.6913000	S. Atlantic	1990
tco2	2010-2019	-1.8598674	1.8542801	-1.7959912	-1.7432059	S. Atlantic	1990

Past versions of crossover_analysis_5_basin_decadal-6.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

S. Atlantic | 2000s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0020362	0.0293242	1.0008357	1.0008934	S. Atlantic	2000
nitrate	2000-2009	1.0000725	0.0121769	1.0000580	1.0000000	S. Atlantic	2000
nitrate	2010-2019	1.0016937	0.0136628	0.9999443	1.0011000	S. Atlantic	2000
oxygen	1990-1999	1.0001672	0.0092431	1.0013016	0.9996750	S. Atlantic	2000
oxygen	2000-2009	1.0000574	0.0107910	1.0000638	1.0000004	S. Atlantic	2000
oxygen	2010-2019	1.0028668	0.0090837	1.0016501	1.0032604	S. Atlantic	2000
phosphate	1990-1999	0.9999784	0.0209686	0.9994902	0.9996469	S. Atlantic	2000
phosphate	2000-2009	1.0000953	0.0140014	1.0000507	1.0000006	S. Atlantic	2000
phosphate	2010-2019	1.0081250	0.0253785	1.0092757	1.0011000	S. Atlantic	2000
salinity	1990-1999	0.0011322	0.0055341	0.0009565	0.0010000	S. Atlantic	2000
salinity	2000-2009	0.0000000	0.0049318	0.0000000	0.0000000	S. Atlantic	2000
salinity	2010-2019	0.0012337	0.0067151	0.0011848	0.0000507	S. Atlantic	2000
silicate	1990-1999	1.0114300	0.0398372	1.0087609	1.0064502	S. Atlantic	2000
silicate	2000-2009	1.0018525	0.0619886	1.0015999	1.0000000	S. Atlantic	2000
silicate	2010-2019	0.9949076	0.0361630	0.9947182	0.9938433	S. Atlantic	2000
talk	1990-1999	1.8070750	3.1753371	2.1275570	1.4167500	S. Atlantic	2000
talk	2000-2009	0.0000000	3.1065346	0.0000000	0.0000000	S. Atlantic	2000
talk	2010-2019	1.3090154	2.6701418	1.1958616	0.9447500	S. Atlantic	2000
tco2	1990-1999	1.0285789	2.5567809	1.1192790	1.6913000	S. Atlantic	2000
tco2	2000-2009	0.0000000	2.5033593	0.0000000	0.0000000	S. Atlantic	2000
tco2	2010-2019	-0.0656638	1.8481982	-0.0647531	-0.1067000	S. Atlantic	2000

Past versions of crossover_analysis_5_basin_decadal-7.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

S. Atlantic | 2010s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0004320	0.0166191	1.0016295	0.9992058	S. Atlantic	2010
nitrate	2000-2009	0.9984909	0.0136402	1.0002253	0.9989012	S. Atlantic	2010
nitrate	2010-2019	1.0000604	0.0112289	1.0000595	1.0000031	S. Atlantic	2010
oxygen	1990-1999	0.9979632	0.0085943	0.9984111	0.9984566	S. Atlantic	2010
oxygen	2000-2009	0.9972214	0.0089795	0.9984275	0.9967502	S. Atlantic	2010
oxygen	2010-2019	1.0000210	0.0065725	1.0000176	1.0000000	S. Atlantic	2010
phosphate	1990-1999	0.9966369	0.0272791	0.9988655	0.9963749	S. Atlantic	2010
phosphate	2000-2009	0.9925266	0.0239819	0.9914080	0.9989012	S. Atlantic	2010
phosphate	2010-2019	1.0001150	0.0156687	1.0000584	1.0000017	S. Atlantic	2010
salinity	1990-1999	-0.0004036	0.0029662	-0.0001912	-0.0004000	S. Atlantic	2010
salinity	2000-2009	-0.0012337	0.0067151	-0.0011848	-0.0000507	S. Atlantic	2010
salinity	2010-2019	0.0000000	0.0024898	0.0000000	0.0000000	S. Atlantic	2010
silicate	1990-1999	1.0107674	0.0275559	1.0148146	1.0051918	S. Atlantic	2010
silicate	2000-2009	1.0064439	0.0374334	1.0061670	1.0061948	S. Atlantic	2010
silicate	2010-2019	1.0001251	0.0161346	1.0001223	1.0000008	S. Atlantic	2010
talk	1990-1999	0.5974985	2.7863374	0.5783019	0.8136912	S. Atlantic	2010
talk	2000-2009	-1.3090154	2.6701418	-1.1958616	-0.9447500	S. Atlantic	2010
talk	2010-2019	0.0000000	1.7979367	0.0000000	0.0000000	S. Atlantic	2010
tco2	1990-1999	1.8598674	1.8542801	1.7959912	1.7432059	S. Atlantic	2010
tco2	2000-2009	0.0656638	1.8481982	0.0647531	0.1067000	S. Atlantic	2010
tco2	2010-2019	0.0000000	1.6005303	0.0000000	0.0000000	S. Atlantic	2010

Past versions of crossover_analysis_5_basin_decadal-8.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Past versions of crossover_analysis_5_basin_decadal-9.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Indian | 1990s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0001047	0.0145383	1.0000564	1.0000000	Indian	1990
nitrate	2000-2009	0.9998960	0.0188514	1.0000253	1.0005000	Indian	1990
nitrate	2010-2019	0.9931633	0.0102768	0.9939763	0.9933495	Indian	1990
oxygen	1990-1999	1.0000701	0.0119076	1.0000841	1.0000000	Indian	1990
oxygen	2000-2009	0.9988041	0.0103323	0.9993330	0.9998678	Indian	1990
oxygen	2010-2019	1.0026078	0.0075400	1.0011090	1.0011786	Indian	1990
phosphate	1990-1999	1.0000907	0.0135443	1.0000861	1.0000003	Indian	1990
phosphate	2000-2009	1.0021132	0.0137941	1.0022736	1.0036183	Indian	1990
phosphate	2010-2019	1.0023022	0.0107815	1.0016784	1.0031516	Indian	1990
salinity	1990-1999	0.0000000	0.0025633	0.0000000	0.0000000	Indian	1990
salinity	2000-2009	0.0009612	0.0031643	0.0003647	-0.0001000	Indian	1990
salinity	2010-2019	0.0008975	0.0047108	-0.0000274	-0.0002009	Indian	1990
silicate	1990-1999	1.0003655	0.0272635	1.0004177	1.0000000	Indian	1990
silicate	2000-2009	1.0014820	0.0228503	1.0027016	1.0046000	Indian	1990
silicate	2010-2019	1.0048879	0.0154447	1.0066379	1.0057718	Indian	1990
talk	1990-1999	0.0000000	2.9762752	0.0000000	0.0000000	Indian	1990
talk	2000-2009	1.9866327	3.2416636	2.4022193	1.9213000	Indian	1990
talk	2010-2019	2.0841410	2.8443193	2.7929988	1.9921088	Indian	1990
tco2	1990-1999	0.0000000	1.6935864	0.0000000	0.0000000	Indian	1990
tco2	2000-2009	-1.6637212	2.1444850	-1.7945690	-1.8213000	Indian	1990
tco2	2010-2019	-2.4120977	1.6739726	-2.0509233	-2.2425192	Indian	1990

Past versions of crossover_analysis_5_basin_decadal-10.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Indian | 2000s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0004543	0.0187861	1.0001531	0.9995002	Indian	2000
nitrate	2000-2009	1.0001334	0.0164388	1.0000891	1.0000003	Indian	2000
nitrate	2010-2019	0.9938363	0.0090026	0.9932698	0.9956679	Indian	2000
oxygen	1990-1999	1.0013033	0.0103625	1.0007491	1.0001322	Indian	2000
oxygen	2000-2009	1.0000399	0.0089898	1.0000443	1.0000000	Indian	2000
oxygen	2010-2019	1.0007849	0.0067417	0.9993524	1.0008785	Indian	2000
phosphate	1990-1999	0.9980782	0.0137844	0.9978779	0.9963947	Indian	2000
phosphate	2000-2009	1.0000605	0.0111217	1.0000581	1.0000007	Indian	2000
phosphate	2010-2019	1.0009060	0.0097940	1.0014515	1.0020777	Indian	2000
salinity	1990-1999	-0.0009612	0.0031643	-0.0003647	0.0001000	Indian	2000
salinity	2000-2009	0.0000000	0.0025063	0.0000000	0.0000000	Indian	2000
salinity	2010-2019	0.0018489	0.0041454	0.0017559	0.0018358	Indian	2000
silicate	1990-1999	0.9990485	0.0234314	0.9977195	0.9954211	Indian	2000
silicate	2000-2009	1.0002136	0.0208118	1.0001160	1.0000001	Indian	2000
silicate	2010-2019	1.0005760	0.0175663	1.0021476	1.0018409	Indian	2000
talk	1990-1999	-1.9866327	3.2416636	-2.4022193	-1.9213000	Indian	2000
talk	2000-2009	0.0000000	3.1999028	0.0000000	0.0000000	Indian	2000
talk	2010-2019	0.4627533	3.0967473	0.2254189	-0.1629833	Indian	2000
tco2	1990-1999	1.6637212	2.1444850	1.7945690	1.8213000	Indian	2000
tco2	2000-2009	0.0000000	3.3864853	0.0000000	0.0000000	Indian	2000
tco2	2010-2019	-0.7239355	2.5428093	-0.5062694	-0.9718994	Indian	2000

Past versions of crossover_analysis_5_basin_decadal-11.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Indian | 2010s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0069899	0.0105564	1.0061261	1.0066951	Indian	2010
nitrate	2000-2009	1.0062825	0.0091450	1.0068542	1.0043510	Indian	2010
nitrate	2010-2019	1.0000230	0.0072457	1.0000238	1.0000008	Indian	2010
oxygen	1990-1999	0.9974536	0.0074586	0.9989410	0.9988229	Indian	2010
oxygen	2000-2009	0.9992598	0.0067273	1.0006850	0.9991223	Indian	2010
oxygen	2010-2019	1.0000122	0.0052798	1.0000159	1.0000001	Indian	2010
phosphate	1990-1999	0.9978153	0.0107862	0.9984112	0.9968583	Indian	2010
phosphate	2000-2009	0.9991875	0.0098673	0.9986294	0.9979266	Indian	2010
phosphate	2010-2019	1.0000224	0.0077246	1.0000181	1.0000068	Indian	2010
salinity	1990-1999	-0.0008975	0.0047108	0.0000274	0.0002009	Indian	2010
salinity	2000-2009	-0.0018489	0.0041454	-0.0017559	-0.0018358	Indian	2010
salinity	2010-2019	0.0000000	0.0019406	0.0000000	0.0000000	Indian	2010
silicate	1990-1999	0.9953659	0.0154007	0.9936255	0.9942641	Indian	2010
silicate	2000-2009	0.9997295	0.0178870	0.9980689	0.9981628	Indian	2010
silicate	2010-2019	1.0002316	0.0230110	1.0002007	1.0000313	Indian	2010
talk	1990-1999	-2.0841410	2.8443193	-2.7929988	-1.9921088	Indian	2010
talk	2000-2009	-0.4627533	3.0967473	-0.2254189	0.1629833	Indian	2010
talk	2010-2019	0.0000000	1.1152891	0.0000000	0.0000000	Indian	2010
tco2	1990-1999	2.4120977	1.6739726	2.0509233	2.2425192	Indian	2010
tco2	2000-2009	0.7239355	2.5428093	0.5062694	0.9718994	Indian	2010
tco2	2010-2019	0.0000000	2.0059804	0.0000000	0.0000000	Indian	2010

Past versions of crossover_analysis_5_basin_decadal-12.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Past versions of crossover_analysis_5_basin_decadal-13.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

N. Atlantic | 1990s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0002216	0.0210870	1.0002478	1.0000000	N. Atlantic	1990
nitrate	2000-2009	1.0060106	0.0231158	1.0072847	1.0033558	N. Atlantic	1990
nitrate	2010-2019	1.0076626	0.0227285	1.0057461	1.0087758	N. Atlantic	1990
oxygen	1990-1999	1.0000623	0.0111770	1.0000502	1.0000000	N. Atlantic	1990
oxygen	2000-2009	1.0028432	0.0151035	1.0026438	1.0020491	N. Atlantic	1990
oxygen	2010-2019	1.0059298	0.0127849	1.0049356	1.0050855	N. Atlantic	1990
phosphate	1990-1999	1.0004435	0.0298607	1.0004353	1.0000000	N. Atlantic	1990
phosphate	2000-2009	0.9935484	0.0435414	0.9943921	0.9988462	N. Atlantic	1990
phosphate	2010-2019	1.0039893	0.0323897	1.0013460	1.0010907	N. Atlantic	1990
salinity	1990-1999	0.0000000	0.0105298	0.0000000	0.0000000	N. Atlantic	1990
salinity	2000-2009	0.0002803	0.0135644	0.0007632	0.0013000	N. Atlantic	1990
salinity	2010-2019	-0.0035802	0.0129847	-0.0023281	0.0000487	N. Atlantic	1990
silicate	1990-1999	1.0015029	0.0552438	1.0013693	1.0000000	N. Atlantic	1990
silicate	2000-2009	1.0039906	0.0533408	1.0088465	0.9985367	N. Atlantic	1990
silicate	2010-2019	0.9861506	0.0531541	0.9870197	0.9825116	N. Atlantic	1990
talk	1990-1999	0.0000000	3.0549682	0.0000000	0.0000000	N. Atlantic	1990
talk	2000-2009	0.2509969	3.3257618	0.4016342	0.0668000	N. Atlantic	1990
talk	2010-2019	-0.3766157	4.6523587	-0.4021624	-0.8105105	N. Atlantic	1990
tco2	1990-1999	0.0000000	4.3495103	0.0000000	0.0000000	N. Atlantic	1990
tco2	2000-2009	-3.0020110	3.7962001	-2.4708710	-2.9689000	N. Atlantic	1990
tco2	2010-2019	-6.7308628	5.1418767	-5.2884049	-7.7144298	N. Atlantic	1990

Past versions of crossover_analysis_5_basin_decadal-14.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

N. Atlantic | 2000s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	0.9945440	0.0226545	0.9933068	0.9966554	N. Atlantic	2000
nitrate	2000-2009	1.0002885	0.0240904	1.0002526	1.0000000	N. Atlantic	2000
nitrate	2010-2019	1.0046295	0.0177526	1.0024768	1.0053216	N. Atlantic	2000
oxygen	1990-1999	0.9973873	0.0148099	0.9976011	0.9979551	N. Atlantic	2000
oxygen	2000-2009	1.0001412	0.0168356	1.0001818	1.0000000	N. Atlantic	2000
oxygen	2010-2019	1.0038086	0.0155267	1.0027344	1.0027017	N. Atlantic	2000
phosphate	1990-1999	1.0084914	0.0459496	1.0078826	1.0011552	N. Atlantic	2000
phosphate	2000-2009	1.0007723	0.0395190	1.0009562	1.0000002	N. Atlantic	2000
phosphate	2010-2019	1.0027112	0.0173204	1.0011740	1.0012237	N. Atlantic	2000
salinity	1990-1999	-0.0002803	0.0135644	-0.0007632	-0.0013000	N. Atlantic	2000
salinity	2000-2009	0.0000000	0.0132424	0.0000000	0.0000000	N. Atlantic	2000
salinity	2010-2019	-0.0064878	0.0129637	-0.0043466	-0.0026000	N. Atlantic	2000
silicate	1990-1999	0.9988106	0.0529929	0.9940171	1.0014655	N. Atlantic	2000
silicate	2000-2009	1.0008673	0.0417936	1.0008117	1.0000000	N. Atlantic	2000
silicate	2010-2019	0.9850334	0.0343804	0.9855459	0.9869000	N. Atlantic	2000
talk	1990-1999	-0.2509969	3.3257618	-0.4016342	-0.0668000	N. Atlantic	2000
talk	2000-2009	0.0000000	3.3115850	0.0000000	0.0000000	N. Atlantic	2000
talk	2010-2019	-0.7200088	5.4773205	-1.1461204	-1.2687164	N. Atlantic	2000
tco2	1990-1999	3.0020110	3.7962001	2.4708710	2.9689000	N. Atlantic	2000
tco2	2000-2009	0.0000000	2.9059169	0.0000000	0.0000000	N. Atlantic	2000
tco2	2010-2019	-3.8259951	3.4324554	-3.0322458	-3.7469366	N. Atlantic	2000

Past versions of crossover_analysis_5_basin_decadal-15.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

N. Atlantic | 2010s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	0.9928999	0.0224797	0.9947839	0.9913006	N. Atlantic	2010
nitrate	2000-2009	0.9957013	0.0176186	0.9978117	0.9947065	N. Atlantic	2010
nitrate	2010-2019	1.0001135	0.0151827	1.0001063	1.0000000	N. Atlantic	2010
oxygen	1990-1999	0.9942633	0.0124958	0.9952196	0.9949403	N. Atlantic	2010
oxygen	2000-2009	0.9964431	0.0154126	0.9974930	0.9973055	N. Atlantic	2010
oxygen	2010-2019	1.0000370	0.0086484	1.0000302	1.0000000	N. Atlantic	2010
phosphate	1990-1999	0.9970529	0.0320720	0.9996759	0.9989105	N. Atlantic	2010
phosphate	2000-2009	0.9975853	0.0168610	0.9990935	0.9987778	N. Atlantic	2010
phosphate	2010-2019	1.0000847	0.0131231	1.0000862	1.0000001	N. Atlantic	2010
salinity	1990-1999	0.0035802	0.0129847	0.0023281	-0.0000487	N. Atlantic	2010
salinity	2000-2009	0.0064878	0.0129637	0.0043466	0.0026000	N. Atlantic	2010
salinity	2010-2019	0.0000000	0.0042167	0.0000000	0.0000000	N. Atlantic	2010
silicate	1990-1999	1.0170031	0.0556180	1.0159833	1.0177997	N. Atlantic	2010
silicate	2000-2009	1.0164748	0.0369565	1.0158553	1.0132739	N. Atlantic	2010
silicate	2010-2019	1.0002313	0.0216609	1.0002201	1.0000004	N. Atlantic	2010
talk	1990-1999	0.3766157	4.6523587	0.4021624	0.8105105	N. Atlantic	2010
talk	2000-2009	0.7200088	5.4773205	1.1461204	1.2687164	N. Atlantic	2010
talk	2010-2019	0.0000000	6.4254264	0.0000000	0.0000000	N. Atlantic	2010
tco2	1990-1999	6.7308628	5.1418767	5.2884049	7.7144298	N. Atlantic	2010
tco2	2000-2009	3.8259951	3.4324554	3.0322458	3.7469366	N. Atlantic	2010
tco2	2010-2019	0.0000000	3.2444041	0.0000000	0.0000000	N. Atlantic	2010

Past versions of crossover_analysis_5_basin_decadal-16.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

Past versions of crossover_analysis_5_basin_decadal-17.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

N. Pacific | 1990s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0000822	0.0128283	1.0001041	1.0000000	N. Pacific	1990
nitrate	2000-2009	0.9993837	0.0126450	0.9970720	0.9997000	N. Pacific	1990
nitrate	2010-2019	0.9996404	0.0107156	0.9966815	0.9986880	N. Pacific	1990
oxygen	1990-1999	1.0007308	0.0389311	1.0011947	1.0000000	N. Pacific	1990
oxygen	2000-2009	1.0076218	0.0312738	1.0042530	1.0057410	N. Pacific	1990
oxygen	2010-2019	1.0066858	0.0183370	1.0051605	1.0030434	N. Pacific	1990
phosphate	1990-1999	1.0001394	0.0167235	1.0001411	1.0000000	N. Pacific	1990
phosphate	2000-2009	0.9982351	0.0162192	0.9968676	0.9985219	N. Pacific	1990
phosphate	2010-2019	1.0059922	0.0152279	1.0030759	1.0067516	N. Pacific	1990
salinity	1990-1999	0.0000000	0.0021750	0.0000000	0.0000000	N. Pacific	1990
salinity	2000-2009	-0.0007977	0.0022377	-0.0009524	-0.0009000	N. Pacific	1990
salinity	2010-2019	-0.0010850	0.0176338	-0.0020684	0.0000190	N. Pacific	1990
silicate	1990-1999	1.0001737	0.0186622	1.0002312	1.0000000	N. Pacific	1990
silicate	2000-2009	0.9982685	0.0223113	0.9976305	0.9986708	N. Pacific	1990
silicate	2010-2019	0.9970521	0.0099473	0.9966349	0.9965594	N. Pacific	1990
talk	1990-1999	0.0000000	3.7896391	0.0000000	0.0000000	N. Pacific	1990
talk	2000-2009	0.6577284	3.1516485	1.0461176	0.4376000	N. Pacific	1990
talk	2010-2019	1.5502396	3.2648760	2.0912907	2.0013646	N. Pacific	1990
tco2	1990-1999	0.0000000	3.9913530	0.0000000	0.0000000	N. Pacific	1990
tco2	2000-2009	-0.3578554	3.8868821	-0.9168012	-0.4286000	N. Pacific	1990
tco2	2010-2019	-0.9094575	3.0694834	-1.1260676	-0.9545519	N. Pacific	1990

Past versions of crossover_analysis_5_basin_decadal-18.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

N. Pacific | 2000s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0007770	0.0126884	1.0031072	1.0003001	N. Pacific	2000
nitrate	2000-2009	1.0000429	0.0092687	1.0000381	1.0000000	N. Pacific	2000
nitrate	2010-2019	0.9990939	0.0085547	0.9992134	0.9997290	N. Pacific	2000
oxygen	1990-1999	0.9936123	0.0404782	0.9973541	0.9942918	N. Pacific	2000
oxygen	2000-2009	1.0003993	0.0283617	1.0003619	1.0000000	N. Pacific	2000
oxygen	2010-2019	1.0029198	0.0182671	1.0042679	0.9994962	N. Pacific	2000
phosphate	1990-1999	1.0020508	0.0175578	1.0034528	1.0014803	N. Pacific	2000
phosphate	2000-2009	1.0001191	0.0155168	1.0001604	1.0000000	N. Pacific	2000
phosphate	2010-2019	1.0056392	0.0110298	1.0058295	1.0062517	N. Pacific	2000
salinity	1990-1999	0.0007977	0.0022377	0.0009524	0.0009000	N. Pacific	2000
salinity	2000-2009	0.0000000	0.0021318	0.0000000	0.0000000	N. Pacific	2000
salinity	2010-2019	0.0015983	0.0043209	0.0012445	0.0013562	N. Pacific	2000
silicate	1990-1999	1.0021669	0.0195615	1.0027186	1.0013310	N. Pacific	2000
silicate	2000-2009	1.0000821	0.0128734	1.0000937	1.0000000	N. Pacific	2000
silicate	2010-2019	0.9955159	0.0084629	0.9962325	0.9955220	N. Pacific	2000
talk	1990-1999	-0.6577284	3.1516485	-1.0461176	-0.4376000	N. Pacific	2000
talk	2000-2009	0.0000000	2.9385024	0.0000000	0.0000000	N. Pacific	2000
talk	2010-2019	1.5997282	2.6393958	1.5684540	1.6458585	N. Pacific	2000
tco2	1990-1999	0.3578554	3.8868821	0.9168012	0.4286000	N. Pacific	2000
tco2	2000-2009	0.0000000	3.2420278	0.0000000	0.0000000	N. Pacific	2000
tco2	2010-2019	-0.4773818	2.7125545	-0.6948785	-0.5675000	N. Pacific	2000

Past versions of crossover_analysis_5_basin_decadal-19.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

N. Pacific | 2010s

parameter	decade	offset_adj_mean	offset_adj_sd	offset_adj_mean_weighted	offset_adj_median	basin	decade_start
nitrate	1990-1999	1.0004739	0.0107055	1.0034215	1.0013137	N. Pacific	2010
nitrate	2000-2009	1.0009802	0.0085779	1.0008379	1.0002711	N. Pacific	2010
nitrate	2010-2019	1.0000078	0.0039653	1.0000076	1.0000000	N. Pacific	2010
oxygen	1990-1999	0.9936765	0.0175353	0.9951442	0.9969659	N. Pacific	2010
oxygen	2000-2009	0.9974012	0.0172020	0.9961867	1.0005040	N. Pacific	2010
oxygen	2010-2019	1.0000412	0.0090867	1.0000264	1.0000000	N. Pacific	2010
phosphate	1990-1999	0.9942793	0.0156666	0.9971747	0.9932937	N. Pacific	2010
phosphate	2000-2009	0.9945115	0.0108789	0.9942950	0.9937871	N. Pacific	2010
phosphate	2010-2019	1.0000225	0.0067122	1.0000212	1.0000000	N. Pacific	2010
salinity	1990-1999	0.0010850	0.0176338	0.0020684	-0.0000190	N. Pacific	2010
salinity	2000-2009	-0.0015983	0.0043209	-0.0012445	-0.0013562	N. Pacific	2010
salinity	2010-2019	0.0000000	0.0031958	0.0000000	0.0000000	N. Pacific	2010
silicate	1990-1999	1.0030559	0.0099876	1.0034864	1.0034525	N. Pacific	2010
silicate	2000-2009	1.0045767	0.0085289	1.0038398	1.0044981	N. Pacific	2010
silicate	2010-2019	1.0000277	0.0074419	1.0000254	1.0000000	N. Pacific	2010
talk	1990-1999	-1.5502396	3.2648760	-2.0912907	-2.0013646	N. Pacific	2010
talk	2000-2009	-1.5997282	2.6393958	-1.5684540	-1.6458585	N. Pacific	2010
talk	2010-2019	0.0000000	3.9756474	0.0000000	0.0000000	N. Pacific	2010
tco2	1990-1999	0.9094575	3.0694834	1.1260676	0.9545519	N. Pacific	2010
tco2	2000-2009	0.4773818	2.7125545	0.6948785	0.5675000	N. Pacific	2010
tco2	2010-2019	0.0000000	2.2247482	0.0000000	0.0000000	N. Pacific	2010

Past versions of crossover_analysis_5_basin_decadal-20.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
4a7550e	jens-daniel-mueller	2022-02-15
8804a83	jens-daniel-mueller	2022-02-15
e1243c2	jens-daniel-mueller	2022-02-15

xover_subbasin_decade_stats_all <- xover_subbasin_decade_stats_all %>%
    mutate(
    basin = fct_relevel(
      basin,
      "N. Pacific",
      "S. Pacific",
      "N. Atlantic",
      "S. Atlantic",
      "Indian"
    )
  )


xover_subbasin_decade_stats_all_cstar <- xover_subbasin_decade_stats_all %>%
  filter(parameter %in% c("talk", "phosphate", "tco2")) %>%
  select(
    parameter,
    basin,
    decade,
    decade_start,
    offset_adj_mean_weighted,
  ) %>%
  pivot_wider(names_from = parameter,
              values_from = offset_adj_mean_weighted) %>%
  mutate(cstar = tco2  -
           (117 * (1 - phosphate) * 2e-6)  - 0.5 *
           (talk - (16 * (1 - phosphate) * 2e-6))) %>%
  pivot_longer(phosphate:cstar,
               values_to = "offset_adj_mean_weighted",
               names_to = "parameter")
  # filter(parameter == "cstar")



xover_subbasin_decade_stats_all_cstar %>%
  # filter(parameter %in% c("talk", "tco2", "phosphate")) %>%
  ggplot(aes(decade_start, offset_adj_mean_weighted)) +
  geom_hline(data = hline_intercept %>%
               filter(parameter %in% c("talk", "tco2", "phosphate")),
             aes(yintercept = intercept)) +
  geom_point(aes(fill = basin), shape = 21) +
  geom_line(aes(col = basin)) +
  scale_fill_brewer(palette = "Paired") +
  scale_color_brewer(palette = "Paired") +
  scale_x_continuous(breaks = seq(1990, 2010, 10)) +
  facet_grid(parameter ~ decade, scales = "free_y")

Past versions of full_decadal_crossover_analysis-1.png

Version	Author	Date
cf43743	jens-daniel-mueller	2022-02-15
4a7550e	jens-daniel-mueller	2022-02-15

xover_subbasin_decade_stats_all %>%
  filter(parameter %in% c("talk", "tco2", "phosphate")) %>%
  ggplot(aes(decade_start, offset_adj_mean_weighted)) +
  geom_hline(data = hline_intercept %>% filter(parameter %in% c("talk", "tco2", "phosphate")), aes(yintercept = intercept)) +
  geom_point(aes(fill = basin), shape = 21) +
  geom_linerange(aes(ymin = offset_adj_mean_weighted - offset_adj_sd,
                     ymax = offset_adj_mean_weighted + offset_adj_sd,
                     col = basin)) +
  geom_line(aes(col = basin)) +
  scale_fill_brewer(palette = "Paired") +
  scale_color_brewer(palette = "Paired") +
  scale_x_continuous(breaks = seq(1990, 2010, 10)) +
  facet_grid(parameter ~ decade, scales = "free_y")

Past versions of full_decadal_crossover_analysis-2.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
cf43743	jens-daniel-mueller	2022-02-15
4a7550e	jens-daniel-mueller	2022-02-15

xover_subbasin_decade_stats_all %>%
  filter(parameter %in% c("talk", "tco2", "phosphate")) %>%
  ggplot(aes(decade_start, offset_adj_mean)) +
  geom_hline(data = hline_intercept %>% filter(parameter %in% c("talk", "tco2", "phosphate")), aes(yintercept = intercept)) +
  geom_point(aes(fill = basin), shape = 21) +
  geom_line(aes(col = basin)) +
  scale_fill_brewer(palette = "Paired") +
  scale_color_brewer(palette = "Paired") +
  scale_x_continuous(breaks = seq(1990, 2010, 10)) +
  facet_grid(parameter ~ decade, scales = "free_y")

Past versions of full_decadal_crossover_analysis-3.png

Version	Author	Date
6e65117	jens-daniel-mueller	2022-02-16
cf43743	jens-daniel-mueller	2022-02-15

xover_cruise_stats_all <- xover_cruise_stats_all %>%
  mutate(basin = fct_relevel(
    basin,
    "N. Pacific",
    "S. Pacific",
    "N. Atlantic",
    "S. Atlantic",
    "Indian"
  ))

expocodes <- inner_join(GLODAP, basinmask_5)

expocodes <- expocodes %>%
  count(basin, cruise_expocode)


xover_cruise_stats_all <- left_join(xover_cruise_stats_all,
                                    expocodes)

xover_cruise_stats_all_cstar <- xover_cruise_stats_all %>%
  filter(parameter %in% c("talk", "phosphate", "tco2")) %>%
  select(parameter,
         dateA,
         basin,
         decade,
         cruise_expocode,
         n,
         offset_adj_mean_weighted,) %>%
  pivot_wider(names_from = parameter,
              values_from = offset_adj_mean_weighted) %>%
  mutate(cstar = tco2  -
           (117 * (1 - phosphate) * 2e-6)  - 0.5 *
           (talk - (16 * (1 - phosphate) * 2e-6))) %>%
  pivot_longer(phosphate:cstar,
               values_to = "offset_adj_mean_weighted",
               names_to = "parameter")
# filter(parameter == "cstar")

hline_intercept <-
  tibble(parameter = unique(xover_cruise_stats_all_cstar$parameter)) %>%
  mutate(intercept = if_else(parameter %in% c("cstar", "talk", "tco2"),
                             0,
                             1))

xover_cruise_stats_all_cstar %>%
  # filter(parameter %in% c("talk", "tco2", "phosphate")) %>%
  group_by(basin) %>%
  group_split() %>%
  # head(1) %>%
  map(
    ~ ggplot(data = .x,
             aes(dateA, offset_adj_mean_weighted, size = n)) +
      geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
      geom_point(alpha = 0.3) +
      labs(title = .x$basin) +
      facet_grid(parameter ~ decade, scales = "free_y")
  )

[[1]]

[[2]]

[[3]]

[[4]]

[[5]]

7 RV activity

GLODAP_counts <- full_join(
  GLODAP,
  GLODAP_expocodes
)

GLODAP_counts <- GLODAP_counts %>%
  mutate(decade = cut(
    year,
    seq(1990, 2020, 10),
    right = FALSE,
    labels = c("1990-1999", "2000-2009", "2010-2019")
  ), .after = year) %>%
  filter(!is.na(decade))

GLODAP_counts <- GLODAP_counts %>%
  mutate(RV = str_sub(cruise_expocode, 1, 4))

RV_activity <- GLODAP_counts %>%
  count(decade, basin_AIP, RV) %>%
  group_by(decade, basin_AIP) %>%
  mutate(n_total = sum(n)) %>%
  ungroup() %>%
  mutate(n_prop = 100* n / n_total)

RV_activity <-RV_activity %>%
  group_by(decade, basin_AIP) %>%
  mutate(rank = rank(-n_prop)) %>%
  ungroup()

RV_activity %>%
  ggplot(aes(rank, n_prop)) +
  geom_line() +
  geom_point() +
  geom_text(data = RV_activity %>% filter(n_prop > 20),
             aes(rank, n_prop, label = RV),
             nudge_x = 5) +
  labs(y = "proportion of tco2 samples (%)") +
  facet_grid(decade ~ basin_AIP)

Past versions of RV_activity-1.png

Version	Author	Date
daa43b9	jens-daniel-mueller	2021-12-06

rm(RV_activity)

8 Largest cruises

large_cruises <- GLODAP_counts %>%
  count(decade, basin_AIP, cruise_expocode) %>%
  group_by(decade, basin_AIP) %>%
  mutate(n_total = sum(n)) %>%
  ungroup() %>%
  mutate(n_prop = 100* n / n_total)

large_cruises <- large_cruises %>%
  group_by(decade, basin_AIP) %>%
  mutate(rank = rank(-n_prop)) %>%
  ungroup()


large_cruises %>%
  group_split(decade, basin_AIP) %>%
  head(1) %>%
  map(
    ~
      ggplot(data = .x,
             aes(rank, n_prop)) +
      geom_line() +
      geom_point(
        data = .x %>% filter(rank <= 5),
        aes(rank, n_prop, fill = cruise_expocode), shape = 21) +
      scale_fill_brewer(palette = "Set1") +
      xlim(0, max(large_cruises$rank)) +
      labs(y = "proportion of tco2 samples (%)") +
      facet_grid(decade ~ basin_AIP)
  )

[[1]]

Past versions of large_cruises-1.png

Version	Author	Date
9075296	jens-daniel-mueller	2022-01-12

large_cruises %>%
  filter(rank <= 5) %>%
  select(decade, basin_AIP, rank, n_prop, cruise_expocode) %>%
  mutate(n_prop = round(n_prop, 1)) %>%
  arrange(decade, basin_AIP, rank) %>%
  kable() %>%
  kable_styling() %>%
  scroll_box(height = "300px")

decade	basin_AIP	rank	n_prop	cruise_expocode
1990-1999	Atlantic	1	5.4	323019940104
1990-1999	Atlantic	2	3.9	33RO19980123
1990-1999	Atlantic	3	3.8	06AQ19980328
1990-1999	Atlantic	4	3.6	316N19970530
1990-1999	Atlantic	5	3.6	74DI19970807
1990-1999	Indian	1	8.1	316N19951202
1990-1999	Indian	2	8.0	316N19950124
1990-1999	Indian	3	7.7	316N19950310
1990-1999	Indian	4	7.3	316N19950829
1990-1999	Indian	5	7.0	316N19941201
1990-1999	Pacific	1	5.7	316N19920502
1990-1999	Pacific	2	5.6	31DS19960105
1990-1999	Pacific	3	5.6	31DS19940126
1990-1999	Pacific	4	5.5	318M19940327
1990-1999	Pacific	5	4.2	31DS19920907
2000-2009	Atlantic	1	4.6	33RO20050111
2000-2009	Atlantic	2	4.5	33RO20030604
2000-2009	Atlantic	3	4.1	06AQ20050122
2000-2009	Atlantic	4	3.5	06AQ20080210
2000-2009	Atlantic	5	2.7	35MF20080207
2000-2009	Indian	1	19.4	33RR20090320
2000-2009	Indian	2	10.4	33RR20070322
2000-2009	Indian	3	9.1	33RR20070204
2000-2009	Indian	4	9.0	33RR20080204
2000-2009	Indian	5	8.2	49NZ20031209
2000-2009	Pacific	1	7.0	33RO20071215
2000-2009	Pacific	2	6.0	318M20040615
2000-2009	Pacific	3	4.9	49NZ20030803
2000-2009	Pacific	4	4.6	49NZ20090410
2000-2009	Pacific	5	4.6	49NZ20051031
2010-2019	Atlantic	1	6.8	33RO20100308
2010-2019	Atlantic	2	6.3	33RO20130803
2010-2019	Atlantic	3	5.7	33RO20110926
2010-2019	Atlantic	4	5.5	740H20180228
2010-2019	Atlantic	5	5.1	33RO20131223
2010-2019	Indian	1	19.3	33RO20180423
2010-2019	Indian	2	18.4	33RR20160321
2010-2019	Indian	3	12.5	33RR20160208
2010-2019	Indian	4	10.5	096U20180111
2010-2019	Indian	5	9.6	325020190403
2010-2019	Pacific	1	5.9	33RO20161119
2010-2019	Pacific	2	4.1	318M20130321
2010-2019	Pacific	3	4.1	320620180309
2010-2019	Pacific	4	4.0	320620170703
2010-2019	Pacific	5	3.6	49RY20110515

rm(GLODAP_count, large_cruises)

9 Indian Ocean 1990 CRM

IO_CRM_meas <- IO_CRM_meas %>%
  fill(cruise:batch) %>%
  select(-starts_with("ph")) %>%
  rename(talk_meas = talk_ave,
         tco2_meas = tco2_ave)

CRM_ref <- CRM_ref %>%
  select(-c(date, comment, sal)) %>%
  rename(talk_ref = talk,
         tco2_ref = tco2)

IO_CRM_offset <-
  left_join(IO_CRM_meas,
            CRM_ref) %>%
  mutate(batch = as.factor(batch))

IO_CRM_offset <- IO_CRM_offset %>%
  mutate(talk_offset = talk_meas - talk_ref,
         tco2_offset = tco2_meas - tco2_ref)

IO_CRM_offset <- IO_CRM_offset %>%
  select(-c(talk_meas:talk_ref)) %>%
  pivot_longer(ends_with("_offset"),
               values_to = "offset",
               names_to = "parameter") %>%
  mutate(parameter = str_remove(parameter, "_offset"),
         start_date = mdy(start_date))

IO_CRM_offset %>%
  ggplot(aes(offset)) +
  geom_histogram(binwidth = 1) +
  facet_wrap(~ parameter)

Past versions of IO_1990_CRM-1.png

Version	Author	Date
d454df1	jens-daniel-mueller	2021-12-15

IO_CRM_offset <- IO_CRM_offset %>%
  filter(cell != "All")

IO_CRM_offset_mean <- IO_CRM_offset %>%
  group_by(parameter) %>%
  summarise(offset_mean = mean(offset),
            offset_sd = sd(offset)) %>%
  ungroup()

IO_CRM_offset %>%
  filter(parameter == "talk") %>%
  ggplot() +
  scale_fill_brewer(palette = "Set1",
                    name = "CRM batch") +
  geom_hline(data = IO_CRM_offset_mean %>% filter(parameter == "talk"),
             aes(yintercept = offset_mean)) +
  geom_hline(
    data = IO_CRM_offset_mean %>% filter(parameter == "talk"),
    aes(yintercept = offset_mean - offset_sd),
    linetype = 2
  ) +
  geom_hline(
    data = IO_CRM_offset_mean %>% filter(parameter == "talk"),
    aes(yintercept = offset_mean + offset_sd),
    linetype = 2
  ) +
  geom_point(aes(start_date, offset, fill = batch, size=n),
             shape = 21) +
  scale_size(name = "Nr of\nmeasurements") +
  labs(x = "Cruise start date",
       y = "TA offset meas-CRM (µmol/kg)",
       title = "RV Knorr IO 1990 - TA reference measurements",
       subtitle = "Data source: Tables 1 and 2 from Millero et al. (1998)")

Past versions of IO_1990_CRM-2.png

Version	Author	Date
61d5f49	jens-daniel-mueller	2021-12-15
d454df1	jens-daniel-mueller	2021-12-15

10 Write files

GLODAP  %>%
  select(-cruise_expocode) %>%
  write_csv(paste(path_preprocessing,
                  "GLODAPv2.2021_preprocessed.csv",
                  sep = ""))

GLODAP_tracer  %>%
  write_csv(paste(
    path_preprocessing,
    "GLODAPv2.2021_preprocessed_tracer.csv",
    sep = ""
  ))

GLODAP_adjustments  %>%
  write_csv(paste(path_preprocessing,
                  "GLODAPv2.2021_adustments.csv",
                  sep = ""))

# GLODAP_adjustments_NA_cruises  %>%
#   select(cruise_expocode, cruise) %>%
#   write_csv(paste(
#     path_preprocessing,
#     "GLODAPv2.2021_adustments_NA_cruises.csv",
#     sep = ""
#   ))
#
# GLODAP_adjustments_duplicated_cruises  %>%
#   drop_na() %>%
#   write_csv(
#     paste(
#       path_preprocessing,
#       "GLODAPv2.2021_adustments_duplicated_cruises.csv",
#       sep = ""
#     )
#   )

11 Overview plots

11.1 Assign coarse spatial grid

For the following plots, the cleaned data set was re-opened and observations were gridded spatially to intervals of:

• 5° x 5°

GLODAP <- m_grid_horizontal_coarse(GLODAP)

11.2 Histogram Zonal coverage

GLODAP_histogram_lat <- GLODAP %>%
  group_by(lat_grid) %>%
  tally() %>%
  ungroup()

GLODAP_histogram_lat %>%
  ggplot(aes(lat_grid, n)) +
  geom_col() +
  coord_flip() +
  theme(legend.title = element_blank())

Past versions of coverage_histogram_zonal-1.png

Version	Author	Date
98599d8	jens-daniel-mueller	2021-06-27
9d8353f	jens-daniel-mueller	2021-05-31

rm(GLODAP_histogram_lat)

11.3 Histogram temporal coverage

GLODAP_histogram_year <- GLODAP %>%
  group_by(year) %>%
  tally() %>%
  ungroup()

GLODAP_histogram_year %>%
  ggplot() +
  geom_col(aes(year, n)) +
  theme(
    axis.title.x = element_blank()
  )

Past versions of coverage_histogram_temporal-1.png

Version	Author	Date
98599d8	jens-daniel-mueller	2021-06-27
9d8353f	jens-daniel-mueller	2021-05-31

rm(GLODAP_histogram_year)

11.4 Zonal temporal coverage (Hovmoeller)

GLODAP_hovmoeller_year <- GLODAP %>%
  group_by(year, lat_grid) %>%
  tally() %>%
  ungroup()

GLODAP_hovmoeller_year %>%
  ggplot(aes(year, lat_grid, fill = log10(n))) +
  geom_tile() +
  geom_vline(xintercept = c(1999.5, 2012.5)) +
  scale_fill_viridis_c(option = "magma", direction = -1) +
  theme(legend.position = "top",
        axis.title.x = element_blank())

Past versions of coverage_hovmoeller-1.png

Version	Author	Date
98599d8	jens-daniel-mueller	2021-06-27
9d8353f	jens-daniel-mueller	2021-05-31

rm(GLODAP_hovmoeller_year)

11.5 Coverage map

map +
  geom_raster(data = GLODAP_obs_grid,
              aes(lon, lat, fill = log10(n))) +
  scale_fill_viridis_c(option = "magma",
                       direction = -1)

Past versions of coverage_map-1.png

Version	Author	Date
98599d8	jens-daniel-mueller	2021-06-27
9d8353f	jens-daniel-mueller	2021-05-31

GLODAP_obs_grid_all_vars <- GLODAP %>%
  select(year, lat, lon, cruise, sal, temp, oxygen,
         phosphate, nitrate, silicate, tco2, talk) %>%
  pivot_longer(cols = sal:talk,
               names_to = "parameter",
               values_to = "value") %>%
  mutate(presence = if_else(is.na(value), "missing", "available")) %>%
  count(year, lat, lon, parameter, presence)

GLODAP_obs_grid_all_vars_wide <- GLODAP_obs_grid_all_vars %>%
  pivot_wider(names_from = "presence",
              values_from = n,
              values_fill = 0) %>%
  mutate(ratio_available = available/(available+missing))

all_plots <- GLODAP_obs_grid_all_vars_wide %>%
  # mutate(cruise = as.factor(cruise)) %>%
  group_split(year) %>%
  # tail(3) %>%
  map(
    ~ map +
      geom_tile(
        data = .x,
        aes(
          x = lon,
          y = lat,
          width = 1,
          height = 1,
          fill = ratio_available
        )
      ) +
      scale_fill_scico(palette = "berlin",
                       limits = c(0,1)) +
      labs(title = unique(.x$year)) +
      facet_wrap(~ parameter)
  )


pdf(file = paste0(path_preprocessing, "GLODAPv2.2021_preprocessed_coverage_maps.pdf"),
    width = 10,
    height = 5)
all_plots

[[1]]

[[2]]

[[3]]

[[4]]

[[5]]

[[6]]

[[7]]

[[8]]

[[9]]

[[10]]

[[11]]

[[12]]

[[13]]

[[14]]

[[15]]

[[16]]

[[17]]

[[18]]

[[19]]

[[20]]

[[21]]

[[22]]

[[23]]

[[24]]

[[25]]

[[26]]

[[27]]

[[28]]

[[29]]

[[30]]

[[31]]

[[32]]

[[33]]

[[34]]

[[35]]

[[36]]

[[37]]

[[38]]

[[39]]

[[40]]

[[41]]

[[42]]

[[43]]

[[44]]

[[45]]

dev.off()

png
  2

11.6 Time series

GLODAP_time_series <- GLODAP %>%
  select(year, basin_AIP, lat, depth, sal, temp,
         oxygen, aou, nitrate, silicate, phosphate,
         tco2, talk)

GLODAP_time_series <- GLODAP_time_series %>%
  mutate(depth_grid = cut(depth, seq(0,1e4,1000)))

GLODAP_time_series <- GLODAP_time_series %>%
  pivot_longer(sal:talk,
               names_to = "parameter",
               values_to = "value") %>%
  filter(!is.na(value),
         !is.na(depth_grid))

GLODAP_time_series %>%
  group_split(basin_AIP, depth_grid) %>%
  # head(1) %>%
  map(
    ~ ggplot(data = .x,
             aes(year, value, col = lat)) +
      geom_jitter(alpha = 0.1) +
      scale_color_divergent() +
      facet_grid(parameter ~ depth_grid,
                 scales = "free_y") +
      labs(title = paste(
        "basin_AIP:",
        unique(.x$basin_AIP),
        "| depth_grid:",
        unique(.x$depth_grid)
      ))
  )

12 CANYON-B

12.1 Prediction

source("/net/kryo/work/uptools/co2_calculation/CANYON-B/CANYONB.R")

GLODAP_CB <- GLODAP %>%
  mutate(lon = if_else(lon > 180, lon - 360, lon)) %>%
  arrange(year) %>%
  select(row_number, year, date, lat, lon, depth, basin_AIP,
         temp, sal, oxygen,
         talk, tco2, nitrate, phosphate, silicate)

# filter rows with essential variables for Canyon-B
GLODAP_CB <- GLODAP_CB %>%
  filter(across(c(lat, lon, depth,
                  temp, sal, oxygen), ~ !is.na(.x)))

GLODAP_CB <- GLODAP_CB %>%
  mutate(as_tibble(
    CANYONB(
      date = paste0(as.character(date), " 12:00"),
      lat = lat,
      lon = lon,
      pres = depth,
      temp = temp,
      psal = sal,
      doxy = oxygen,
      param = c("AT", "CT", "NO3", "PO4", "SiOH4")
    )
  ))

GLODAP_CB <- GLODAP_CB %>%
  select(-ends_with(c("_cim", "_cin", "_cii")))


GLODAP_CB <- GLODAP_CB %>%
  rename(
    "talk_CANYONB" = "AT",
    "tco2_CANYONB" = "CT",
    "nitrate_CANYONB" = "NO3",
    "phosphate_CANYONB" = "PO4",
    "silicate_CANYONB" = "SiOH4"
  )

12.2 Comparison to observations

variables <- c("talk", "tco2", "nitrate", "phosphate", "silicate")

for (i_variable in variables) {
  # i_variable <- variables[1]

  # calculate equal axis limits and binwidth
  axis_lims <- GLODAP_CB %>%
    drop_na() %>%
    summarise(max_value = max(c(max(
      !!sym(i_variable)
    ),
    max(!!sym(
      paste0(i_variable, "_CANYONB")
    )))),
    min_value = min(c(min(
      !!sym(i_variable)
    ),
    min(!!sym(
      paste0(i_variable, "_CANYONB")
    )))))

  binwidth_value <- (axis_lims$max_value - axis_lims$min_value) / 60
  axis_lims <- c(axis_lims$min_value, axis_lims$max_value)

  print(
    ggplot(GLODAP_CB, aes(
      x = !!sym(i_variable),
      y = !!sym(paste0(i_variable, "_CANYONB"))
    )) +
      geom_bin2d(binwidth = binwidth_value) +
      scale_fill_viridis_c(trans = "log10") +
      geom_abline(slope = 1, col = 'red') +
      coord_equal(xlim = axis_lims,
                  ylim = axis_lims) +
      facet_wrap( ~ basin_AIP) +
      labs(title = "All years")
  )


  # for (i_year in unique(GLODAP_CB$year)) {
  #   # i_year <- 2017
  #
  #   print(
  #     ggplot(
  #       GLODAP_CB %>% filter(year == i_year),
  #       aes(x = !!sym(i_variable),
  #           y = !!sym(paste0(
  #             i_variable, "_CANYONB"
  #           )))
  #     ) +
  #       geom_bin2d(binwidth = binwidth_value) +
  #       scale_fill_viridis_c(trans = "log10") +
  #       geom_abline(slope = 1, col = 'red') +
  #       coord_equal(xlim = axis_lims,
  #                   ylim = axis_lims) +
  #       facet_wrap( ~ basin_AIP) +
  #       labs(title = paste("Year:", i_year))
  #   )
  # }

}

12.3 Write files

GLODAP_CB %>%
  select(row_number,
         talk_CANYONB, tco2_CANYONB,
         nitrate_CANYONB, phosphate_CANYONB, silicate_CANYONB) %>%
  write_csv(paste(path_preprocessing,
                             "GLODAPv2.2021_Canyon-B.csv",
                             sep = ""))

13 Crossover data

GLODAP_CB <-
  read_csv(paste(path_preprocessing,
                 "GLODAPv2.2021_Canyon-B.csv",
                 sep = ""))

cruises_phosphate_gap_fill <-
  c("33MW19930704",
    "33RO20030604",
    "33RO20050111",
    "33RO19980123")

cruises_talk_gap_fill <-
  c("06AQ19980328")

cruises_tco2_calc <-
  c("35TH20040604",
    "29AH20160617")

cruises_talk_calc <-
  c("06MT19900123",
    "316N19920502",
    "316N19921006")

xover_add_decade <- glodapv2_2021_xover_add %>%
  mutate(dateA = ymd(str_sub(cruise_A, 5, 12)),
         dateB = ymd(str_sub(cruise_B, 5, 12))) %>%
  mutate(decade = cut(
    year(dateB),
    c(1989, 1999, 2009, 2019),
    labels = c("1989-1999", "2000-2009", "2010-2019")
  )) %>%
  filter(!is.na(decade),
         !is.na(offset)) %>%
  arrange(dateB)

xover_add_decade %>%
  group_by(parameter, cruise_A) %>%
  summarise(offset_mean = mean(offset, na.rm = TRUE)) %>%
  ungroup() %>%
  kable(caption = "Long-term average per cruise and parameter") %>%
  kable_styling() %>%
  scroll_box(height = "250px")

Long-term average per cruise and parameter

parameter	cruise_A	offset_mean
phosphate	06AQ19980328	1.0076477
phosphate	06MT19900123	0.9952731
phosphate	29AH20160617	0.9848944
phosphate	316N19920502	1.0081928
phosphate	316N19921006	1.0099657
phosphate	33MW19930704	0.9890182
phosphate	33RO19980123	0.9965710
phosphate	33RO20030604	0.9966745
phosphate	33RO20050111	1.0019318
phosphate	35TH20040604	0.9740753
talk	06AQ19980328	0.5163006
talk	06MT19900123	-3.5574819
talk	29AH20160617	1.5479474
talk	316N19920502	-4.3333542
talk	316N19921006	-1.0527798
talk	33MW19930704	-0.6041569
talk	33RO19980123	-0.8518579
talk	33RO20030604	-1.8164213
talk	33RO20050111	1.6308865
talk	35TH20040604	0.3672771
tco2	06AQ19980328	-0.5510192
tco2	06MT19900123	-2.6515513
tco2	29AH20160617	6.3313796
tco2	316N19920502	0.2705865
tco2	316N19921006	0.7551445
tco2	33MW19930704	-1.3349429
tco2	33RO19980123	0.5594899
tco2	33RO20030604	-0.7151763
tco2	33RO20050111	-0.3622474
tco2	35TH20040604	1.2796712

xover_add_decade %>%
  group_by(parameter, decade, cruise_A) %>%
  summarise(offset_mean = mean(offset, na.rm = TRUE)) %>%
  ungroup() %>%
  kable(caption = "Decadal average per cruise and parameter") %>%
  kable_styling() %>%
  scroll_box(height = "250px")

Decadal average per cruise and parameter

parameter	decade	cruise_A	offset_mean
phosphate	1989-1999	06AQ19980328	1.0088276
phosphate	1989-1999	06MT19900123	0.9925257
phosphate	1989-1999	29AH20160617	0.9796380
phosphate	1989-1999	316N19920502	1.0067578
phosphate	1989-1999	316N19921006	1.0017277
phosphate	1989-1999	33MW19930704	0.9882398
phosphate	1989-1999	33RO19980123	0.9952849
phosphate	1989-1999	33RO20030604	1.0012928
phosphate	1989-1999	33RO20050111	1.0009821
phosphate	1989-1999	35TH20040604	0.9712452
phosphate	2000-2009	06AQ19980328	1.0053414
phosphate	2000-2009	06MT19900123	1.0010033
phosphate	2000-2009	29AH20160617	0.9899738
phosphate	2000-2009	316N19920502	1.0075795
phosphate	2000-2009	316N19921006	1.0137857
phosphate	2000-2009	33MW19930704	0.9846140
phosphate	2000-2009	33RO19980123	1.0037495
phosphate	2000-2009	33RO20030604	0.9921003
phosphate	2000-2009	33RO20050111	1.0025604
phosphate	2000-2009	35TH20040604	0.9765408
phosphate	2010-2019	06AQ19980328	1.0092836
phosphate	2010-2019	06MT19900123	0.9922316
phosphate	2010-2019	29AH20160617	0.9904749
phosphate	2010-2019	316N19920502	1.0127004
phosphate	2010-2019	316N19921006	1.0143839
phosphate	2010-2019	33MW19930704	0.9964602
phosphate	2010-2019	33RO19980123	0.9950980
phosphate	2010-2019	33RO20030604	0.9944871
phosphate	2010-2019	33RO20050111	1.0032793
phosphate	2010-2019	35TH20040604	0.9766304
talk	1989-1999	06AQ19980328	4.2986091
talk	1989-1999	06MT19900123	-1.7866112
talk	1989-1999	29AH20160617	1.5510114
talk	1989-1999	316N19920502	-0.0551690
talk	1989-1999	316N19921006	0.4878711
talk	1989-1999	33MW19930704	-0.6029753
talk	1989-1999	33RO19980123	0.1289735
talk	1989-1999	33RO20030604	-2.6727990
talk	1989-1999	33RO20050111	1.2382129
talk	1989-1999	35TH20040604	0.3314651
talk	2000-2009	06AQ19980328	-0.2162355
talk	2000-2009	06MT19900123	-4.0659303
talk	2000-2009	29AH20160617	2.3884257
talk	2000-2009	316N19920502	-4.0265274
talk	2000-2009	316N19921006	-0.9215473
talk	2000-2009	33MW19930704	-0.3195600
talk	2000-2009	33RO19980123	-5.2032065
talk	2000-2009	33RO20030604	-0.9500663
talk	2000-2009	33RO20050111	1.2662351
talk	2000-2009	35TH20040604	1.1230941
talk	2010-2019	06AQ19980328	0.7206032
talk	2010-2019	06MT19900123	-3.9344689
talk	2010-2019	29AH20160617	-0.1395747
talk	2010-2019	316N19920502	-6.9326869
talk	2010-2019	316N19921006	-2.7246632
talk	2010-2019	33MW19930704	-0.9855887
talk	2010-2019	33RO19980123	0.3001826
talk	2010-2019	33RO20030604	-1.7612909
talk	2010-2019	33RO20050111	1.8786579
talk	2010-2019	35TH20040604	-1.0676170
tco2	1989-1999	06AQ19980328	1.1144077
tco2	1989-1999	06MT19900123	-0.2131875
tco2	1989-1999	29AH20160617	8.1120081
tco2	1989-1999	316N19920502	0.1582007
tco2	1989-1999	316N19921006	0.2100602
tco2	1989-1999	33MW19930704	-0.1342253
tco2	1989-1999	33RO19980123	0.4187870
tco2	1989-1999	33RO20030604	0.8379332
tco2	1989-1999	33RO20050111	1.4562572
tco2	1989-1999	35TH20040604	2.7288076
tco2	2000-2009	06AQ19980328	-1.3551591
tco2	2000-2009	06MT19900123	-3.4099140
tco2	2000-2009	29AH20160617	6.1180167
tco2	2000-2009	316N19920502	0.5997351
tco2	2000-2009	316N19921006	0.8386702
tco2	2000-2009	33MW19930704	-1.6191444
tco2	2000-2009	33RO19980123	1.0463619
tco2	2000-2009	33RO20030604	-1.2259491
tco2	2000-2009	33RO20050111	1.0973981
tco2	2000-2009	35TH20040604	1.2641341
tco2	2010-2019	06AQ19980328	-1.1823577
tco2	2010-2019	06MT19900123	-3.9523709
tco2	2010-2019	29AH20160617	1.1923250
tco2	2010-2019	316N19920502	-0.1669434
tco2	2010-2019	316N19921006	1.2167030
tco2	2010-2019	33MW19930704	-3.8756236
tco2	2010-2019	33RO19980123	0.4491628
tco2	2010-2019	33RO20030604	-2.5484791
tco2	2010-2019	33RO20050111	-2.0013224
tco2	2010-2019	35TH20040604	-3.0344442

xover_add_decade %>%
  filter(cruise_A %in% cruises_talk_calc,
         parameter == "talk") %>%
  group_by(parameter, decade, cruise_A) %>%
  summarise(offset_mean = mean(offset, na.rm = TRUE)) %>%
  ungroup() %>%
  kable(caption = "Decadal talk average per cruise") %>%
  kable_styling() %>%
  scroll_box(height = "250px")

Decadal talk average per cruise

parameter	decade	cruise_A	offset_mean
talk	1989-1999	06MT19900123	-1.7866112
talk	1989-1999	316N19920502	-0.0551690
talk	1989-1999	316N19921006	0.4878711
talk	2000-2009	06MT19900123	-4.0659303
talk	2000-2009	316N19920502	-4.0265274
talk	2000-2009	316N19921006	-0.9215473
talk	2010-2019	06MT19900123	-3.9344689
talk	2010-2019	316N19920502	-6.9326869
talk	2010-2019	316N19921006	-2.7246632

xover_add_decade %>%
  filter(cruise_A %in% cruises_talk_calc,
         parameter == "talk") %>%
  group_by(parameter, decade) %>%
  summarise(offset_mean = mean(offset, na.rm = TRUE)) %>%
  ungroup() %>%
  kable(caption = "Decadal talk average") %>%
  kable_styling() %>%
  scroll_box(height = "250px")

Decadal talk average

parameter	decade	offset_mean
talk	1989-1999	-0.7851301
talk	2000-2009	-3.6581063
talk	2010-2019	-4.6182733

xover_add_decade %>%
  filter(cruise_A %in% cruises_talk_calc,
         parameter == "talk") %>%
  group_by(parameter) %>%
  summarise(offset_mean = mean(offset, na.rm = TRUE)) %>%
  ungroup() %>%
  kable(caption = "talk average") %>%
  kable_styling() %>%
  scroll_box(height = "250px")

talk average

parameter	offset_mean
talk	-3.407015

xover_add_decade %>%
  filter(cruise_A %in% cruises_talk_calc,
         parameter == "talk") %>%
  group_by(parameter, cruise_A) %>%
  summarise(offset_mean = mean(offset, na.rm = TRUE)) %>%
  ungroup() %>%
  kable(caption = "talk average per cruise") %>%
  kable_styling() %>%
  scroll_box(height = "250px")

talk average per cruise

parameter	cruise_A	offset_mean
talk	06MT19900123	-3.557482
talk	316N19920502	-4.333354
talk	316N19921006	-1.052780

hline_intercept <- hline_intercept %>%
  filter(parameter %in% unique(xover_add_decade$parameter))


p_crossover_ts <- xover_add_decade %>%
  ggplot(aes(dateB, offset)) +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  geom_point(shape = 21) +
  scale_color_brewer(palette = "Set1") +
  facet_grid(parameter ~ ., scales = "free_y") +
  theme(
    legend.position = "bottom",
    legend.direction = "vertical",
    axis.title.x = element_blank()
  )

p_crossover_decadal <-
  ggplot() +
  geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
  geom_violin(data = xover_add_decade,
               aes(x = decade, y = offset), fill="gold") +
  geom_boxplot(data = xover_add_decade,
               aes(x = decade, y = offset),
               width = 0.2) +
  facet_grid(parameter ~ ., scales = "free_y") +
  labs(title = "Decadal offsets") +
  theme(axis.title.x = element_blank(),
        axis.text.x = element_text(angle = 90))


p_crossover_ts + p_crossover_decadal +
  plot_layout(widths = c(2, 1))

Past versions of prepare_additional_crossover_data-1.png

Version	Author	Date
ecc669f	jens-daniel-mueller	2022-01-04
494beda	jens-daniel-mueller	2022-01-03

13.1 Gap filling

GLODAP <- left_join(GLODAP,
                    GLODAP_CB %>%
                      select(row_number, ends_with("_CANYONB")))

# fill missing phosphate with CANYON-B estimate

GLODAP_phosphate_fill <- GLODAP %>%
  filter(cruise_expocode %in% cruises_phosphate_gap_fill,
         is.na(phosphate),
         oxygenqc == 1)

GLODAP_phosphate_fill <- GLODAP_phosphate_fill %>%
  mutate(phosphate = phosphate_CANYONB) %>%
  filter(!is.na(phosphate))

map +
  geom_tile(data = GLODAP_phosphate_fill %>%
              distinct(lon, lat, cruise_expocode),
            aes(lon, lat, fill = cruise_expocode)) +
  scale_fill_brewer(palette = "Set1")

Past versions of CANYON-B_gap_filling-1.png

Version	Author	Date
494beda	jens-daniel-mueller	2022-01-03

for (i_cruise in cruises_phosphate_gap_fill) {
  # i_cruise <- cruises_phosphate_gap_fill[1]

  p_crossover_ts <- xover_add_decade %>%
    filter(cruise_A %in% i_cruise) %>%
    ggplot(aes(dateB, offset)) +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_point(shape = 21) +
    scale_color_brewer(palette = "Set1") +
    facet_grid(parameter ~ ., scales = "free_y") +
    labs(title = i_cruise) +
    theme(
      legend.position = "bottom",
      legend.direction = "vertical",
      axis.title.x = element_blank()
    )

  p_crossover_decadal <-
    ggplot() +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_violin(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      fill = "gold"
    ) +
    geom_boxplot(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      width = 0.2
    ) +
    facet_grid(parameter ~ ., scales = "free_y") +
    theme(axis.title.x = element_blank(),
          axis.text.x = element_text(angle = 90))

  print(
  p_crossover_ts + p_crossover_decadal +
    plot_layout(widths = c(2, 1))
  )

}

Past versions of CANYON-B_gap_filling-2.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

Past versions of CANYON-B_gap_filling-3.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

Past versions of CANYON-B_gap_filling-4.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

Past versions of CANYON-B_gap_filling-5.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

# fill missing talk with CANYON-B estimate

GLODAP_talk_fill <- GLODAP %>%
  filter(cruise_expocode %in% cruises_talk_gap_fill,
         is.na(talk),
         oxygenqc == 1)

GLODAP_talk_fill <- GLODAP_talk_fill %>%
  mutate(talk = talk_CANYONB) %>%
  filter(!is.na(talk))


map +
  geom_tile(data = GLODAP_talk_fill %>%
              distinct(lon, lat, cruise_expocode),
            aes(lon, lat, fill = cruise_expocode)) +
  scale_fill_brewer(palette = "Set1")

Past versions of CANYON-B_gap_filling-6.png

Version	Author	Date
494beda	jens-daniel-mueller	2022-01-03

for (i_cruise in cruises_talk_gap_fill) {
  # i_cruise <- cruises_phosphate_gap_fill[1]

  p_crossover_ts <- xover_add_decade %>%
    filter(cruise_A %in% i_cruise) %>%
    ggplot(aes(dateB, offset)) +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_point(shape = 21) +
    scale_color_brewer(palette = "Set1") +
    facet_grid(parameter ~ ., scales = "free_y") +
    labs(title = i_cruise) +
    theme(
      legend.position = "bottom",
      legend.direction = "vertical",
      axis.title.x = element_blank()
    )

  p_crossover_decadal <-
    ggplot() +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_violin(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      fill = "gold"
    ) +
    geom_boxplot(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      width = 0.2
    ) +
    facet_grid(parameter ~ ., scales = "free_y") +
    theme(axis.title.x = element_blank(),
          axis.text.x = element_text(angle = 90))

  print(p_crossover_ts + p_crossover_decadal +
          plot_layout(widths = c(2, 1)))

}

Past versions of CANYON-B_gap_filling-7.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

GLODAP_gap_fill <- bind_rows(
  GLODAP_phosphate_fill,
  GLODAP_talk_fill
)

13.2 Flagging

GLODAP_tco2_calc <- GLODAP %>%
  filter(cruise_expocode %in% cruises_tco2_calc,
         tco2f == 0)


map +
  geom_tile(data = GLODAP_tco2_calc %>%
              distinct(lon, lat, cruise_expocode),
            aes(lon, lat, fill = cruise_expocode)) +
  scale_fill_brewer(palette = "Set1")

Past versions of flagged_cruises-1.png

Version	Author	Date
494beda	jens-daniel-mueller	2022-01-03

for (i_cruise in cruises_tco2_calc) {
  # i_cruise <- cruises_phosphate_gap_fill[1]

  p_crossover_ts <- xover_add_decade %>%
    filter(cruise_A %in% i_cruise) %>%
    ggplot(aes(dateB, offset)) +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_point(shape = 21) +
    scale_color_brewer(palette = "Set1") +
    facet_grid(parameter ~ ., scales = "free_y") +
    labs(title = i_cruise) +
    theme(
      legend.position = "bottom",
      legend.direction = "vertical",
      axis.title.x = element_blank()
    )

  p_crossover_decadal <-
    ggplot() +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_violin(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      fill = "gold"
    ) +
    geom_boxplot(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      width = 0.2
    ) +
    facet_grid(parameter ~ ., scales = "free_y") +
    theme(axis.title.x = element_blank(),
          axis.text.x = element_text(angle = 90))

  print(p_crossover_ts + p_crossover_decadal +
          plot_layout(widths = c(2, 1)))

}

Past versions of flagged_cruises-2.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

Past versions of flagged_cruises-3.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

GLODAP_talk_calc <- GLODAP %>%
  filter(cruise_expocode %in% cruises_talk_calc,
         talkf == 0)


map +
  geom_tile(data = GLODAP_talk_calc %>%
              distinct(lon, lat, cruise_expocode),
            aes(lon, lat, fill = cruise_expocode)) +
  scale_fill_brewer(palette = "Set1")

Past versions of flagged_cruises-4.png

Version	Author	Date
494beda	jens-daniel-mueller	2022-01-03

for (i_cruise in cruises_talk_calc) {
  # i_cruise <- cruises_phosphate_gap_fill[1]

  p_crossover_ts <- xover_add_decade %>%
    filter(cruise_A %in% i_cruise) %>%
    ggplot(aes(dateB, offset)) +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_point(shape = 21) +
    scale_color_brewer(palette = "Set1") +
    facet_grid(parameter ~ ., scales = "free_y") +
    labs(title = i_cruise) +
    theme(
      legend.position = "bottom",
      legend.direction = "vertical",
      axis.title.x = element_blank()
    )

  p_crossover_decadal <-
    ggplot() +
    geom_hline(data = hline_intercept, aes(yintercept = intercept)) +
    geom_violin(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      fill = "gold"
    ) +
    geom_boxplot(
      data = xover_add_decade %>%
        filter(cruise_A %in% i_cruise),
      aes(x = decade, y = offset),
      width = 0.2
    ) +
    facet_grid(parameter ~ ., scales = "free_y") +
    theme(axis.title.x = element_blank(),
          axis.text.x = element_text(angle = 90))

  print(
  p_crossover_ts + p_crossover_decadal +
    plot_layout(widths = c(2, 1))
  )

}

Past versions of flagged_cruises-5.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

Past versions of flagged_cruises-6.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

Past versions of flagged_cruises-7.png

Version	Author	Date
1a9c797	jens-daniel-mueller	2022-01-03
494beda	jens-daniel-mueller	2022-01-03

GLODAP_calc <- bind_rows(
  GLODAP_tco2_calc,
  GLODAP_talk_calc
)

13.3 Write files

GLODAP_crossover <- bind_rows(
  GLODAP_gap_fill,
  GLODAP_calc
)

GLODAP_crossover_write <- GLODAP_crossover %>%
  select(
    EXPOCODE = cruise_expocode,
    STNNBR = station,
    CASTNO = cast,
    BTLNBR = bottle,
    DATE = date,
    LATITUDE = lat,
    LONGITUDE = lon,
    CTDPRS = pressure,
    CTDTMP = temp,
    CTDSAL = sal,
    CTDSAL_FLAG_W = salinityf,
    PHSPHT = phosphate,
    PHSPHT_FLAG_W = phosphatef,
    TCARBN = tco2,
    TCARBN_FLAG_W = tco2f,
    ALKALI = talk,
    ALKALI_FLAG_W = talkf)

GLODAP_crossover_write <- GLODAP_crossover_write %>%
  mutate(DATE = format(DATE,  "%Y%m%d"))


last_line <- "END_DATA"

for (i_EXPOCODE in unique(GLODAP_crossover_write$EXPOCODE)) {
  # i_EXPOCODE <- unique(GLODAP_crossover_write$EXPOCODE)[1]

  temp <- GLODAP_crossover_write %>%
    filter(EXPOCODE == i_EXPOCODE) %>%
    add_row(.before = 1)

  cat("Bottle",
      "\n",
      file = paste0(
        path_preprocessing,
        "crossover_cruises/",
        i_EXPOCODE,
        ".exc.csv"
      )
    )

  temp %>%
    write_csv(
      file = paste0(
        path_preprocessing,
        "crossover_cruises/",
        i_EXPOCODE,
        ".exc.csv"
      ),
      na = "",
      append = TRUE,
      col_names = TRUE
    )

  write(
    last_line,
    file = paste0(
      path_preprocessing,
      "crossover_cruises/",
      i_EXPOCODE,
      ".exc.csv"
    ),
    append = TRUE
  )


}

Session information

sessionInfo()

R version 4.1.2 (2021-11-01)
Platform: x86_64-pc-linux-gnu (64-bit)
Running under: openSUSE Leap 15.3

Matrix products: default
BLAS:   /usr/local/R-4.1.2/lib64/R/lib/libRblas.so
LAPACK: /usr/local/R-4.1.2/lib64/R/lib/libRlapack.so

locale:
 [1] LC_CTYPE=en_US.UTF-8       LC_NUMERIC=C
 [3] LC_TIME=en_US.UTF-8        LC_COLLATE=en_US.UTF-8
 [5] LC_MONETARY=en_US.UTF-8    LC_MESSAGES=en_US.UTF-8
 [7] LC_PAPER=en_US.UTF-8       LC_NAME=C
 [9] LC_ADDRESS=C               LC_TELEPHONE=C
[11] LC_MEASUREMENT=en_US.UTF-8 LC_IDENTIFICATION=C

attached base packages:
[1] stats     graphics  grDevices utils     datasets  methods   base

other attached packages:
 [1] kableExtra_1.3.4 ggrepel_0.9.1    lubridate_1.8.0  ggforce_0.3.3
 [5] metR_0.11.0      scico_1.3.0      patchwork_1.1.1  collapse_1.7.0
 [9] forcats_0.5.1    stringr_1.4.0    dplyr_1.0.7      purrr_0.3.4
[13] readr_2.1.1      tidyr_1.1.4      tibble_3.1.6     ggplot2_3.3.5
[17] tidyverse_1.3.1  workflowr_1.7.0

loaded via a namespace (and not attached):
 [1] nlme_3.1-155       fs_1.5.2           bit64_4.0.5        RColorBrewer_1.1-2
 [5] webshot_0.5.2      httr_1.4.2         rprojroot_2.0.2    tools_4.1.2
 [9] backports_1.4.1    bslib_0.3.1        utf8_1.2.2         R6_2.5.1
[13] mgcv_1.8-38        DBI_1.1.2          colorspace_2.0-2   withr_2.4.3
[17] tidyselect_1.1.1   processx_3.5.2     bit_4.0.4          compiler_4.1.2
[21] git2r_0.29.0       cli_3.1.1          rvest_1.0.2        xml2_1.3.3
[25] labeling_0.4.2     sass_0.4.0         scales_1.1.1       checkmate_2.0.0
[29] callr_3.7.0        systemfonts_1.0.3  digest_0.6.29      svglite_2.0.0
[33] rmarkdown_2.11     pkgconfig_2.0.3    htmltools_0.5.2    highr_0.9
[37] dbplyr_2.1.1       fastmap_1.1.0      rlang_0.4.12       readxl_1.3.1
[41] rstudioapi_0.13    jquerylib_0.1.4    generics_0.1.1     farver_2.1.0
[45] jsonlite_1.7.3     vroom_1.5.7        magrittr_2.0.1     Matrix_1.4-0
[49] Rcpp_1.0.8         munsell_0.5.0      fansi_1.0.2        lifecycle_1.0.1
[53] stringi_1.7.6      whisker_0.4        yaml_2.2.1         MASS_7.3-55
[57] grid_4.1.2         parallel_4.1.2     promises_1.2.0.1   crayon_1.4.2
[61] lattice_0.20-45    splines_4.1.2      haven_2.4.3        hms_1.1.1
[65] knitr_1.37         ps_1.6.0           pillar_1.6.4       reprex_2.0.1
[69] glue_1.6.0         evaluate_0.14      getPass_0.2-2      data.table_1.14.2
[73] modelr_0.1.8       vctrs_0.3.8        tzdb_0.2.0         tweenr_1.0.2
[77] httpuv_1.6.5       cellranger_1.1.0   gtable_0.3.0       polyclip_1.10-0
[81] assertthat_0.2.1   xfun_0.29          broom_0.7.11       later_1.3.0
[85] viridisLite_0.4.0  ellipsis_0.3.2
